LG 37LG710H Owner's Manual

Hide thumbs Also See for 37LG710H:
Table of Contents

Advertisement

Quick Links

See also: Setup Manual
OWNER'S MANUAL
LCD TV
Please read this manual carefully before operating
your set and retain it for future reference.
32LG710H
32LD650H
37LG710H
37LD650H
42LG710H
42LD650H
47LD650H
55LD650H
P/NO : SAC34134301 (1101-REV04)
32LD655H
37LD655H
42LD655H
www.lg.com

Advertisement

Table of Contents
loading

Related Manuals for LG 37LG710H

Summary of Contents for LG 37LG710H

  • Page 1 OWNER’S MANUAL LCD TV Please read this manual carefully before operating your set and retain it for future reference. 32LG710H 32LD650H 32LD655H 37LG710H 37LD650H 37LD655H 42LG710H 42LD650H 42LD655H 47LD650H 55LD650H www.lg.com P/NO : SAC34134301 (1101-REV04)

  • Page 2: Warning / Caution

    Do not attempt to modify this product in any way as practical. without written authorization from LG Electronics. Unauthorized modification could void the user’s authority to operate this product...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Protect the power cord from being walked on or pinched particularly at plugs, convenience recepta- Keep these instructions. cles, and the point where they exit from the appara- tus. Heed all warnings. Follow all instructions.
  • Page 4 CAUTION concerning the Power Cord : Do not expose to dripping or splashing and do not It is recommend that appliances be placed upon a place objects filled with liquids, such as vases, cups, dedicated circuit; that is, a single outlet circuit which etc.
  • Page 5 A A N N T T E E N N N N A A S S V V e e n n t t i i l l a a t t i i o o n n Install your TV where there is proper ventilation. Do O O u u t t d d o o o o r r a a n n t t e e n n n n a a g g r r o o u u n n d d i i n n g g not install in a confined space such as a bookcase.

  • Page 6: Table Of Contents

    CONTENTS WARNING / CAUTION Photo List ............
  • Page 7 TIME SETTING Clock Setting - Auto Clock Setup ........- Manual Clock Setup .

  • Page 8: Features Of This Tv

    TruSurround XT technology is incorporated under Unlike other sensors which can only sense brightness license from SRS Labs, Inc. of ambient light, LG’s “Intelligent Sensor” uses 4,096 sensing steps to evaluate its surroundings. Using a Automatically enhances and amplifies the sound of...

  • Page 9: Accessories

    PREPERATION ACCESSORIES Ensure that the following accessories are included with your TV. If an accessory is missing, please contact the dealer where you purchased the TV. The accessories included may differ from the images below. CD Manual Owner’s Manual 1.5V 1.5V Power Cord Torx plus Remote Control,...

  • Page 10: Front Panel Information

    PREPARATION PREPARATION FRONT PANEL INFORMATION Image shown may differ from your TV. 32/37/42LG710H CHANNEL( Buttons VOLUME (+, -) Intelligent Sensor Buttons Adjusts picture according to the surrounding conditions. ENTER ENTER Button MENU MENU Button Power/Standby Indicator Illuminates red in standby mode. INPUT INPUT Button Illuminates blue when the set is...
  • Page 11 32/37/42/47/55LD650H, 32/37/42LD655H CHANNEL( Buttons VOLUME (+, -) Buttons ENTER SPEAKER ENTER Button MENU MENU Button INPUT Power/Standby Indicator INPUT Button Illuminates red in standby mode. POWER Button Illuminates blue when the set is switched on. Remote Control Sensor Intelligent Sensor Adjusts picture according to the surrounding condi- tions.

  • Page 12: Back Panel Information

    PREPARATION BACK PANEL INFORMATION Image shown may differ from your TV. 32/37/42LG710H M.P.I. M.P.I. ANTENNA IN ANTENNA IN GAME TV-LINK CONTROL OPTICAL SPEAKER OUT HDMI/DVI IN DIGITAL (SERVICE ONLY) AUDIO OUT RESET UPDATE RS-232C IN REMOTE AUDIO (SERVICE ONLY) CONTROL OUT RGB(PC) (RGB/DVI) 1(DVI)
  • Page 13 32/37/42LD650H, 32/37/42LD655H M.P.I. M.P.I. ANTENNA IN ANTENNA IN AC IN GAME CONTROL RESET UPDATE HDMI/DVI IN OPTICAL TV-LINK CFG DIGITAL AUDIO VIDEO MONO SPEAKER AUDIO OUT AV IN 2 REMOTE RGB IN (PC) AUDIO IN RS-232C IN CONTROL (RGB/DVI) (SERVICE ONLY) INTERFACE 47/55LD650H AC IN...
  • Page 14 Enables/disables software downloads and debug mode. RJP INTERFACE (REMOTE JACK PACK PORT) TV - LINK CFG Connect this to an LG remote jack pack system. Computer input for programming Free To Guest ser- ANTENNA IN vices.

  • Page 15: Stand Instructions

    STAND INSTRUCTIONS Image shown may differ from your TV. 32/37/42LG710H INSTALLATION DETACHMENT Carefully place the TV screen side down on a Carefully place the TV screen side down on a cushioned surface to protect the screen from cushioned surface to protect the screen from damage.
  • Page 16 PREPARATION 32/37/42/47/55LD650H, 32/37/42LD655H INSTALLATION DETACHMENT Carefully place the TV screen side down on a Carefully place the TV screen side down on a cushioned surface to protect the screen from cushioned surface to protect the screen from damage. damage. Assemble the parts of the S S T T A A N N D D B B O O D D Y Y with the S S T T A A N N D D B B A A S S E E of the TV.

  • Page 17: Cable Management

    CABLE MANAGEMENT Image shown may differ from your TV. 32/37/42LG710H Connect the cables as necessary. Put the cables inside the CABLE MANAGEMENT CLIP and snap it closed. To connect additional equipment, see the EXTERNAL EQUIPMENT SETUP section. To help prevent the power cable from being removed by accident, secure the power cable with the included P P ROTECTIVE BRACKET /SCREW.
  • Page 18 PREPARATION 32/37/42/47/55LD650H, 32/37/42LD655H Connect the cables as necessary. Put the cables inside the CABLE MANAGEMENT CLIP and snap it closed. To connect additional equipment, see the EXTERNAL EQUIPMENT SETUP section. To help prevent the power cable from being removed by accident, secure the power cable with the included P P ROTECTIVE BRACKET AC IN /SCREW.

  • Page 19: Desktop Pedestal Installation

    PREPARATION DESKTOP PEDESTAL INSTALLATION Image shown may differ from your TV. For proper ventilation, allow a clearance of 4 inches on all four sides from the wall. 4 inches 4 inches 4 inches 4 inches CAUTION Ensure adequate ventilation by following the clearance recommendations. Do not mount near or above any type of heat source.

  • Page 20: Attaching The Tv To A Desk

    PREPARATION ATTACHING THE TV TO A DESK The TV should be attached to a desk so it cannot be pulled in a forward/backward direction, potentially causing injury or damaging the product. 32/37/42LG710H Stand 4-Screws Desk (not provided as parts of the product) Recommended screw size: M5 x L ( *L: Table depth + 8 ~ 10mm ) ex) Table depth: 15mm, Screw: M5 x 25 32/37/42LD650H, 32/37/42LD655H...

  • Page 21: Vesa Wall Mounting

    If installed on a ceiling or slanted wall, it may fall and result in severe personal injury. We recommend that you use an LG brand wall mount when mounting the TV to a wall. LG recommends that wall mounting be performed by a qualified professional installer.
  • Page 22 Do not use fasten the screws too strongly, this may damage the TV or cause the TV to a fall, leading to When purchasing our wall mount kit, a detailed personal injury. LG is not liable for these kinds of installation manual and all parts necessary for accidents.

  • Page 23: Securing The Tv To The Wall To Prevent Falling When The Tv Is Used On A Stand

    SECURING THE TV TO THE WALL TO PREVENT FALLING WHEN THE TV IS USED ON A STAND You should purchase necessary components to prevent the TV from tipping over (when not using a wall mount). Image shown may differ from your TV. We recommend that you set up the TV close to a wall so it cannot fall over if pushed backwards.

  • Page 24: Antenna Or Cable Connection

    PREPARATION PREPARATION To prevent damage, do not connect to the power outlet until all connections are made between the devices. ANTENNA OR CABLE CONNECTION 1. Antenna (Analog or Digital) This image refers to using a Wall Antenna Socket or Outdoor Antenna without a Cable Box Connection.

  • Page 25: Mpi Card Slot / Ppv Card Installation

    MPI CARD SLOT / PPV CARD INSTALLATION (Except 47/55LD650H) The MPI card is equipped with an RF jack for antenna/cable signal source connection. This card can be removed and replaced with a third-party PPV (Pay-Per-View) card. MPI Card Removal / PPV Card Installation 1.

  • Page 26: External Equipment Setup

    EXTERNAL EQUIPMENT SETUP To prevent the equipment damage, never plug in any power cords until you have finished connecting all equipment. Image shown may differ from your TV. HD RECEIVER SETUP This TV can receive Digital Over-the-air or Digital Cable signals without an external digital set-top box. However, if you do receive digital signals from a digital set-top box or other digital external device, refer to the figure as shown below.
  • Page 27 HDMI Connection HDMI/DVI IN HDMI/DVI IN 1. How to connect Connect the digital set-top box to H H D D M M I I / / D D V V I I I I N N 1 1 ( ( D D V V I I ) ) or 2 2 jack on the TV. 1(DVI) 1(DVI) No separate audio connection is necessary.
  • Page 28 EXTERNAL EQUIPMENT SETUP EXTERNAL EQUIPMENT SETUP DVI to HDMI Connection 1. How to connect TV-LINK Connect the DVI output of the digital set-top box to the H H D D M M I I / / D D V V I I I I N N 1 1 ( ( D D V V I I ) ) jack on the TV. HDMI/DVI IN (SERVICE ONLY) RESET...

  • Page 29: Dvd Setup

    DVD SETUP Component Connection 1. How to connect Connect the video outputs ( Y, P ) of the DVD to the C C O O M M P P O O N N E E N N T T I I N N V V I I D D E E O O jacks on the TV. TV-LINK Match the jack colors ( Y = green, P = red ) .

  • Page 30: Vcr Setup

    EXTERNAL EQUIPMENT SETUP EXTERNAL EQUIPMENT SETUP VCR SETUP To avoid picture noise ( interference ) , leave an adequate distance between the VCR and TV. Antenna Connection 1. How to connect Connect the RF antenna out socket of the ANTENNA IN ANTENNA IN M.P.I.

  • Page 31: Other A/V Source Setup

    OTHER A/V SOURCE SETUP Camcorder 1. How to connect Video Game Set Connect the A A U U D D I I O O /V V I I D D E E O O jacks between TV and external equipment. Match the jack colors.

  • Page 32: Pc Setup

    EXTERNAL EQUIPMENT SETUP PC SETUP This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's settings. RESET UPDATE VGA (D-Sub 15 pin) Connection RS-232C IN (SERVICE ONLY AUDIO RGB(PC) (RGB/DVI) 1. How to connect Connect the VGA output of the PC to the R R G G B B ( ( P P C C ) ) VIDEO AUDIO...
  • Page 33 NOTES be a noise on the screen. To get the best picture quality, adjust the PC graph- ics card to 1 1 3 3 6 6 0 0 x x 7 7 6 6 8 8 (32/37/42LG710H, Avoid keeping a fixed image on the screen for a 32LD650H, 32LD655H) or 1 1 9 9 2 2 0 0 x x 1 1 0 0 8 8 0 0...

  • Page 34: Screen Setup For Pc Mode

    EXTERNAL EQUIPMENT SETUP Screen Setup for PC mode Selecting Resolution When using RGB-PC input, change the resolution in the menus to match the PC’s. The P P o o s s i i t t i i o o n n , P P h h a a s s e e , and S S i i z z e e can also be adjusted. SCREEN PICTURE Move...
  • Page 35 Auto Configure Automatically adjusts picture position and minimizes image instability. After adjustment, if the image is still not correct, try using the manual settings or a different resolution or refresh rate on the PC. SCREEN Move Prev. PICTURE Move Enter Resolution •...
  • Page 36 EXTERNAL EQUIPMENT SETUP Adjustment for screen Position, Size, and Phase If the picture is not clear after auto adjustment and especially if characters are still trembling, adjust the picture phase manually. This feature operates only in RGB-PC mode. SCREEN PICTURE Move Prev.
  • Page 37 Screen Reset (Reset to original factory values) Returns P P o o s s i i t t i i o o n n , S S i i z z e e , and P P h h a a s s e e to the default factory settings. This feature operates only in RGB-PC mode.

  • Page 38: Watching Tv / Channel Control

    WATCHING TV / CHANNEL CONTROL REMOTE CONTROL FUNCTIONS When using the remote control, aim it at the remote control sensor on the TV. POWER Turns your TV or any other programmed equipment on POWER or off, depending on mode. Selects the remote’s operating mode: TV, STB, DVD, or INFO GUIDE PORTAL...

  • Page 39: Installing Batteries

    THUMBSTICK Navigates the on-screen menus and adjusts the system settings to your preference. (Up/Down/Left Right/ENTER) RETURN Clears all on-screen displays and returns to TV viewing from any menu. Displays the main menu. MENU INPUT Rotates through inputs. Also switches the TV on from standby. Adjusts the volume.

  • Page 40: Turning On The Tv

    WATCHING TV / CHANNEL CONTROL WATCHING TV / CHANNEL CONTROL TURNING ON THE TV First, connect the power cord correctly. At this moment, the TV switches to standby mode. In standby mode to turn TV on, press the button on the TV or press P P O O W W E E R R button on the remote control.

  • Page 41: On-Screen Menus Selection

    ON-SCREEN MENUS SELECTION Your TV's OSD (On Screen Display) may differ slightly from that shown in this manual. AUDIO PICTURE CHANNEL Move Enter Move Enter Move Enter Auto Volume : On Aspect Ratio : 16:9 Auto Tuning Clear Voice II : On Picture Mode : Standard Manual Tuning...

  • Page 42: Channel Setup

    WATCHING TV / CHANNEL CONTROL CHANNEL SETUP Auto Scan (Auto Tuning) Automatically finds all channels available through antenna or cable inputs and stores them in memory on the channel list. Run Auto Tuning again after any Antenna/Cable connection changes. CHANNEL CHANNEL Move Enter...

  • Page 43: Add/Delete Channel (Manual Tuning)

    Add/Delete Channel (Manual Tuning) If selecting DIGITAL input signal, you can view the on-screen signal strength monitor to see the quality of the signal being received. CHANNEL CHANNEL Move Enter Move Enter Auto Tuning Auto Tuning DIGITAL Manual Tuning Manual Tuning Channel Edit Channel Edit Select channel type and...

  • Page 44: Channel Editing

    WATCHING TV / CHANNEL CONTROL Channel Editing The channels in the Channel Edit List are displayed in black and the channels deleted from the Channel Edit List are displayed in blue. When a channel number is deleted, it means that you will be unable to select it using C C H H button during TV viewing.

  • Page 45: Input List

    INPUT LIST Component RGB-PC INPUT ENTER Select the desired input source. HDMI2 HDMI1 RGB-PC Component T T V V : Select it to watch over-the-air, cable and digital cable broadcasts. A A V V 1 1 - - 2 2 : Select them to watch a VCR or other external equipment.

  • Page 46: Example Electronic Program Guide

    WATCHING TV / CHANNEL CONTROL EXAMPLE ELECTRONIC PROGRAM GUIDE This is an example of a typical TV electronic program guide showing available programming. CHANNEL INDICATOR PROGRAMMING GRID Currently tuned channel Program listings arranged in and program. time slots TV PROGRAM Current program on select- DATE/TIME OSD ed channel.

  • Page 47: Usb

    Image shown may differ from your TV. ENTRY MODES When you connect a USB device, this pop-up menu is displayed automatically. When the Pop-Up menu does not appear, you can select Photo List or Music List on Extra contents. On a USB device, you can not add a new folder or delete an existing folder. Connect the USB device to the U U S S B B I I N N jack on the side of TV.
  • Page 48 Precautions with USB devices. Only a USB storage device is recognizable. If the USB storage device is connected through a USB hub, the device is not recognizable. A USB storage device using an automatic recognition program may not be recognized. A USB storage device which uses its own driver may not be recognized.

  • Page 49: Photo List

    PHOTO LIST This TV only supports picture in JPEG(.jpg) format. The On-Screen Display on your model may be slightly different. Supported photo file: * .JPG • You can view JPG files only. • Only baseline scan is supported among JPG. •...
  • Page 50 Photo Selection and Pop-up Menu Photo List Page 2/3 No Marked Drive1 Up Folder KY103 03/30/2008 JMJ001 KY101 KY104 06/10/2008 06/19/2008 KY102 KY105 04/03/2008 01/31/2008 JMJ001 JMJ005 01/01/2000 05/13/2008 JMJ002 JMJ006 06/15/2008 05/26/2008 1366 768, 125KB JMJ003 JMJ007 04/03/2008 02/18/2008 Up Folder JMJ004 JMJ008...

  • Page 51: Screen Mode

    Full Screen Menu You can change the Photo List view so that it fills the screen. More operations are available in full screen mode. Photo List Page 2/3 No Marked Drive1 Up Folder KY103 03/30/2008 JMJ001 KY101 KY104 06/10/2008 06/19/2008 KY102 KY105 04/03/2008...
  • Page 52 Select the S S l l i i d d e e s s h h o o w w , B B G G M M , ENTER ( ( R R o o t t a a t t e e ) ) , D D e e l l e e t t e e , O O p p t t i i o o n n , or H H i i d d e e .

  • Page 53: Music List

    MUSIC LIST You can use the Music List menu to play MP3 files from a USB storage device. This TV cannot play back copy-protected files. The On-Screen Display on your model may be slightly different. Supported music file: * .MP3 Bit rate range 32 Kbps - 320 Kbps •...
  • Page 54 Music Selection and Pop-up Menu P P l l a a y y (During stop): Play the selected file. Once a song finishes playing, the next selected one will be played. When there are no selected Music List No Marked Page 2/3 files to play, the next one in the current folder Drive1...

  • Page 55: Extra Contents

    The play information box (as shown below) will automatically move across the screen when there is no user input to pre- vent a fixed image remaining on the screen for a extended period of time. NOTE When music is playing, is displayed in front of the music play time.

  • Page 56: Picture Control

    PICTURE CONTROL PIP (PICTURE-IN-PICTURE) PIP enables the end user to view two sources on the screen at the same time. The end user can switch between the Main and Sub picture sizes. PIP Operation 1. Connect auxiliary source(s) to TV connections panel.
  • Page 57 Main Picture Source Available Sub Picture Sources AV1, AV2, HDMI1, HDMI2 TV, AV1or AV2, HDMI1, HDMI2 AV1or AV2 TV, AV1, AV2, HDMI1or HDMI2 HDMI1or HDMI2 TV, AV1, AV2, HDMI1, HDMI2 Component, RGB-PC...

  • Page 58: Picture Size (Aspect Ratio) Control

    PICTURE CONTROL PICTURE SIZE (ASPECT RATIO) CONTROL This feature lets you choose the way an analog picture with a 4:3 aspect ratio is displayed on your TV. RGB-PC input source can only use 4:3 or 16:9 aspect ratio. 1 1 6 6 : : 9 9 Press the R R A A T T I I O O button repeatedly to select the picture options RATIO S S e e t t B B y y P P r r o o g g r r a a m m , , 4 4 : : 3 3 , ,...
  • Page 59 Set by program 16:9 Selects the proper picture proportion to match Adjust the picture horizontally, in a linear pro- the source’s image. portion to fill the entire screen. (4:3 4:3) Set By Program (16:9 16:9) Set By Program Choose 4:3 when you want to view a picture with an original 4:3 aspect ratio.
  • Page 60 PICTURE CONTROL Zoom Choose Zoom when you want to view the picture without any alteration. However, the top and bottom portions of the picture will be cropped. Just Scan Normally the edges of video signals are cropped 1-2%. Just Scan turns off this cropping and shows the complete video.

  • Page 61: Preset Picture Settings (Picture Mode)

    PRESET PICTURE SETTINGS (PICTURE MODE) There are factory presets for picture settings available in the user menus. You can use a preset, change each setting manually, , or use the Intelligent Sensor. PICTURE Move Enter PICTURE Move Enter Aspect Ratio : 16:9 Aspect Ratio : 16:9 Picture Mode : Standard Picture Mode : Standard...

  • Page 62: Manual Picture Adjustment - User Mode

    PICTURE CONTROL MANUAL PICTURE ADJUSTMENT - USER MODE Adjust the picture appearance to suit your preference and viewing situations. This feature is disable in “P P i i c c t t u u r r e e M M o o d d e e - - I I n n t t e e l l l l i i g g e e n n t t S S e e n n s s o o r r ”. PICTURE Move Enter...

  • Page 63: Picture Improvement Technology

    PICTURE IMPROVEMENT TECHNOLOGY You can calibrate the screen for each Picture Mode or set the video value according to the special video screen. You can set the video seeing differently for each input. To reset to the factory default after making adjustments to each input source, execute the P P i i c c t t u u r r e e R R e e s s e e t t function for each Picture Mode.
  • Page 64 PICTURE CONTROL Set to warm to enhance hotter colors such as red, or set to cool to enhance cooler Color Temperature colors such as blue. Adjusts the contrast to keep it at the best level according to the brightness of the Dynamic Contrast screen.

  • Page 65: Picture Reset

    PICTURE RESET Settings of the selected picture modes return to the default factory settings. PICTURE PICTURE Move Enter Move Enter • Backlight • Backlight • Contrast • Contrast All picture settings will be resetted. • Brightness • Brightness Continue? • Sharpness •...

  • Page 66: Demo Mode

    PICTURE CONTROL DEMO MODE Displays a slide show to explain the various feature of this TV. OPTION OPTION Move Enter Move Enter Menu Language : English Menu Language : English Audio Language : English Audio Language : English Caption : Off Caption : Off Set ID...

  • Page 67: Sound & Language Control

    SOUND & LANGUAGE CONTROL AUTO VOLUME LEVELER (AUTO VOLUME) Auto Volume makes sure that the volume level remains consistent whether you are watching a commercial or a regular TV program. Because each broadcasting station has its own signal conditions, volume adjustment may be needed every time the channel is changed.

  • Page 68: Preset Sound Settings (Sound Mode)

    SOUND &LANGUAGE CONTROL SOUND &LANGUAGE CONTROL PRESET SOUND SETTINGS (SOUND MODE) Sound Mode lets you enjoy the best sound without any special adjustment as the TV sets the appropriate sound options based on the program content. AUDIO AUDIO Move Enter Move Enter Auto Volume...

  • Page 69: Sound Setting Adjustment - User Mode

    SOUND SETTING ADJUSTMENT - USER MODE Adjust the sound to suit your taste and room situations. AUDIO AUDIO Move Enter Move Enter Auto Volume : Off Auto Volume : Off Clear Voice II : Off Clear Voice II : Off •...

  • Page 70: Srs Trusurround Xt

    Return to the previous menu. I I n n f f i i n n i i t t e e S S o o u u n n d d : Infinite Sound is a patented LG proprietary sound process- MENU ing technology that strives immersive 5.1...

  • Page 71: Clear Voice Ll

    CLEAR VOICE II By differentiating the human sound range from others, it improves the sound quality of voices. AUDIO AUDIO Move Enter Move Enter Auto Volume : Off Auto Volume : Off Clear Voice II : On Clear Voice II : On •...

  • Page 72: Balance

    SOUND &LANGUAGE CONTROL BALANCE Adjust the left/right sound of speaker to suit your taste and room situations. AUDIO AUDIO Move Enter Move Enter Auto Volume : Off Auto Volume : Off Clear Voice II : Off Clear Voice II : Off •...

  • Page 73: Tv Speakers On/Off Setup

    TV SPEAKERS ON/OFF SETUP If you wish to use an external Hi-Fi system or a SRS System, turn off the TV’s internal speakers. In A A V V , C C o o m m p p o o n n e e n n t t , R R G G B B and H H D D M M I I with HDMI to DVI cable, the TV speaker can be operational even when there is no video signal.

  • Page 74: Audio Reset

    SOUND &LANGUAGE CONTROL AUDIO RESET Settings of the selected Sound Mode return to the default factory settings. AUDIO AUDIO Move Move Enter Enter • Level • Level Balance Balance Sound Mode : Standard Sound Mode : Standard • SRS TruSurround XT: Off •...

  • Page 75: Stereo/Sap Broadcast Setup

    STEREO/SAP BROADCAST SETUP For Analog only: This TV can receive MTS stereo programs and any SAP (Secondary Audio Program) that accom- panies the stereo program if the station transmits an additional sound signal. Mono sound is automatically used if the broadcast is only in Mono. If other languages are available on the digital signal,select them with the S S A A P P button.

  • Page 76: Audio Language

    SOUND &LANGUAGE CONTROL AUDIO LANGUAGE Other languages may be available if a digital signal is provided by the broadcasting station. This feature operates only in DTV mode. OPTION OPTION Move Enter Move Enter Menu Language : English Menu Language : English Audio Language : English Audio Language...

  • Page 77: On-Screen Menus Language Selection

    ON-SCREEN MENUS LANGUAGE SELECTION The menus can be shown on the screen in the selected language. OPTION OPTION Move Enter Move Enter Menu Language : English Menu Language : English English Audio Language : English Audio Language : English Español Caption : Off Caption...

  • Page 78: Caption Mode

    SOUND &LANGUAGE CONTROL CAPTION MODE Analog Broadcasting System Captions Captions are provided to help the hearing impaired watch TV. Select a caption mode for displaying captioning information if provided on a program. Analog caption displays information at any position on the screen and is usually the program's dialog.

  • Page 79: Digital Broadcasting System Captions

    Digital Broadcasting System Captions Choose the language you want the DTV/CADTV Captions to appear in. Other Languages can be chosen for digital sources only if they are included on the program. This function in only available when Caption Mode is set On. OPTION OPTION Move...

  • Page 80: Caption Option

    SOUND &LANGUAGE CONTROL Caption Option Customize the DTV captions that appear on your screen. This function in only available when Caption Mode is set On. OPTION Move Enter Custom OPTION Move Enter Size A Standard Menu Language : English Menu Language : English Audio Language : English...

  • Page 81: Time Setting

    TIME SETTING CLOCK SETTING Auto Clock Setup The time is set automatically from a digital channel signal. The digital channel signal includes information for the current time provided by the broadcasting station. Set the clock manually if the current time is set incorrectly by the auto clock function. TIME TIME Move...

  • Page 82: Manual Clock Setup

    TIME SETTING TIME SETTING Manual Clock Setup If the current time setting is wrong, reset the clock manually. TIME TIME Move Enter Move Enter Manual Clock Clock Off Time : Off Off Time : Off Month On Time : Off On Time : Off Date...

  • Page 83: Auto On/Off Time Setting

    AUTO ON/OFF TIME SETTING This function operates only if the current time has been set. O O f f f f T T i i m m e e function overrides the O O n n T T i i m m e e function if they are both set to the same time. The TV must be in standby mode for the O O n n T T i i m m e e to work.

  • Page 84: Sleep Timer Setting

    TIME SETTING TIME SETTING SLEEP TIMER SETTING The Sleep Timer turns the TV off at the preset time. Note that this setting is cleared when the TV is turned off. TIME TIME Move Enter Move Enter Clock Clock Off Time : Off Off Time : Off...

  • Page 85: Parental Control / Ratings

    PARENTAL CONTROL / RATINGS Parental Control can be used to block specific channels, ratings and other viewing sources. The Parental Control Function (V-Chip) is used to block program viewing based on the ratings sent by the broad- casting station. The default setting is to allow all programs to be viewed. Viewing can be blocked by choosing the type of the program and the categories.

  • Page 86: Lock System

    PARENTAL CONTROL /RATINGS Lock System Enables or disables the blocking scheme you set up previously. LOCK LOCK Move Enter Move Enter Lock System : Off Lock System : On Set Password Set Password Block Channel Block Channel Movie Rating Movie Rating TV Rating-Children TV Rating-Children TV Rating-General...

  • Page 87: Set Password

    Set Password Set up blocking schemes to block specific channels, ratings, and external viewing sources. A password is required to gain access to this menu. LOCK LOCK Move Enter Move Enter Lock System : Off Lock System : Off Set Password Set Password Block Channel Block Channel...

  • Page 88: Channel Blocking

    PARENTAL CONTROL /RATINGS CHANNEL BLOCKING Blocks any channels that you do not want to watch or that you do not want your children to watch. LOCK Move Enter Lock System : Off Set Password Block Channel Movie Rating TV Rating-Children TV Rating-General Downloadable Rating Input Block...

  • Page 89: Movie & Tv Rating

    MOVIE & TV RATING Movie Rating (MPAA) - For USA Blocks movies according to the movie ratings limits specified, so children cannot view certain movies. You can set the ratings limit by blocking out all the movies with the ratings above a specified level. Keep in mind that the movie ratings limit only applies to movies shown on TV, not TV programs, such as soap operas.
  • Page 90 PARENTAL CONTROL /RATINGS TV Rating Children - For USA Prevents children from watching certain children's TV programs, according to the ratings limit set. The children rating does not apply to other TV programs. Unless you block certain TV programs intended for mature audi- ences in the TV Rating - sub menu, your children can view those programs.
  • Page 91 TV Rating General - For USA Based on the ratings, blocks certain TV programs that you and your family do not want to view. LOCK LOCK Move Enter Move Enter Lock System : Off Lock System : Off Set Password Set Password Block Channel Block Channel...
  • Page 92 PARENTAL CONTROL /RATINGS TV Rating English - For CANADA Selecting Canadian English rating system. LOCK LOCK Blocking off : Permits all programs Move Enter Move Enter Lock System : Off Lock System : Off Set Password Set Password Block Channel Block Channel TV Rating-English TV Rating-English...
  • Page 93 TV Rating French - For CANADA Selecting Canadian French rating system. LOCK LOCK Move Enter Move Enter Blocking off : Permits all programs Lock System : Off Lock System : Off Set Password Set Password Block Channel Block Channel 8ans+ TV Rating-English TV Rating-English 13ans+...

  • Page 94: Downloadable Rating

    PARENTAL CONTROL /RATINGS DOWNLOADABLE RATING This function is available only for digital channels. This function operates only when TV has received Region5 Rating data. LOCK LOCK Move Enter Move Enter Lock System : Off Lock System : Off Set Password Set Password Humor Humor...

  • Page 95: External Input Blocking

    EXTERNAL INPUT BLOCKING Enables you to block an input. LOCK LOCK Move Enter Move Enter Lock System : Off Lock System : Off Set Password Set Password Block Channel Block Channel Component Movie Rating Movie Rating TV Rating-Children TV Rating-Children RGB-PC TV Rating-General TV Rating-General...

  • Page 96: Appendix

    APPENDIX TROUBLESHOOTING A A b b n n o o r r m m a a l l O O p p e e r r a a t t i i o o n n Check to see if there is any object between the product and the remote control causing obstruction.
  • Page 97 A A u u d d i i o o P P r r o o b b l l e e m m s s Press the VOL or VOLUME button. Sound muted? Press the MUTE button. Picture OK but No sound Try another channel.

  • Page 98: Maintenance

    APPENDIX MAINTENANCE Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you can enjoy your new TV. Caution: Be sure to turn the power off and unplug the power cord before you begin any cleaning. Cleaning the Screen Here’s a great way to keep the dust off your screen for a while.

  • Page 99: Product Specifications

    PRODUCT SPECIFICATIONS 32LG710H 37LG710H 42LG710H MODELS (42LG710H-UA) (32LG710H-UA) (37LG710H-UA) 797 x 597 x 232.5 mm 918.6 x 684.8 x 293.4 mm 1026.2 x 734.1 x 293.4 mm Dimensions With stand 31.3 x 23.5 x 9.15 inch 36.1 x 26.9 x 1 1.5 inch 40.4 x 28.9 x 1 1.5 inch...
  • Page 100 APPENDIX 37LD650H (37LD650H-UA) 32LD650H (32LD650H-UA) MODELS 37LD655H (37LD655H-UA) 32LD655H (32LD655H-UA) 797.0 mm x 557.7 mm x 207 .0 mm 916.0 mm x 626.0 mm x 261.0 mm With stand Dimensions (31.3 inch x 21.9 inch x 8.1 inch) (36.0 inch x 24.6 inch x 10.2 inch) (Width x Height x Depth) 797 .0 x 495.0 x 97 .1 mm...

  • Page 101: Programming The Remote Control

    PROGRAMMING THE REMOTE CONTROL The provided universal remote control can be programmed to operate most remote-controllable devices. Note that the remote may not control all models of other brands. Programming a code into a remote mode Testing your remote control. To find out whether your remote control can operate other components without programming, turn on a component such as a STB(Set-Top Box) and press the corresponding mode button (such as a S S T T B B ) on the remote control, while pointing at the component.
  • Page 102 145 147 VIDEOSONIC REALISTIC 003 008 010 014 047 048 WARDS 003 013 017 024 LG (GOLDSTAR) 001 012 013 020 031 033 034 040 031 033 034 040 101 106 1 14 123 053 054 101 053 054 131...
  • Page 103 HDSTB Brand Codes Brand Codes Brand Codes ALPHASTAR DSR 123 HUGHES SATELLITE SERVICE CO 028 035 047 057 AMPLICA HUMAX(SL) ASTRO PHILIPS(ML) 1 59 JANIEL 060 147 SCIENTIFIC ATLANTA 032 138 ASTR O THOMPSON(ML) 1 60 JERROLD SKY LIFE ASTRO NOKIA(ML) 1 61 KATHREIN SONY...

  • Page 104: Ir Codes

    APPENDIX IR CODES 1. How to Connect Connect your wired remote control to the Remote Control port on the TV. 2. Remote Control IR Codes Output waveform Single pulse, modulated with 37 .917KHz signal at 455KHz Carrier frequency FCAR = 1/TC = fOSC/12 Duty ratio = T1/TC = 1/3 Configuration of frame 1st frame...
  • Page 105 Code Code Function Note Function Note (Hexa) (Hexa) Discrete IR Code POWER Remote control Button (Power On/Off) (TV Input Selection) Remote control Button Discrete IR Code INPUT Remote control Button (AV1 Input Selection) Remote control Button Discrete IR Code RATIO Remote control Button (AV2 Input Selection) GUIDE...

  • Page 106: Open Source License

    APPENDIX OPEN SOURCE LICENSE GNU GENERAL PUBLIC LICENSE Version 2, June 1991 Copyright (C) 1989, 1991 Free Software Foundation, Inc., 51 the program proprietary. To prevent this, we have made it clear Franklin Street, Fifth Floor, Boston, MA 021 10-1301 USA that any patent must be licensed for everyone's free use or not licensed at all.
  • Page 107 b) You must cause any work that you distribute or publish, c) Accompany it with the information you received as to the that in whole or in part contains or is derived from the offer to distribute corresponding source code. (This alter- Program or any part there of, to be licensed as a whole at native is allowed only for noncommercial distribution and only if you received the program in object code or exe-...
  • Page 108 APPENDIX 7 . If, as a consequence of a court judgment or allegation of any later version published by the Free Software Foundation. patent infringement or for any other reason (not limited to If the program does not specify a version number of this patent issues), conditions are imposed on you (whether by license, you may choose any version ever published by the Free Software Foundation.
  • Page 109 END OF TERMS AND CONDITIONS Also add information on how to contact you by electronic and paper mail. How to apply these terms to your new programs If the program is interactive, make it output a short notice like If you develop a new program, and you want it to be of the great- this when it starts in an interactive mode: est possible use to the public, the best way to achieve this is to Gnomovision version 69, Copyright (C) year name of author...

  • Page 110: Gnu Lesser General Public License

    APPENDIX GNU LESSER GENERAL PUBLIC LICENSE Version 2.1, February 1999 Copyright (C) 1991, 1999 Free Software Foundation, Inc. 51 To protect each distributor, we want to make it very clear that Franklin Street, Fifth Floor, Boston, MA 021 10-1301 there is no warranty for the free library. Also, if the library is mod- Everyone is permitted to copy and distribute verbatim copies of ified by someone else and passed on, the recipients should know this license document, but changing it is not allowed.
  • Page 111 Although the Lesser General Public License is Less protective of each copy an appropriate copyright notice and disclaimer of the users' freedom, it does ensure that the user of a program that warranty; keep intact all the notices that refer to this license is linked with the Library has the freedom and the wherewithal to and to the absence of any warranty;...
  • Page 112 APPENDIX 3. You may opt to apply the terms of the ordinary GNU General the object file is unrestricted, regardless of whether it is legal- Public License instead of this License to a given copy of the ly a derivative work. (Executable containing this object code Library.
  • Page 113 For an executable, the required form of the "work that uses of the rights granted herein. the library" must include any data and utility programs need- You are not responsible for enforcing compliance by third ed for reproducing the executable from it. However, as a spe- parties with this license.
  • Page 114 APPENDIX If the library does not specify a license version number, you To apply these terms, attach the following notices to the library. may choose any version ever published by the Free Software It is safest to attach them to the start of each source file to most Foundation.
  • Page 115 MOZILLA PUBLIC LICENSE Version 1.1 --------------- 1.Definitions. code which is described in the source code notice required by exhibit as original code, and which, at the time 1.0.1. “Commercial use” means distribution or otherwise making of its release under this license is not already covered the covered code available to a third party.
  • Page 116 APPENDIX (c) the licenses granted in this section 2.1(a) and (b) are You may not offer or impose any terms on any source code effective on the date Initial developer first distributes version that alters or restricts the applicable version of original code under the terms of this license.
  • Page 117 3.7 . Larger works. (c) Representations. contributor represents that, except as disclosed pursuant You may create a larger work by combining covered code to section 3.4(a) above, contributor believes that contributor's with other code not governed by the terms of this license modifications are contributor's original creation(s) and distribute the larger work as a single product.
  • Page 118 APPENDIX 7 . DISCLAIMER OF WARRANTY. such participant under sections 2.1(b) and 2.2(b) are COVERED CODE IS PROVIDED UNDER THIS LICENSE revoked effective as of the date you first made, used, ON AN “AS IS” BASIS, WITHOUT WARRANTY OF ANY sold, distributed, or had made, modifications made by that participant.
  • Page 119 1 1. MISCELLANEOUS. EXHIBIT A -Mozilla Public License. This license represents the complete agreement concerning subject matter hereof. If any provision of this license is The contents of this file are subject to the Mozilla Public License Version 1.1 (the “license”); you may not use this file except in held to be unenforceable, such provision shall be reformed only to the extent necessary to make it enforceable.
  • Page 120 28 – 33 b -LAN™ Setup & Overview page 40 Pro:Idiom is a registered trademark of Zenith Electronics LLC. Pro:Centric is a trademark of LG Electronics b -LAN is a trademark of U.S.A., Inc. LodgeNet Interactive Corporation. All other trademarks or registered trademarks are the property of their respective owners.
  • Page 121 • Consult the dealer or an experienced radio/TV technician for help. CAUTION: Do not attempt to modify this product in any way without written authorization from LG Electronics U.S.A., Inc. Unauthorized modification could void the user’s authority to operate this product.
  • Page 122 IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 15. Never touch this apparatus or antenna during a thun- der or lighting storm. 2. Keep these instructions. 16. When mounting a TV on the wall, make sure not to 3. Heed all warnings. install the TV by the hanging power and signal cables 4.
  • Page 123 IMPORTANT SAFETY INSTRUCTIONS 24. Cleaning (Continued from previous page) When cleaning, unplug the power cord and rub gently 21. Grounding with a soft cloth to prevent scratching. Do not spray Ensure that you connect the earth ground wire to pre- water or other liquids directly on the TV as electric vent possible electric shock (i.e., a TV with a three- shock may occur.
  • Page 124 Table of Contents Safety Warnings ....... 2 Learning / Teaching a Master TV Setup using a TLL-1100A Clone Programmer .

  • Page 125: Setup Checklist / Overview

    Setup Checklist / Overview Setup Checklist Installation and Setup Checklist Commercial Mode Setup __ Unpack TV and all accessories. __ Complete Commercial Mode Setup (configure __ Install batteries in remote control. all relevant Installer Menu items as required of __ Install TV on VESA mount or stand. your institution and configure display features Note: It may be advisable to make all cable for the end user).

  • Page 126: Pro:centric Tv Interactive Menu Features

    Pro:Centric TV Interactive Menu Features Important: Pro:Centric operation requires that Installer Menu item 119 DATA CHANNEL be set appropriately and that the TV be in PPV or FTG Mode. The interactive Pro:Centric TV enables guests—from the comfort of their hotel Channel Guide rooms—to view and select from a complete listing of hotel services and amenities.

  • Page 127: Ld650H/Ld655H Rear Jack Panel

    LD650H/LD655H Rear Jack Panel 32/37/42LD650H/LD655H OPTICAL DIGITAL AUDIO OUT UPDATE Use for amps and home theater systems. Note: In standby mode, this port is Restricted to software updates. not enabled. AUDIO/VIDEO IN 1 RESET Connection for composite audio/video Press RESET to output from external device.

  • Page 128: Lg710H Rear Jack Panel

    LG710H Rear Jack Panel TV-LINK CFG Use for local FTG configuration. UPDATE RESET Restricted to software updates. Press RESET to re-initialize the TV. GAME CONTROL (LodgeNet PPV Mode only) Restricted to service use only. OPTICAL DIGITAL AUDIO OUT Use for amps and home theater RGB IN (PC) systems.

  • Page 129: Side Connections Panel / Rf Antenna Connection

    Side Connections Panel / RF Antenna Connection Side Connections Panel (All LD650H/LD655H/LG710H TVs) USB IN Insert USB device for software updates or for picture/music entertainment, as applicable. A/V 2 Input L/MONO-AUDIO-R IN Connect to audio output jacks on external device. For only mono audio output, connect to Left audio input.

  • Page 130: Installer Overview

    Configuration Utility in the FTG Configuration Application. Pages 16 to 20 describe Installer Menu items in detail. Installer Remote POWER The LG Installer Remote is supplied with and dedicated to operate the GUIDE PORTAL INFO TV. See next page for typical key functions in TV operating mode. Some DVD and VCR controls may be available for selected LG DVD/VCR products.

  • Page 131: Installer Remote Control Typical Key Functions

    Installer Remote Control Typical Key Functions The LG Installer Remote illustrated below and throughout this document shows typical remote control functions and is provided for reference only. This Installer Remote may vary from the Installer Remote supplied with the TV.

  • Page 132: Commercial Mode Setup For Master Tv

    Commercial Mode Setup for Master TV This section describes how to set up a Master TV when the EBL is in Pass-through Mode. Note: Disconnect all Aux inputs. Under certain conditions, Auto Tuning (Channel Search) is disabled if there is an Aux input active. Note: Refer to “FTG Mode of Operation” on pages 24 to 27 for information on configuring/editing Channel Map and Installer Menu settings for an individual TV in FTG Mode.
  • Page 133 Commercial Mode Setup for Master TV (Cont.) (Continued from previous page) 3. Run Auto Tuning (Channel Search). a) Search for all available analog and digital channels: Go to the Channel Menu, select the Auto Tuning option, and follow the CHANNEL Move Enter on-screen instructions.

  • Page 134: Installer Menu

    Installer Menu Use the Installer Menu to set up or change operational settings. Refer to the table starting on the next page for brief descriptions of Installer Menu items. More detailed descriptions follow the table listing. Accessing the Installer Menu Make sure the TV is ON.
  • Page 135 Installer Menu (Cont.) Installer Menu Items 000 through 071 Menu Function Value Range Default Value Brief Description of Function and Comments Item INSTALLER SEQ 0 ~ 3 Leave default set to 0. POWER MANAGE 0 ~ 7 Sets number of hours of no activity before automatic shutoff. AC ON 0 / 1 Set to 1 to enable Auto Turn ON when AC power is applied.
  • Page 136 Installer Menu (Cont.) Installer Menu Items 073 through 119 Menu Function Value Range Default Value Brief Description of Function and Comments Item If set to 1 and Channel Override is 0, “NOT AVAILABLE” message is displayed CH NOT AVBLE 0 / 1 when directly accessing a channel not in the favorite Channel List.
  • Page 137 Installer Menu (Cont.) Detailed Descriptions of Installer Menu Items NOTE: For items 007, 008, and 009 For legacy reasons, the scale used is 0 – 63. The PTC software 000 - INSTALLER SEQUENCE will translate this to the 0 – 100 scale used by the TV. Specifies entry sequence to the Installer Menu.
  • Page 138 Installer Menu (Cont.) 015 - SLEEP TIMER 034 - CAMPORT EN. (Camera Port Enable) If set to 1, the Sleep Timer feature may be used. If set to 0, the Set to 1 to enable Video 2 input on display panel. If set to 0, Video Sleep Timer is not available.
  • Page 139 Installer Menu (Cont.) 070 - FOR. CH-TIME (Channel-Time Display Foreground Color) 084 - PERMANENT BLK (Permanent Block) Set according to Color Chart: Allows Lock (Parental Control) blocking schemes to be permanent by disabling the blocking hours function. Set to 1 to install Paren- 0 = Black 3 = Cyan 6 = Yellow...
  • Page 140 Installer Menu (Cont.) • 6 = Scaler Model RJPs: DVI Mode 103 - ATSC TUNE MODE Enables RJP feature for use with reduced cable bundle models. Sets ATSC tuning mode: Default set to 1 for Physical Channel In this mode, when an HDMI/DVI source is connected to the scan.

  • Page 141: Tv Setup Menus Overview

    TV Setup Menus Overview On-screen setup menus control the features of the TV. Press MENU on the Installer Remote to access the TV setup menus, and set the TV features to the desired configuration for the end user. CHANNEL PICTURE TIME AUDIO LOCK...

  • Page 142: (2-5-4 + Menu Mode)

    Adding Channel Label Icons / Custom Channel Labels (2-5-4 + MENU Mode) Editing/Adding Channel Icons and/or Labels Editing and adding the labels can only be done if there are channels entered into the TV’s Channel Map either during If there is no pre-assigned icon, you can make a custom Commercial Mode Setup (see pages 13 to 14), by cloning, channel label of up to seven (7) characters to help identify or by using some PPV provider’s master remote controls.

  • Page 143: Ftg Mode Of Operation

    FTG Mode of Operation FTG Configuration Overview The following steps outline local FTG configuration of individual TVs. Since these models are equipped with the EBL module, they can also be broadcast configured in FTG Mode by a Free-To-Guest Management Appliance (FMA) head end device.

  • Page 144: Determining The Tv Operating Mode / Ftg Channel Map Configuration Utility Overview

    FTG Mode of Operation (Cont.) Determining the TV Operating Mode / FTG Channel Map Configuration Utility Overview ASPECT RATIO Move Enter To determine the operating mode of the Function Menu TV, press MENU on the Installer Remote. Set By Program Shows that the EBL is in If the end user Function Menu (showing FTG Mode .

  • Page 145: Ftg Channel Map Configuration Utility / Ftg Channel Map Editor Overview

    FTG Mode of Operation (Cont.) FTG Channel Map Configuration Utility / FTG Channel Map Editor Overview The FTG Channel Map Editor shows a single Logical Channel’s Data and the FTG Channel Map. LOGICAL CHANNEL MAPPING CUSTOM CHANNEL LABELS/ICONS SET CHANNEL ATTRIBUTES Select a Logical Channel number, then Enter custom labels and select icons by Check/select Encrypted, OSD, or...

  • Page 146: Ftg Installer Menu Configuration Utility Overview

    FTG Mode of Operation (Cont.) FTG Installer Menu Configuration Utility Overview CONFIGURATION SETTINGS HOSPITAL-GRADE TV ONLY Select tabs for categories of Installer Set Hospital items on Installer Menu Menu items to set up TV. for hospital-grade TVs. INSTALLER DEFAULTS LEARN Click to reset FTG Installer Menu Click to transfer Installer items shown in the FTG Configuration...

  • Page 147: Cloning Overview / Clonable Menu Features

    Cloning Overview / Clonable Menu Features IMPORTANT CLONING INFORMATION Before you begin cloning: There are three options for cloning a Master TV Setup: • Complete the Commercial Mode Setup procedure on • Using a USB memory device pages 13 to 14. • Using a TLL-1100A clone programmer • The Master TV EBL must be in Pass-through Mode.

  • Page 148: Cloning Procedures

    Cloning Procedures Learning / Teaching a Master TV Setup using a USB Memory Device USB Cloning Notes • Read the IMPORTANT CLONING INFORMATION on page 28 before beginning any cloning procedures. • Do not remove the TV power cord or the USB memory device while Learning or Teaching, as doing so may harm the USB memory device.

  • Page 149: Learning / Teaching A Master Tv Setup Using A Tll-1100A Clone Programmer

    Cloning Procedures (Cont.) Learning / Teaching a Master TV Setup using a TLL-1100A Clone Programmer Warning: Do not connect a clone programmer to any PPV card installed in the Master TV or any MPI port while the TV is in PPV Mode, or the clone programmer and the PPV card will be damaged.
  • Page 150 (6) DISPLAY CLONE SETUP Since the TLL-1100A’s time cannot be set directly, the current time needs CLONE CLOCK = XX:XX to be copied from an LG TV equipped with MPI input capability. CLOCK = XX:XX THE CLONE IS VERSION VX.X.X...

  • Page 151: Learning / Teaching A Master Tv Setup Using An Lt2002 Clone Programmer

    Cloning Procedures (Cont.) Learning / Teaching a Master TV Setup using an LT2002 Clone Programmer Warning: Do not connect a clone programmer to any PPV card installed in the Master TV or any MPI port while the TV is in PPV Mode, or the clone programmer and the PPV card will be damaged.
  • Page 152 TO EXECUTE ITEM, PRESS ON/OFF, POWER, OR ENTER. be copied from an LG TV equipped with MPI input capability. After the time is copied to the LT2002 clone programmer, the current time can then be transferred to another TV. (This can be a Master TV or another TV which has already had the features set up.)

  • Page 153: Remote Jack Pack / Tv Connections & Setup

    Remote Jack Pack / TV Connections & Setup Remote Jack Pack Setup RJP Available? If you will use a Remote Jack Pack (RJP) in your system, set Installer Menu item 093 RJP AVAILABLE appropriately (for example, on a legacy model RJP: HDMI Mode, set RJP AVAILABLE to 001).

  • Page 154: Reference: Upgrading Tv/Ptc Software With A Usb Memory Device

    Reference: Upgrading TV/PTC Software with a USB Memory Device Checking the Software Versions XXLG710H PTC INSTALLER MENU You can check the software versions of the TV by accessing the Installer Menu: Press Typical Installer MENU repeatedly until the on-screen menu Menu INSTALLER SEQ locks up, and then press 9-8-7-6 + ENTER.

  • Page 155: Reference: Power Consumption Settings

    Reference: Power Consumption Settings 32/37/42/47/55LD650H, 32/37/42LD655H, 32/37/42LG710H The following tables assume that Installer Menu item 118 POWER SAVINGS is set to 003 (default) and Installer Menu item 099 BACK LIGHTING is set as shown below (default value is 255). Item 099 Back Picture Power Percent Savings...
  • Page 156 9.90 % 85.5 43.56 % 122.5 19.14 % 47.19 % 26.73 % 74.8 50.63 % 101.3 33.14 % 70.8 53.27 % 37LG710H 91.5 39.60 % 44.5 67.5 55.45 % 81.3 46.34 % 63.5 58.09 % 53.14 % 31.5 59.3 60.86 % 63.5...

  • Page 157: Reference: Tv Camport Auto Sense Operation

    Reference: TV Camport Auto Sense Operation The Camport Auto Sense function is enabled when: CAMPORT (Side Video) Functionality Control 1. Installer Menu item 034 CAMPORT EN is set to 1 AND Item 034 Item 040 Side Video 2. Installer Menu item 040 AUTO CAMPORT is enabled (1). CAMPORT EN AUTO CAMPORT Operation...

  • Page 158: Reference: Tv Aux Input Configuration

    Reference: TV Aux Input Configuration ENABLE MPI DATA MPI DATA DATA STATUS DIRECT ACCESS START AUX STATUS TYPE TYPE 0xD2 Tuning DATA STATUS SOURCE Installer Menu 0x41 SOURCES CURRENT AV TYPE 0x0D ASSIGN- ENABLED (R/W) SOURCE (R) MENT SOURCE (R) OLD_ OLD_ Source...

  • Page 159: Reference: B-Lan Setup & Overview

    Reference: b-LAN Setup & Overview The b-LAN module is internal to the TV. It allows the hotel/institution head end equipment to communicate, via the institution’s RF distribution system, with the TV for configuration and control. The b-LAN module also com- prises the data tuner required for Pro:Centric operation.

  • Page 160: Reference: Rjp Model List And Input Auto-Sensing Hierarchy

    Reference: RJP Model List and Input Auto-sensing Hierarchy RJP Model List Legacy Models Scaler Models RJP-101M RJP-101ML RJP-110F RJP-210F RJP-110FW RJP-210FW RJP-110W RJP-210W RJP-110WBR RJP-210WBR RJP-110S RJP-210S RJP-120G RJP-220G RJP-120T RJP-220T RJP-201B RJP-301B RJP-202B RJP-302B RJP Input Auto-sensing Hierarchy Priority Video Audio 1st (Highest)

  • Page 161: Troubleshooting

    Wrong battery polarity. Check that “+” and “-” match in battery compartment. Too much light in room. Dim room light. Wrong Installer Remote. Requires compatible Installer Remote. Contact your LG dealer. Picture Reception Normal picture, Audio muted. Press MUTE or use Volume Up key to increase sound level.

  • Page 162: Troubleshooting Flowchart

    Troubleshooting (Cont.) Troubleshooting Flowchart Controller Quick Check STATUS Plug into AC connected LED on PTC to AC Power outlet. Board Power? blinking? Cycle the power by removing and reconnecting the AC Power cord. Then, observe POWER LED on front of TV. POWER Bad Analog or LED lit?

  • Page 163: Commercial Mode Check / Ftg Operating Troubleshooting

    Troubleshooting (Cont.) Commercial Mode Check / FTG Operation Troubleshooting Commercial Mode Check Press POWER on Installer Remote. responded? Leave the TV set ON. Go to Installer Menu by pressing MENU until the TV stops responding. stopped Stopped TV is in responding or responding Commercial Mode.

  • Page 164: Clone Programmer Troubleshooting

    Then redo Learn/Teach. (Learning usually takes about 90 sec- onds; Teaching usually takes 3 to 4 minutes.) Remote does not operate Wrong Installer Remote. Only use an LG Installer Remote to operate clone programmer clone programmer. with TV. Clone menu does not dis- MPI cord not connected.

  • Page 165: Glossary Of Terms

    Glossary of Terms A list of definitions for some of the words found in this guide. 75 OHM RF CABLE COMPOSITE VIDEO PHYSICAL CHANNEL NUMBER The wire that comes from an off-air Typical video jack, uses one wire for The actual channel number. Analog antenna or cable service provider. The transporting three-color video signals. channels use the Physical Channel end looks like a hex-shaped nut with a number and digital channels can use a...

  • Page 166: Document Revision History / Notes

    Document Revision History / Notes Document Revision History Date Description August 2010 Revision A: New document October 2010 Revision B: Power Savings updates for LD65xH TVs; troubleshooting update Product documentation is available online at: www.LGsolutions.com/products. From the Products page, select TVs, Systems & Solutions, then LCD TVs, then the applicable TV. Click the Literature & Downloads tab at the bottom of the TV page, and select the required document(s) from the Downloads list.
  • Page 167 The model and serial number of the TV is located 1-800-243-0000 USA, Consumer User on the back and/or on one side of the TV. Record these numbers below should you ever need 1-888-865-3026 USA, Commercial User service. 1-888-542-2623 CANADA MODEL LG Customer Information Center SERIAL...
