Summary of Contents for Cardio Theater LCS TX

  • Page 1 EXHIBIT L – User Manual Submitted with original application on 3-6-00 FCC ID M4D1010...
  • Page 2 INSTRUCTION MANUAL LCS TX – 4 Channel Transmitter LCS1 – Single Channel Transmitter Cardio Theater Inc. Service 1-800-776-6695 Sales 1-800-CARDIO-1...

  • Page 3: Table Of Contents

    Introduction CONGRATULATIONS on your choice of this product. Its superior sound reproduction will provide enjoyment and entertainment. We appreciate your patronage and take pride in the quality components our company builds. Please read this manual before you install and operate the system. This manual will acquaint you with operating features and system-connection considerations. Retain this manual for future reference.

  • Page 4: Before You Begin

    Quantity two per receiver POWER ADAPTER (aka: wallbug) Quantity – As ordered POWER CORD (two wireties per Quantity – one wallbug) per transmitter ANTENNA Quantity – one per CSAFE CABLE transmitter Quantity – one per each Cardio Theater Ready piece of equipment.

  • Page 5: Important Safeguards

    Important Safeguards Please read all of the safeguards before operating this unit. Follow all warnings placed on the unit and adhere to the operating and use instructions. Retain this manual for future The unit should be located away from heat sources 7.

  • Page 6: Safety Precautions

    Important Safeguards - Continued - Any component stand should be - The unit should 12. Stands Damage requiring service moved with care. Quick or excessive force be serviced by a qualified technician when: could cause the stand to overturn. The power-supply cord or the plug has been damaged;...

  • Page 7: General Information

    General Information • Group the audio components in a single location to minimize cabling. • If the audio components are stacked in a stereo cabinet, ensure that there is adequate ventilation. LCS-TX (4 channel) • Place the LCS transmitter in a well-ventilated area with the front and back easily accessible. •...

  • Page 8: Controls And Indicators

    Controls and Indicators LCS-TX 4 Channel Transmitter - Front - For setting desired channel to be adjusted. 1. Channel Select - Indicates current channel 2. Channel Indicator – Indicates volume level selected. 3. Volume Indicator - For setting volume level of selected channel. 4.
  • Page 9 Controls and Indicators LCS1 – Single Channel Transmitter - FRONT Channel Channel Volume Volume Level Meter Level Meter For setting desired channel to be adjusted. 1. Channel – For setting audio input levels. 2. Level Meter – Indicates volume level selected. 3.
  • Page 10 Controls and Indicators LCS Receiver Indicates current channel selected. 1. Channel Display - To select the desired listening channel. 2. Channel Select - To select desired listening volume. 3. Volume Adjust - Audio mute. 4. Mute - Standard 3.5mm headphone jack. 5.

  • Page 11: System Connections

    System Connections Transmitters NOTE: MAKE ALL CONNECTIONS TO THE TRANSMITTER AND RECEIVERS WITH POWER OFF. Step 1 Connect the Antenna to the Antenna connector on the back of the LCS-TX – 4 Channel (the LCS1 – Single Channel comes with the antenna already connected). Step 2 Connect up to four (4) pieces of audio equipment to the stereo input jacks on the back of the LCS-TX and one (1) on the LCS1.

  • Page 12: Receiver Configurations

    LCS Receiver with power adapter For cardiovascular equipment that is not Cardio Theater ready, power must be supplied via a power adapter connected to a 110-volt outlet. The power adapter is connected to the LCS Receiver by a telephone connector on the back of the unit.

  • Page 13: Attaching Lcs Receivers

    Attaching LCS Receivers The LCS Receiver can be attached to virtually any piece of equipment. For equipment with round handles or railing, LCS Receivers are supplied with a built-in mounting block. • Align the LCS Receiver on the handle or rail as shown.

  • Page 14: Lcs-Tx - 4 Channel Transmitter Setup

    2 seconds before the unit enters normal operating mode. If the unit does not display this information you have a previous version and you should contact the Cardio Theater Service Center for assistance. Set to U.S. mode: •...

  • Page 15: Lcs1- Single Channel Transmitter Setup

    LCS1- Single Channel Transmitter Setup Programming LCS1 – Single Channel Transmitter Set to U.S. mode: • Press channel down and volume down while powering the unit on – display shows “1776” until released, then displays the software version, then enters normal operation showing the group # on the left side of the display and the channel # on the right.

  • Page 16: Lcs Receiver Setup

    LCS Receiver, power the unit on while holding the channel down and volume down buttons. The display will show “76” until the buttons are released. If the unit does not display this information, you have a previous version and you should contact the Cardio Theater Service Center for assistance. Set to U.S. mode: •...
  • Page 17 LCS Receiver Setup, Continued Example: If you are using a four channel transmitter that is set to group 3*, and an LCS1 single channel transmitter that is set to group 5, channel 2, you would select frequencies 9, 10, 11, 12 & 18. Press volume down after selecting each frequency and volume up to lock the information into memory.

  • Page 18: Specifications

    Specifications LCS-TX – 4 Channel Transmitter Transmission Frequency Range....905 MHz to 925 MHz Frequency Range ........52 channels, adjustable from 905 MHz to 925 MHz. Transmission Power ........95 dbmv max. Transmission Range........150 ft. from antenna Power Consumption ........25 watts max. Audio Inputs ..........
  • Page 19 circuit different from that to which the receiver is connected; 4) consult the dealer or an experienced radio/TV technician for additional suggestions.
  • Page 20 FCC regulations. Note: Cardio Theater follows a policy of continuous advancements in development. For this reason, specifications may be changed without notice. For questions regarding any specifications, please call the Service Center at (800) 776-6695.
