SUB1010FS, 1015FS & 1025SS
Water Pumps
06879, 06881 & 06885
Please read and fully understand the instructions in this manual
before operation. Keep this manual safe for future reference.
1
Advertisement
Table of Contents
Related Manuals for SIP SUB1025SS
Summary of Contents for SIP SUB1025SS
- Page 1 This will allow the recycling of raw materials and help protect the envi- ronment. FOR HELP OR ADVISE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR, OR SIP DIRECTLY ON: TEL: 01509500400 06879, 06881 & 06885 EMAIL: sales@sip-group.com or technical@sip-group.com www.sip-group.com...
-
Page 2: Declaration Of Conformity
Conforms to the requirements of the following directive(s), as indicated. 2006/95/EC Low Voltage Directive 2004/108/EC EMC Directive 2002/95/EC RoHS Directive And the relevant harmonised standard/s, including: EN 55014-1+A2:2011 EN 55014-2:+A2:2008 EN 61000-3-2+A2:2009 EN 61000-3-3:2008 Signed: …………………………………... Mr P. Ippaso - Managing Director - SIP (Industrial Products) Ltd Date: 26/03/2013. -
Page 3: Table Of Contents
NOTES CONTENTS Page No. Description Safety Symbols Used Throughout This Manual Safety Instructions Specified Conditions of Use Electrical Connection Guarantee Technical Specifications Contents & Accessories Getting to Know Your Water pump Operating Instructions Maintenance Instructions Troubleshooting Exploded Drawing - 06879 Sub 1010FS Parts List - 06879 Sub 1010FS Exploded Drawing - 06881 Sub 1015FS Parts List - 06881 Sub 1015FS... -
Page 4: Safety Symbols Used Throughout This Manual
SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL PARTS LIST 06885 SUB1025SS Danger / Caution: Indicates risk of personal injury and/or the possibility of damage. Ref No. Description SIP Code Ref No. Description SIP Code Float switch PW11-00086 Motor lining PW11-00115 Warning: Risk of electrical injury or damage! - Page 5 USE ONLY RECOMMENDED ACCESSORIES: Consult this user manual, your distributor or SIP directly for recommended accessories. Follow the instructions that accompany the accessories. The use of improper accessories may cause hazards and will invalidate any warranty you may have.
-
Page 6: Stator
SAFETY INSTRUCTIONS….cont PARTS LIST When installing, please ensure your SIP submersible pump is disconnected from 06881 SUB1015FS the electrical supply to prevent possible injury to people and / or damage due to un-wanted start up. Ref No. Description SIP Code Ref No. -
Page 7: Specified Conditions Of Use
EXPLODED DRAWING SPECIFIED CONDITIONS OF USE 06881 SUB1015FS This range of submersible water pumps can be used to drain rain water, do- mestic waste water and to remove water from flooded rooms in emergency conditions. The pump can be used to transfer clean or moderately dirty fluids (depending on the model). -
Page 8: Electrical Connection
Capacitor gland PW11-00056 Steel ball PW11-00073 This SIP water pump is fitted with a standard 230v ~ 13 amp type plug. Before using the water pump, inspect the mains lead and plug to ensure that neither are dam- Screw 3.9x30 PW11-00057 Screw 4.2x32... -
Page 9: Guarantee
Always fully unwind the lead during use. GUARANTEE This SIP water pump is covered by a 12 month parts and labour warranty covering fail- ure due to manufacturers defects. This does not cover failure due to misuse or operat-... -
Page 10: Technical Specifications
TECHNICAL SPECIFICATIONS TROUBLESHOOTING Fault Possible cause Solution Name Sub 1010FS Sub 1015FS Sub 1025SS 1.Blown fuse. 1.Check and replace with SIP Part No. 06879 06881 06885 correct rated fuse. Power 400w 850w 1100w 2.Residual current circuit 2.Check and reset. Flow Rate... -
Page 11: Getting To Know Your Water Pump
MAINTENANCE INSTRUCTIONS GETTING TO KNOW YOUR WATER PUMP The pump is mainly maintenance free, you may need, from time to time to clear the impeller of any unwanted waste / debris. Always ensure that the mains lead is removed from the power supply before all maintenance operations. Remove the base retaining screws (see below diagrams). -
Page 12: Operating Instructions
32mm 13, 15 & 19mm 25mm When installing, please ensure your SIP submersible pump is disconnected from the electrical supply to prevent possible injury to people and / or damage due to un- wanted start up. Screw the hose adaptor onto the elbow, then screw it into the side of the water pump.
