Please dispose of packaging for the product in a responsible
manner. It is suitable for recycling. Help to protect the
12v / 24v
environment, take the packaging to the local amenity tip
and place into the appropriate recycling bin.
Diesel Transfer Pump Kit
Never dispose of electrical equipment or batteries in with
your domestic waste. If your supplier offers a disposal facili-
ty please use it or alternatively use a recognised re-cycling
agent. This will allow the recycling of raw materials and help
protect the environment.
FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR, OR
SIP DIRECTLY ON:
TEL: 01509500400
06801 / 06803
EMAIL: sales@sip-group.com or technical@sip-group.com
www.sip-group.com
Please read and fully understand the instructions in this manual
before operation. Keep this manual safe for future reference.
Ref: 270115
24
1
Advertisement
Table of Contents
Related Manuals for SIP 06801
Summary of Contents for SIP 06801
- Page 1 FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR, OR SIP DIRECTLY ON: TEL: 01509500400 06801 / 06803 EMAIL: sales@sip-group.com or technical@sip-group.com www.sip-group.com Please read and fully understand the instructions in this manual before operation. Keep this manual safe for future reference.
- Page 2 Conforms to the requirements of the following directive(s), as indicated. 2004/108/EC EMC Directive 2008/35/EC RoHS Directive And the relevant harmonised standard(s), including EN 61000-6-1:2007 EN 61000-6-3:2007+A1:2011 Signed: …………………………………... Mr P. Ippaso - Managing Director - SIP (Industrial Products) Ltd Date: 17/09/2014.
-
Page 3: Table Of Contents
NOTES CONTENTS Page No. Description Safety Symbols Used Throughout This Manual Safety Instructions Electrical Connection Guarantee Contents and Accessories Technical Specification Assembly Instructions Operating Instructions Maintenance Wiring Diagram Exploded Drawing Parts List Declaration of Conformity... -
Page 4: Safety Symbols Used Throughout This Manual
The pump is a self priming, positive displace- ment, rotary vane machine which operates on a 12V DC (06801) supply or 24V DC (06803) supply. They deliver a flow of approximately 45 litres per minute (Max.). The pump has a built-in bypass valve for added safety and the motor has a 30 minute duty cycle. - Page 5 USE ONLY RECOMMENDED ACCESSORIES: Consult this user manual, your distributor or SIP directly for recommended accessories. Follow the instructions that accompany the accessories. The use of improper accessories may cause hazards and will invalidate any warranty you may have.
- Page 6 SAFETY INSTRUCTIONS….cont NOTES Ensure that the pump is connected to the correct supply voltage. Become familiar with the controls before operating this pump. Do not attempt to move the pump when it is loaded and/or in operation. Check all bolts, nuts, pipe fittings and screws etc. before each use. When maintaining this pump, only the manufacturer’s original replacement parts may be used.
-
Page 7: Electrical Connection
Pump won’t prime. Debris in Bypass valve. Inspect / have the bypass valve inspected. These Diesel transfer pumps have an input voltage of 12V DC (06801) & 24V DC Motor vanes are sticking Inspect / have the vanes and slots in rotor (06803) supply and are IP55 rated. -
Page 8: Guarantee
GUARANTEE PARTS LIST - 06801 These SIP transfer pumps are covered by a 12 month parts and labour warranty cover- ing failure due to manufacturers defects. This does not cover failure due to misuse or Ref. No. Description Sip Part No. Ref. No. -
Page 9: Technical Specification
Power Lead Fuse Cover Fuel Outlet Fuel Inlet Handle Positive Clamp (Red) On/Off Switch Negative Clamp (Black) TECHNICAL SPECIFICATION Model No. 06801 06803 Input Voltage 12v DC 24v DC Motor 140 watts 140 watts Duty Cycle 30 mins (max.) 30 mins (max.) Flow Rate 40 l/min (max.) -
Page 10: Assembly Instructions
ASSEMBLY INSTRUCTIONS PARTS LIST - 06801 FITTING THE HOSES Ref. No. Description Sip Part No. Ref. No. Description Sip Part No. Motor 12v Bypass valve PW11-00130 PW11-00140 To fit the delivery hose to the pump: Rear cover kit PW11-00131 Bypass spring PW11-00141 Ensure that the supplied O-rings are fitted to each end of the hose (Fig. -
Page 11: Operating Instructions
EXPLODED DRAWING - 06801 OPERATING INSTRUCTIONS POSITIONING THE PUMP The pump can be installed in any direction - Pump axis vertical or horizontal. The pump base should be fixed to a secure surface using the holes provided (Fig. 4). The pump should be installed so that the suction height is as low as possible - maxi- mum of 2 metres. -
Page 12: Maintenance
OPERATING INSTRUCTIONS….cont MAINTENANCE When the desired amount of fluid has been dispensed, release nozzle lever to stop Caution: Ensure that the pump is turned off and that the clips are re- flow. moved from the power supply before carrying out any cleaning or mainte- Immediately switch motor off.
