FOR NORCOLD MODELS 900/9100/N600/N800
Read these important instructions carefully. Become thoroughly acquainted with the
content before installing vents and refrigerator.
IMPORTANT NOTE: Norcold's Venting and Installation instructions must be followed.
These Upper and Lower Side Vent Installation instructions are in addition to Norcold's
Ventilation and Installation instructions that accompany each refrigerator. Follow the Venting
and Installation instructions when installing the refrigerator. Installation must conform with local
codes, or in the absence of local codes, with these standards:
In the United States:
- National Fuel Gas Code, ANSI Z223.1.
- Manufactured Home construction and Safety Standard, Title 24 CFR, Part 32-80.
- Standard for Recreational Vehicles, ANSI A119.2 latest edition.
In Canada:
- Current CGA B149.1 and CGA B149.2 installation code for Propane Appliances and Equip-
ment.
- Current CSA Z240.4.2 Installation Requirement for Propane Appliances and Equipment in
Recreational Vehicles.
- Current CSA Z240.6.2/C22.2 No. 148 Electrical Requirement for Recreational Vehicles.
When installed, the refrigerator must be electrically grounded in accord with local or state codes,
the National Electrical code, and ANSI/NFPA 70. In Canada, grounding is in accord with the
Canadian Electrical Code C22.2.
LP Gas supply piping and fittings must comply with local, state, and national codes governing type
and size. These components should also comply with the current NFPA 501C section 2.41, 1990
and with the current CAN 1-6.10 Standard.
Important!
During storage of the refrigerator in the RV or the trailer, always disconnect the power
source.
Part No. 618698C (7-98)
UPPER & LOWER SIDE
VENT INSTALLATION
1
Advertisement
Related Manuals for Norcold 982F
Summary of Contents for Norcold 982F
- Page 1 IMPORTANT NOTE: Norcold’s Venting and Installation instructions must be followed. These Upper and Lower Side Vent Installation instructions are in addition to Norcold’s Ventilation and Installation instructions that accompany each refrigerator. Follow the Venting and Installation instructions when installing the refrigerator.
- Page 2 Upper and Lower Side Vent Installation These instructions provide an alternative method for installing Norcold 6 and 8 cubic foot refrigerators (see Table 1). This method allows for using two lower vents. The second lower vent serves as the upper exhaust vent, replacing the roof vent. Use only those vents specified in the refrigerator installation guide for side wall installation.
- Page 3 Ventilation Fan Installation To ensure efficient performance, a continuous air flow is required across the refrigerator’s cooling system. A thermostat controlled fan must attach to the refrigerator’s cooling system before placing the refrigerator in the enclosure. This fan assists air flow across the cooling system. The thermostat turns on the fan whenever the refrigerator’s cabinet temperature reaches 95 °...
- Page 4 Fan Installation 1. Position mounting bracket A (See Tools and Parts List, #I) around the top of the two absorber coils. Make sure the wider flange of mounting bracket A is to the bottom. The flanges of mounting bracket A face away from the refrigerator cabinet. See Figure 3. Figure 3 2.
- Page 5 3. Slide mounting brackets along the absorber coils. Leave a 3” clearance between the right edge of the brackets and the cooling unit’s return tube. See Figure 5. Figure 5 4. Tighten 1 1/4” mounting bracket screws securing bracket to cooling system. See Figure 5. 5.
- Page 6 Thermostat Installation 1. Viewing the refrigerator from the rear, mount the thermostat to the right condenser fin. Remove wires from the plastic bag. Untangle any wires that are connected to the thermostat and the fan. Align the holes of the thermostat with the left slot in the condenser fin. See Figures 2 and 6.
- Page 7 Wire Connections Wiring: Splice to Circuit Board (CB) (For 900, 9100, N600, N800 Models): - Route the 6” red spliced wire and attached 60” red fused wire between the front and back absorber coils (Figure 2). - Connect the female end of the 6” red spliced wire to the +12 V CB (circuit board) terminal (Figure 7).
- Page 8 Make sure the wires are pulled in tight between the tie wrap locations and that the tie wraps are firmly secured. The refrigerator is now ready for installation. IMPORTANT: Install the refrigerator according to Norcold’s installation instructions. 900 / 9100 / N600 / N800 Series Side Wall Venting Components Required...
