FOR YOUR SAFETY
If you smell gas:
1. Open windows
2. Do not touch any electrical
switches
3. Extinguish any open flame
4. Immediately call your gas supplier
Improper installation, adjustment, alteration, service, or maintenance can cause
injury or property damage. Read this manual. For assistance or additional informa-
tion consult a qualified installer, service agency, or the gas supplier.
Part No.: 618212D (96-09)
Operator's Guide
for Models:
962
982
WARNING
NORCOLD
P O BOX 4248
SIDNEY OH 45365-4248
900 Series
Refrigerators
963
983
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquid in the vi-
cinity of this or any other appliance.
Vapors can flash back and ignite liq-
uids.
Advertisement
Table of Contents
Related Manuals for Norcold 962
Summary of Contents for Norcold 962
- Page 1 Do not store or use gasoline or other flammable vapors and liquid in the vi- cinity of this or any other appliance. Vapors can flash back and ignite liq- uids. WARNING NORCOLD P O BOX 4248 SIDNEY OH 45365-4248 900 Series FOR YOUR SAFETY...
-
Page 2: Table Of Contents
12 volts DC control voltage (15.4 volts max. - 10.5 volts min.) DC Operation 12 volts DC (15.4 volts max. - 11.5 volts min.) Operating where these specifications are exceeded can damage the refrigerator’s electrical circuit and its related components and will void the refrigerator’s warranty. Table of Contents Auto Mode...9... -
Page 3: Safety Awareness
Always replace a blown fuse with a fuse of the same ampere rating. A circuit overload can result in an electrical fire if undersized wires or improperly sized fuses are used. To prevent a possible electrical fire, follow Norcold’s wire and fuse size requirements (page 6 of "Installation Requirements") and any applicable state, local, or national codes. -
Page 4: Introduction
Norcold refrigerators are the only RV refrigerators manufactured in America, and your 900 series refrigerator is the only RV refrigerator to offer a standard limited two-year warranty. Norcold also offers an additional warranty coverage (2+3 Plan) which extends the standard limited two-year warranty an additional three years for a total of five years protection. -
Page 5: Storage Volume
(one table spoon of baking soda to one quart of water) will freshen the interiors and neutralize odors. Wipe the interior with a soft dry cloth to prevent water spots. Clean the door gaskets in the same manner as the refrigerator interior. -
Page 6: Interior Light
Figure 1 To replace the light bulb, disconnect the 12 volt DC from the rear of the refrigerator. Re- move the light cover by sliding it towards the rear of the fresh food compartment. Remove the bulb from the light bracket. Replace the... -
Page 7: Door Bins And Bin Slide
A frictional drag should be noticed. Repeat all around the door. If the paper does not have a noticeable drag, the gasket is not sealing. Contact your dealer or a Norcold service center for corrective procedures. Figure 4 Rotate slide... -
Page 8: Door Alarm
Norcold Service Center for corrective action. A 12 volt DC supply is required to maintain the refrigerator’s operating control functions. The refrigerator receives its DC power from the vehicle’s 12 volt system; either an auxiliary battery, a converter or engine battery. The 12 VDC system not only supplies power to the refrigerator, but to other DC components in the vehicle. -
Page 9: Auto Mode
"OFF" and then "ON" again. If the gas does not ignite after several attempts, check the input gas supply, or consult with your dealer or a Norcold authorized service center. A different mode of operation may be selected by pressing and holding the "MODE"... -
Page 10: Diagnosic Codes
Battery charging equipment or converter DC connection to the refrigerator Refrigerator’s DC fuse (3 Amp - Control Fuse) See Page 14 Consult your dealer or a Norcold Service Center Check: 10.5 to 15.4 VDC being supplied to refrigerator? Have gas lines been purged? -
Page 11: Refrigerator Failure
If a diagnostic code appears, refer to "Diagnostic Codes and Their Meanings" on page 10. If the refrigerator is operating on gas and a loss of cooling is noticed, switch the refrigerator to the AC mode of operation (see Start-Up Instructions on pages 8 and 9). -
Page 12: Refrigerator Storage
Refrigerator Storage When the refrigerator will not be in use for an extended (seasonal) period of time, it is recommended that all power to the refrigerator be disconnected. Unplug the refrigerator’s AC power cord from the wall receptacle and disconnect the 12 volt DC supply wires from the refrigerator’s power board located at the rear of the refrigerator. -
Page 13: Burner Orifice Removal & Cleaning
Figure 12 1. Remove the refrigerator from its enclosure. Follow "Refrigerator Removal and Replacement" procedure beginning on page 11. 2. Remove the heat deflector cap from the flue. 3. Remove the spiral flue baffle from the flue tube. 4. Using a stiff brush or fine emery cloth, clean the spiral flue baffle of debris. -
Page 14: Fuse Replacement
DC Heater Circuit - 20 amp (yellow) blade-type automotive AC Circuit - 5 amp glass cartridge 10. If a fuse continues to blow, contact your dealer or a Norcold Service Center for corrective action. 5 Amp Glass Cartridge AC Fuse... -
Page 16: Warranty
The Company will provide free service and replacement of defective parts at no charge at all authorized Norcold Service Centers for a period of two years from the date of original purchase. This Limited Warranty covers labor costs incurred in removing and re-installing the refrigerator only when necessary to replace a defective part.
