Design Installation & Operating Manual v.2 EN
Tested by OMNI-Test Laboratories, Inc. and approved to
UL 737 standard - Omni report number: 304-F-06-2
-this document was packed with the appliance fire chamber-
TABLE OF CONTENTS:
a) Characteristics
e) Connector
b) Options
b) Grate
c) Ashes
d) Fuel
d) Surfaces
Page 1 of 20
Agora 850
US EPA exempt
Advertisement
Table of Contents
Related Manuals for Focus Agora 850
Summary of Contents for Focus Agora 850
-
Page 1: Table Of Contents
Agora 850 Design Installation & Operating Manual v.2 EN Tested by OMNI-Test Laboratories, Inc. and approved to UL 737 standard – Omni report number: 304-F-06-2 US EPA exempt -this document was packed with the appliance fire chamber- TABLE OF CONTENTS: 1 –... -
Page 2: Introduction
THEY SHOULD BE STRICTLY OBSERVED. Thank you for choosing focus fireplaces. Appliance designation: agorafocus 850 Manufacturer: focus - atelier dominique imbert – le fort – 34380 viols le fort – France. 2 – SPECIFICATIONS: - NOT FOR MOBILE HOME INSTALLATION! -
Page 3: B) Roof Outlet Requirement
a) Characteristics: • Hearth weight: 61 kg (130 lbs) • Flue diameter: 273 mm (10-3/4 inch); length custom made • Flue weight: 30 kg per meter (21 lbs per foot) • Anchor plate weight: approx. 22 kg (48 lbs) • 2.5 mm (1/10-inch) thick steel •... -
Page 4: C) Chimney Requirement
BE SIZED IN CONGRUENCE WITH THE FIREPLACE STATIC AND DYNAMIC CHARGES. THE SIZE CALCULATION FOR THE SUPPORT IS NOT THE RESPONSIBILITY OF FOCUS OR ITS AFFILIATES. IT IS YOUR RESPONSIBILITY TO CONSULT WITH AN ENGINEER OR ARCHITECT FOR YOUR PROJECT. -
Page 5: F) Fresh Air Intake
Fresh air intake: For optimum functioning, focus requires a fresh air intake in the room (ideally under of the fire). We recommend deflect-O A0684 semi rigid aluminium duct. The wall plate is supplied with a fresh air control. Minimum fresh air intake... -
Page 6: G) Clearances To Combustibles
g) Clearances to combustibles: • Clearances to floor and ceiling: USE OF PROVIDED FIREBOX INSULATOR UNDER THE GRATE (IF ANY: FIRE BRICKS OR VERMICULITE) IS COMPULSORY. Page 6 of 20... - Page 7 • Clearances to walls: CAUTION: THE DISTANCE TO A COMBUSTIBLE WALL MUST BE MAINTAINED AT 36 inches. PROPERTY DAMAGE OR DEATH CAN OCCUR IF THIS DISTANCE IS NOT MAINTAINED. DRYWALL PRODUCTS LINED WITH PAPER SUCH AS SHEETROCK ARE COMBUSTIBLE. CLEARANCES AS INDICATED FURTHER APPLY. Important - manufacturer specifications: When placed close to a non-combustible wall leave a minimum of 8"...
-
Page 8: Installation
Included parts, materials and required tools for installation: -Appliance and designated parts are the fire box, anchor plate (or pedestal if any), black steel flue pipe, focus kit (protective glove, mounting gloves, can of touch-up paint), ash removal hatch, and insulating washers. -
Page 9: C) Assembly Details
c) Assembly details: - Suspended design: stainless steel chimney system anchor plate detail: Page 9 of 20... - Page 10 - focus flue attachment to stainless steel chimney system plate: Page 10 of 20...
- Page 11 - junction sleeve (suspended design) detail: Note: the junction sleeves are manufactured only in case the floor to ceiling height in the room requires to manufacture the focus pipe in several parts (you may not find junction sleeves on usual ceiling heights).
- Page 12 - Suspension mechanism detail: Page 12 of 20...
- Page 13 - Pedestal design : stainless steel chimney system cover disc detail : Page 13 of 20...
-
Page 14: Operating Instructions
4 – OPERATING INSTRUCTIONS: CAUTION: HOT WHILE IN OPERATION. KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. CONTACT MAY CAUSE SKIN BURNS. a) Storage/use of flammable liquids: Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or similar liquids to start or « freshen up » a fire in this heater. Keep all such liquids well away from the heater while it is in use. -
Page 15: E) Before Lighting Your First Fire
- to clean off (with a damp sponge and/or a dry cloth) any dirt collected during transport or installation. Actual scratches on painted designs can be retouched solely with the expressly provided focus can. If this is necessary, ventilate the area thouroughly before lighting your fire to disperse any fumes generated in the spraying process.. -
Page 16: G) Protective Glove
Protective glove: The use of the focus special protective glove supplied with our models is required upon handling the damper, fresh air controls, fire irons, etc. Page 16 of 20... -
Page 17: Maintenance
REMOVED, AS THIS WILL PRODUCE OVER-FIRING OR HOUSE FIRE. DAMAGE CAUSED FROM NON-OBSERVANCE OF THIS CAUTION IS NOT COVERED UNDER FOCUS LIMITED WARRANTY. b) Creosote formation and need for removal: When wood is burned slowly, it produces tar and other organic vapors, which combine with expelled moisture to form creosote. -
Page 18: C) Sweeping Your Chimney
CAUTION: CHEMICAL SWEEP NOT PERMITTED: ONLY MECHANICAL SWEEP ALLOWED! The focus black steel flue, stainless steel flue liner or insulated stainless steel flue chimney system absolutly must be swept with a nylon head sweeper. Never use metal head sweepers! Damage caused from non-observance of this caution is not covered under focus limited warranty. -
Page 19: Warranty
6 – WARRANTY: All of our focus models are guaranteed against any defect in design, construction, or manufacture, and guaranteed to function properly for 10 years from installation. Our product guarantees are applicable only when our fireplaces have been installed with respect to all local building codes and with strict attention to the technical details outlined in our Plan Study as well as our installation, maintenance, and userʼs manuals. - Page 20 Appendix. How to determine if alternate floor protection materials are acceptable. All floor protection must be non-combustible (i.e., metals, brick, stone, mineral fiber boards, etc.). Any organic materials (i.e., plastics, wood paper products, etc.) are combustible and must not be used. The floor protection specified includes some form of thermal designation such as R-value (thermal resistance) or k-factor (thermal conductivity).
