US Robotics 5412 User Manual

Wireless nd1 pc card and pci adapter
Hide thumbs Also See for 5412:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Wireless Nd1 PC Card and PCI Adapter
Wireless Nd1 PC Card, Wireless
Nd1 PCI Adapter: User Guide
Home
Installation
Configuration
Help
The USRobotics Wireless Nd
PC Card and PCI Adapter are the solution to your home and small business
1
wireless connectivity needs. Nd
technology provides the maximum 802.11n Draft 1.0 range in the
1
industry, delivering optimal wireless connections to your PCs, laptops, and other wireless devices. Nd
also
1
provides the maximum speed – up to 270 Mbps – delivering large files like MP3s, digital photos, and digital
video through your network fast and efficiently. And with Nd
, your network will be protected with a
1
maximum security suite of capabilities, including Wi-Fi Protected Access (WPA), WPA2/802.11i, and more.
And to assure a simple, straight-forward installation, U.S. Robotics developed the SureStart installation
wizard. SureStart walks you through the installation of the Nd
PC Card, and PCI Adapter in a seamless
1
fashion. In addition, SureStart provides easy-to-understand guidance to set up security for your wireless
network. Sharing Internet access securely, wirelessly or wired, has never been easier.
file:///G|/CSO/Documentation/Documentation%20-%20Dr...Mach-1%20PCI%20Card/User%20Guide/english/index.html (1 of 2)10/19/2006 12:14:28 PM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5412 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for US Robotics 5412

Summary of Contents for US Robotics 5412

  • Page 1 Wireless Nd1 PC Card and PCI Adapter Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help The USRobotics Wireless Nd PC Card and PCI Adapter are the solution to your home and small business wireless connectivity needs. Nd technology provides the maximum 802.11n Draft 1.0 range in the industry, delivering optimal wireless connections to your PCs, laptops, and other wireless devices.

  • Page 2: System Requirements

    Wireless Nd1 PC Card and PCI Adapter System Requirements Windows™ XP SP1 or later or Windows 2000 SP4 Available PCI or PC slot CD-ROM drive A functioning Ethernet-based cable or DSL modem or other WAN connection for Internet access A browser that supports HTML 4.01 specification with Javascript enabled ©...
  • Page 3 Wireless Nd1 PC Card and PCI Adapter Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help Product Specifications Wireless Nd PC Card Complies with IEEE 802.11n Draft 1.0 270 Mbps wireless radio standard 100mW power output Supports Windows 2000 and Windows XP SecureEasySetup™...
  • Page 4 Wireless Nd1 PC Card and PCI Adapter WPA (Wi-Fi Protected Access) WPA2 (Wi-Fi Protected Access) 802.1x (RADIUS) authentication CCX 1.0 and 2.0 CCKM 64/128-bit WEP (Wired Equivalent Privacy) data encryption Ability to disable wireless radio TKIP Acknowledgements This product includes software developed by MDC and its licensors. This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/).

  • Page 5: Installation

    Wireless Nd1 PC Card and PCI Adapter Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help Installation Depending on the product that you purchased, choose one of the following installation instructions: Click here if you are installing a Wireless Nd PC Card.
  • Page 6 Wireless Nd1 PC Card and PCI Adapter Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help Install Your USRobotics Wireless Nd PCI Adapter Insert the USRobotics Installation CD-ROM into your computer’s CD-ROM or DVD drive. If the CD does not start automatically, start it manually as follows: A.
  • Page 7 Wireless Nd1 PC Card and PCI Adapter 7. Use the screw removed in Step 5 to secure the PCI Adapter. 8. Attach the antennas to the wireless card. 9. Close your computer, plug it in, and turn it on. 10. Windows XP only: A.
  • Page 8 Wireless Nd1 PC Card and PCI Adapter You can also manually enter the wireless security settings to connect your PCI Adapter to any router or access point. If you choose not to connect to a wireless network at this time, you can connect later by following the instructions in Connect to a Wireless Router or Access Point After Installation.
  • Page 9 Wireless Nd1 PC Card and PCI Adapter Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help Install Your USRobotics Wireless Nd PC Card 1. Insert the USRobotics Installation CD-ROM into your computer’s CD or DVD ROM drive.
  • Page 10 Wireless Nd1 PC Card and PCI Adapter 5. Windows XP only: A. If the Found New Hardware Wizard asks to connect to the Windows update Web site to search for software, select No, not this time and click Next. B. With Install the software automatically selected, click Next. 6.
  • Page 11 Wireless Nd1 PC Card and PCI Adapter logos should appear on the device: You can also manually enter the wireless security settings to connect your PC Card to any router or access point. If you choose not to connect to a wireless network at this time, you can connect later by following the instructions in Connect to a Wireless Router or Access Point After Installation.
  • Page 12 Wireless Nd1 PC Card and PCI Adapter © 2005-2006 U.S. Robotics Corporation file:///G|/CSO/Documentation/Documentation%20-%20Dra...-1%20PCI%20Card/User%20Guide/english/pc-install.html (4 of 4)10/19/2006 12:14:31 PM...
  • Page 13 Wireless Nd1 PC Card and PCI Adapter Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help Connect to a Wireless Router or Access Point After Installation To connect to an Nd or other certified SecureEasySetup wireless network device, refer Connect Your PC Card Or PCI Adapter To A certified SecureEasySetup Wireless Router or Access Point.
  • Page 14 Wireless Nd1 PC Card and PCI Adapter 1. Select USRobotics Nd1 SecureEasySetup Wizard from the Start menu's Programs folder. 2. Click Next and follow the on-screen instructions. Security and communication between the certified SecureEasySetup Wireless router or access point and the PC Card PCI Adapter are automatically configured.
  • Page 15 Wireless Nd1 PC Card and PCI Adapter 1. Open the USRobotics Wireless Nd Configuration Utility and select the Wireless Networks tab. 2. Pull down the Add menu and select Use Wizard. Select a wireless network from the list and click Next. 3.

  • Page 16: Configuration Utility

    Wireless Nd1 PC Card and PCI Adapter Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help Overview of the USRobotics Nd Configuration Utility In the Configuration Utility, you can create and edit the settings for wireless connections, view the information regarding your Nd PC Card or PCI Adapter, and perform diagnostic tests on your device.
  • Page 17 Wireless Nd1 PC Card and PCI Adapter In the Link Status area, information regarding your current wireless connection is displayed. file:///G|/CSO/Documentation/Documentation%20-%20Dra...ach-1%20PCI%20Card/User%20Guide/english/utility.html (2 of 7)10/19/2006 12:14:32 PM...
  • Page 18 Wireless Nd1 PC Card and PCI Adapter In Statistics, you can view the results regarding network traffic over your wireless connection. file:///G|/CSO/Documentation/Documentation%20-%20Dra...ach-1%20PCI%20Card/User%20Guide/english/utility.html (3 of 7)10/19/2006 12:14:32 PM...
  • Page 19 Wireless Nd1 PC Card and PCI Adapter In Site Monitor, you can see the wireless network devices that your Wireless Nd Card or PCI Adapter could connect to. If you want to connect to a device that you see in this list, go to the Wireless Networks area.
  • Page 20 Wireless Nd1 PC Card and PCI Adapter In the Diagnostics area, you can run a battery of tests on your Wireless Nd PC Card or PCI Adapter and on your wireless connection. file:///G|/CSO/Documentation/Documentation%20-%20Dra...ach-1%20PCI%20Card/User%20Guide/english/utility.html (5 of 7)10/19/2006 12:14:32 PM...
  • Page 21 Wireless Nd1 PC Card and PCI Adapter In the Information area, you can view the version information for your Wireless Nd Card or PCI Adapter. file:///G|/CSO/Documentation/Documentation%20-%20Dra...ach-1%20PCI%20Card/User%20Guide/english/utility.html (6 of 7)10/19/2006 12:14:32 PM...
  • Page 22 Wireless Nd1 PC Card and PCI Adapter © 2005-2006 U.S. Robotics Corporation file:///G|/CSO/Documentation/Documentation%20-%20Dra...ach-1%20PCI%20Card/User%20Guide/english/utility.html (7 of 7)10/19/2006 12:14:32 PM...
  • Page 23 Wireless Nd1 PC Card and PCI Adapter Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help Introduction to the Configuration Utility The Configuration Utility can be used to change the settings of the Wireless Nd Card or PCI Adapter.
  • Page 24 Wireless Nd1 PC Card and PCI Adapter There are a few ways to access the Configuration Utility and create a wireless connection. Right-click the Utility icon and click Open Utility. This opens the Configuration Utility's Wireless Networks tab. Left-click the Utility icon. If you are connected to a wireless network, the Configuration Utility's Link Status tab opens.

  • Page 25: Basic Troubleshooting Procedure

    Wireless Nd1 PC Card and PCI Adapter Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help Basic Troubleshooting Procedure This procedure addresses some symptoms that you might experience with your PC Card or PCI Adapter, wireless connection, and connection to the Internet: 1.
  • Page 26 Wireless Nd1 PC Card and PCI Adapter I am no longer able to access the Internet. I cannot connect to my wireless router or access point. I am experiencing poor wireless link quality. My computer does not recognise the Wireless Nd PC Card or PCI Adapter.
  • Page 27 Wireless Nd1 PC Card and PCI Adapter The wireless clients seem to be communicating, but they do not appear in the My Computer screen or in the My Network Places screen. My computer does not create a wireless connection to a Wireless Nd1 Router after I changed the settings.

  • Page 28: Pci Adapter

    Wireless Nd1 Router User Guide Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help My computer does not recognise the Wireless Nd PC Card or PCI Adapter. Possible Solution: The Wireless Nd PC Card may not be fully inserted into the PC card slot. You can also try installing the Wireless Nd PC Card into a different PC card slot.
  • Page 29 Wireless Nd1 Router User Guide © 2005-2006 U.S. Robotics Corporation file:///G|/CSO/Documentation/Documentation%20-%20Dra...ch-1%20PCI%20Card/User%20Guide/english/trouble1.html (2 of 2)10/19/2006 12:14:33 PM...
  • Page 30 Wireless Nd1 PC Card and PCI Adapter Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help I am no longer able to access the Internet. When your computer connects to the Internet using the router, a number of devices have to work together.
  • Page 31 Wireless Nd1 PC Card and PCI Adapter 2. Verify the wired or wireless connection to your router. If your computer cannot communicate with the router, it cannot access the Internet. 3. Verify that your router is working. Refer to your router's documentation for additional information.
  • Page 32 Wireless Nd1 PC Card and PCI Adapter 1. Ensure that your computer is close enough to your router to receive a signal and that there is nothing interfering with the signal, such as a microwave oven or a concrete wall. Check the Site Monitor tab of the USRobotics Nd Configuration Utility.
  • Page 33 Wireless Nd1 PC Card and PCI Adapter 1. Ensure that an Ethernet cable is connected between your router's WAN port and the cable/DSL modem's Ethernet port and that the corresponding LEDs are lit. 2. Ensure that your cable/DSL modem is connected to your wall jack. (A cable modem uses a coax cable, and a DSL modem uses an RJ-11 cable.) 3.
  • Page 34 Wireless Nd1 Router User Guide Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help I accidentally clicked Cancel during the software installation procedure for the Wireless Nd PC Card or PCI Adapter. Possible Solution: Remove and reinsert the Installation CD-ROM into your CD-ROM drive. Follow the instructions in this guide for installing the software.

  • Page 35: Installation Cd-Rom

    Wireless Nd1 Router User Guide Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help The USRobotics interface did not begin when I inserted the Installation CD-ROM. Possible Solution: Some programs may disable the autorun feature of Windows. Close any open applications and reinsert the Installation CD-ROM.
  • Page 36 Wireless Nd1 PC Card and PCI Adapter Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help The wireless clients seem to be communicating, but they do not appear in the My Computer screen or in the My Network Places screen.
  • Page 37 Wireless Nd1 PC Card and PCI Adapter Return to Troubleshooting page © 2005-2006 U.S. Robotics Corporation file:///G|/CSO/Documentation/Documentation%20-%20Dr...ch-1%20PCI%20Card/User%20Guide/english/trouble7.htm (2 of 2)10/19/2006 12:14:35 PM...
  • Page 38 Wireless Nd1 Router User Guide Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help I cannot connect to my wireless router or access point. Possible Solution: Ensure that the Configuration Utility is installed for your Wireless Nd PC Card or PCI Adapter and that the Configuration Utility detects your Wireless Nd PC Card or PCI...
  • Page 39 Wireless Nd1 Router User Guide and follow the prompts. Possible Solution: Verify that you are using the same SSID, Channel, and Security information as the wireless router or access point. Perform the following steps to verify and, if necessary, update the settings: 1.
  • Page 40 Wireless Nd1 Router User Guide Possible Solution: Be sure that each Wireless Nd PC Card or PCI Adapter that you want to connect to the wireless network is set to Infrastructure mode within the Configuration Utility. If your Wireless Nd PC Cards or PCI Adapters are not set to Infrastructure mode, they will not be able to communicate with an access point or wireless router.
  • Page 41 Wireless Nd1 PC Card and PCI Adapter Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help The wireless network I want to connect to is not appearing in the Available Networks list in the Configuration Utility. Possible Solution: Verify that your access point or wireless router is functioning correctly.
  • Page 42 Wireless Nd1 PC Card and PCI Adapter Possible Solution: Change the channel on the access point or wireless router to channel 1 and retest. If the problem persists, change the channel on the access point or wireless router to channel 11 and retest. If the problem persists, change the channel on the access point or wireless router to channel 6 and retest.
  • Page 43 Wireless Nd1 Router User Guide Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help The wireless PC Card (adapter) does not work properly, and I may need to uninstall the device. Windows XP Users: Click Windows Start > Control Panel > Add or Remove Programs >...
  • Page 44 Wireless Nd1 PC Card and PCI Adapter Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help Troubleshooting Ping Procedure If at any time during the ping procedure you do not receive a return message for a successful ping, this means that the address you are pinging has been changed and is causing a conflict or is no longer available.
  • Page 45 Wireless Nd1 PC Card and PCI Adapter If you have an IP address of 196.254 or 0.0.0.0, verify that your wireless security settings for your adapter match the wireless security settings on your router and repair the network connection on your computer. 4.
  • Page 46 Wireless Nd1 Router User Guide Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help I am experiencing poor wireless link quality. Solution 1: Poor link quality or range can be caused by environmental interference, such as lead- based paint and concrete walls.
  • Page 47 Wireless Nd1 Router User Guide wireless connection on a different channel. Return to Troubleshooting page © 2005-2006 U.S. Robotics Corporation file:///G|/CSO/Documentation/Documentation%20-%20Dra...h-1%20PCI%20Card/User%20Guide/english/trouble18.html (2 of 2)10/19/2006 12:14:36 PM...
  • Page 48 Wireless Nd1 Router User Guide Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help The USRobotics Nd1 Configuration Utility icon is not displayed in my system tray. Possible Solution: Select the USRobotics Nd1 Configuration Utility from the Windows Start menu. Select Show Utility Icon and click OK.
  • Page 49 Wireless Nd1 Router User Guide Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help The USRobotics Installation CD-ROM did not automatically start when I inserted the Installation CD-ROM. Possible Solution: Some programs (for example, anti-virus programs) may keep the auto-run feature of the USRobotics Installation CD-ROM from beginning.
  • Page 50 Wireless Nd1 Router User Guide Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help My computer does not create a wireless connection to a Wireless Nd Router after I changed the settings. Possible Solution: In the Wireless Nd Configuration Utility, ensure that you are connecting to the correct Wireless Nd Router by verifying the MAC address, Network name (SSID), and security...
  • Page 51 Wireless Nd1 Router User Guide Return to Troubleshooting page © 2005-2006 U.S. Robotics Corporation file:///G|/CSO/Documentation/Documentation%20-%20Dra...h-1%20PCI%20Card/User%20Guide/english/trouble22.html (2 of 2)10/19/2006 12:14:37 PM...

  • Page 52: General Terms

    Wireless Nd1 PC Card and PCI Adapter Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help U.S. Robotics Corporation Two (2) Year Limited Warranty 1.0 GENERAL TERMS: 1.1 This Limited Warranty is extended only to the original end-user purchaser (CUSTOMER) and is not transferable.

  • Page 53: Customer Obligations

    Wireless Nd1 PC Card and PCI Adapter 1.5 U.S. ROBOTICS warrants to the CUSTOMER that this product will be free from defects in workmanship and materials, under normal use and service, for TWO (2) YEARS from the date of purchase from U.S. ROBOTICS or its authorised reseller. 1.6 U.S.

  • Page 54: Obtaining Warranty Service

    Wireless Nd1 PC Card and PCI Adapter 2.2 CUSTOMER is specifically advised to make a backup copy of all software provided with this product. 2.3 CUSTOMER assumes full responsibility to properly install and configure this product and to ensure proper installation, configuration, operation and compatibility with the operating environment in which this product is to function.

  • Page 55: Warranty Replacement

    Wireless Nd1 PC Card and PCI Adapter Product Model Number Product Serial Number Dated Proof of Purchase CUSTOMER contact name & telephone number CUSTOMER Computer Operating System version U.S. ROBOTICS Installation CD-ROM U.S. ROBOTICS Installation Guide 4.0 WARRANTY REPLACEMENT: 4.1 In the event U.S. ROBOTICS Technical Support or its authorised U.S. ROBOTICS Service Centre determines the product or part has a malfunction or failure attributable directly to faulty workmanship and/or materials;...
  • Page 56 Wireless Nd1 PC Card and PCI Adapter authorised. The enclosed Proof of Purchase will be inspected for date of purchase and place of purchase. U.S. ROBOTICS may deny warranty service if visual inspection of the returned product or part does not match the CUSTOMER supplied information for which the RMA was issued.
  • Page 57 Wireless Nd1 PC Card and PCI Adapter caused by acts of nature such as lightning, storms, floods, fires, and earthquakes, etc. Products evidencing the product serial number has been tampered with or removed; misuse, neglect, and improper handling; damage caused by undue physical, temperature, or electrical stress;...

  • Page 58: Governing Law

    Wireless Nd1 PC Card and PCI Adapter Some countries, states, territories or provinces do not allow the exclusion or limitation of implied warranties or the limitation of incidental or consequential damages for certain products supplied to consumers, or the limitation of liability for personal injury, so the above limitations and exclusions may be limited in their application to CUSTOMER.
  • Page 59 1. Know your model and serial number. The model number of the PC Card is 5412. The model number of a PCI Adapter is 5419. You can find your serial number on the side of the package and on the card or adapter.
  • Page 60 Wireless Nd1 PC Card and PCI Adapter Country Webmail Voice www.usr.com/emailsupport/de Austria 07110 900 116 www.usr.com/emailsupport/nl Belgium (Flemish) 070 23 35 45 www.usr.com/emailsupport/be Belgium (French) 070 23 35 46 www.usr.com/emailsupport/cz Czech Republic www.usr.com/emailsupport/ea Denmark 38323011 www.usr.com/emailsupport/ea Finland 08 0091 3100 www.usr.com/emailsupport/fr France 0825 070 693...
  • Page 61 Wireless Nd1 PC Card and PCI Adapter © 2005-2006 U.S. Robotics Corporation file:///G|/CSO/Documentation/Documentation%20-%20Dra...ach-1%20PCI%20Card/User%20Guide/english/support.html (3 of 3)10/19/2006 12:14:38 PM...

  • Page 62: Frequently Asked Questions

    Wireless Nd1 PC Card and PCI Adapter Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help Frequently Asked Questions What is 802.11 wireless networking? 802.11 (sometimes called "Wi-Fi") is a set of protocols that are widely used for small Local Area Networks.
  • Page 63 Wireless Nd1 PC Card and PCI Adapter Radio waves don't really travel the same distance in all directions. Walls, doors, elevator shafts, people, and other obstacles offer varying degrees of attenuation, which cause the Radio Frequency (RF) radiation pattern to be irregular and unpredictable.
  • Page 64 Wireless Nd1 PC Card and PCI Adapter © 2005-2006 U.S. Robotics Corporation file:///G|/CSO/Documentation/Documentation%20-%20Dr...20Mach-1%20PCI%20Card/User%20Guide/english/faq.html (3 of 3)10/19/2006 12:14:39 PM...

  • Page 65: Regulatory Information

    Wireless Nd1 PC Card and PCI Adapter Wireless Nd1 PC Card, Wireless Nd1 PCI Adapter: User Guide Home Installation Configuration Help Regulatory Information Declaration of Conformity U.S. Robotics Corporation 935 National Parkway Schaumburg, IL 60173 U.S.A. declares that this product conforms to the FCC’s specifications: Part 15, Class B This device complies with Part 15 of the FCC Rules.
  • Page 66 FCC Radiation Exposure Statement 5412: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment is in direct contact with the body of the user under normal operating conditions. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
  • Page 67 Wireless Nd1 PC Card and PCI Adapter USR declares that 5412 and 5419 are limited to CH1 through 11, 2412 to 2462 MHz, in the USA by specific firmware, which is controlled by the manufacturer and cannot be changed by the user.

  • Page 68: Radiation Exposure Statement

    Radiation Exposure Statement: 5412: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment is in direct contact with the body of the user under normal operating conditions. This transmitter must not be co-located or...
  • Page 69 We, U.S. Robotics Corporation of 935 National Parkway, Schaumburg, Illinois, 60173- 5157 USA, declare under our sole responsibility that the products, USRobotics Wireless PC Card, Model 5412 and PCI Adapter, Model 5419 to which this declaration relates, are in conformity with the following standards and/or other normative documents.
  • Page 70 Wireless Nd1 PC Card and PCI Adapter The conformity assessment procedure referred to in Article 10 and detailed in Annex IV of Directive 1999/5/EC has been followed. This equipment is in compliance with the European recommendation 1999/519/ECC, governing the exposure to the electromagnetic radiation. This product can be used in the following countries: Germany, Austria, Belgium, Switzerland, Netherlands, Luxembourg, Italy, France, UK, Ireland, Spain, Portugal, Sweden, Norway, Denmark, Finland, Czech Republic, Poland, Hungary, Turkey, and...

  • Page 71: Channel Frequency (Mhz)

    Wireless Nd1 PC Card and PCI Adapter In Guyana and Reunion Islands, outdoor use is forbidden within 2400MHz – 2420MHz frequency band Regulatory Channel Frequency Channel Frequency (MHz) Canada ETSI 2412 2417 2422 2427 2432 2437 2442 2447 2452 2457 2462 2467 2472...
  • Page 72 Radiation Protection (ICNIRP, 1999) for the entire population. The exposure standard for portable equipment uses the "Specific Absorption Rate" as unit of measure. The maximum SAR value of the 5412 wireless device measured in the conformity test is 0.724 W/Kg.
  • Page 73 Wireless Nd1 PC Card and PCI Adapter Go to www.usr.com to see the most recent channel restriction information. © 2005-2006 U.S. Robotics Corporation file:///G|/CSO/Documentation/Documentation%20-%20Dra...-1%20PCI%20Card/User%20Guide/english/regulatory.html (9 of 9)10/19/2006 12:14:39 PM...

  • Page 74: Copyright Information
