Never disassemble or modify this product.
(Improper work may result in injury or fire.
Contact selling office for repair.)
Do not allow foreign body to fall into the
equipment. (It may cause fire or electrocution)
Do not Install on the insulating material (It may
cause fire)
Request
to
seller
contractor for installation.
2. Installation Parts
Below parts are needed for installation. Please procure the parts before installation.
No.
Category
1
LAN Cable
2
DC Adaptor (Using DC)
3
POE hub (Using POE)
4
Screw driver
3. Contents of pack
- REGX-XOXXA (ESL Gateway) 1ea
- User's Manual (this manual) 1ea
- Bracket 1ea (Optional)
- Screw 2ea (Optional)
4. Installation (Using Spring)
① Before Installation, Check following conditions.
- Ceiling should be able to stand weight of ESL Gateway (0.4kg)
- Fix reinforcement material to prevent ESL Gateway from moving on the ceiling.
! WARRING - Be sure to set this equipment on a firm, stable, horizontal ceiling.
(The product could be broken or cause injury if it falls)
② Secure space to insert ESL Gateway into the ceiling
-
Make specified space (Diameter ∅100mm+3, -0)
-
Mounting ceiling thickness : 5mm ~ 20mm
office
or
professional
10BaseT Cat. 5 or 100BaseTX Cat. 5 STP
RJ-45
DC 12V / 1A or above, 3.5∅ DC Power Jack
More 12Watts Max Port Output
Be sure to set this equipment on a firm, stable,
horizontal ceiling. (The product could be
broken or cause injury if it falls)
Installation must be done completely following
this instruction to prevent fire or electrocution.
Do not connect both POE cable and DC cable
to ESL Gateway (It may cause break down or
fire)
Do not cover this equipment with a newspaper,
tablecloth, curtain, etc. (it may cause fire)
Description
(Shielded Twisted
Pair)
