Tek-CARE
Intercom Nurse Call Systems
Operation and Installation Manual
Tek-CARE
NC150 and NC200 series Intercom Nurse Call Systems are designed
®
for nursing home or individual hospital ward use. The Tek-CARE
NC200 systems provide selective two-way audio and visual communication from
master station to staff and patient stations, as well as emergency signaling and call
indication from remote locations. Emergency calls are indicated by a rapid pulsing
of all audible and visual signals associated with the calling station. Emergency calls
take precedence over normal calls and can only be canceled at the point of origin.
NC150 and NC200
®
UL
1069 Listed
®
IL380
Section E
Rev. 23 - 10/2016
NC150 and
®
Advertisement
Table of Contents
Related Manuals for TekTone Tek-CARE NC150N
Summary of Contents for TekTone Tek-CARE NC150N
- Page 1 IL380 Section E Rev. 23 - 10/2016 Tek-CARE NC150 and NC200 ® Intercom Nurse Call Systems 1069 Listed ® Operation and Installation Manual www.tektone.com Phone: 828.524.9967 Toll-Free: 800.327.8466 Sales: Option 2 Tech Support: Option 3 Tek-CARE NC150 and NC200 series Intercom Nurse Call Systems are designed ®...
- Page 2 Tek-CARE NC150 and NC200 Operation and Installation Manual ® No part of this publication may be copied without the express written permission of TekTone Sound & Signal Mfg., Inc. The Copyright © 2001–2016 TekTone Sound & Signal Mfg., Inc., All rights reserved.
-
Page 3: Table Of Contents
......IL380 Tek-CARE NC150 & NC200 Manual • iii Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. ®... -
Page 4: A Word About Esd (Electrostatic Discharge)
This information is provided to make you aware of ESD problems so that precautions may be taken to avoid damage and disruption of system operation. iv • IL380 Tek-CARE NC150 & NC200 Manual ® Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. -
Page 5: System Operating Instructions
Emergency calls are indicated by simultaneous operation of the following signals: • Rapid flashing of the associated station selector lamp, which is marked to indicate call origin. • Rapid flashing of call lamp. • Rapidly pulsing audible tone. IL380 Tek-CARE NC150 & NC200 Manual • 1 Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. ®... -
Page 6: Figure 1-Nc150N And Nc200N Control Locations
– Station Selector Lamps: Indicates incoming call from associated remote station when illuminated. Indicates emergency call from remote when flashing. 2 • IL380 Tek-CARE NC150 & NC200 Manual ® Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. - Page 7 • If a malfunction occurs during a call and causes a lack of indication of call origin on the m aster station, first d etermine the o rigin of t he c all b y o bserving which corridor light and corridor zone light is illuminated, then inform qualified personnel. IL380 Tek-CARE NC150 & NC200 Manual • 3 Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. ®...
- Page 8 Indicates an emergency call when flashing. 13 – Tone Off Switch: Silences normal audible tone signal when pushed down. 4 • IL380 Tek-CARE NC150 & NC200 Manual ® Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved.
-
Page 9: Ir151B, Ir152B Patient Stations
There are no user serviceable parts on the SF155B Emergency Improper Operation: If the call station does not operate as described, contact qualified Call and SF156B Code Call Stations. IL380 Tek-CARE NC150 & NC200 Manual • 5 Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. ®... -
Page 10: Li150B Duty Stations
There are no user serviceable parts on the LI382 Corridor Zone Lights other than lamps. There are no user serviceable parts on the LI382LED Corridor Zone Lights. 6 • IL380 Tek-CARE NC150 & NC200 Manual ® Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. -
Page 11: System Installation
3 amps. The FZ151 Fuse Assembly must be located between the PK800A and the PK151A or PK152. See for actual FZ151 connection points. Figure 16 IL380 Tek-CARE NC150 & NC200 Manual • 7 Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. ®... -
Page 12: Wiring Installation
Replace self-tapping metal screws. housing attachment. 8 • IL380 Tek-CARE NC150 & NC200 Manual ® Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. -
Page 13: Housing Installation
IR150B, IR151B, IR152B and IR155B SF156B, LI150B, LI381, LI382 and LI382LED Install ring with panel mounting holes at top and bottom, as shown. IL380 Tek-CARE NC150 & NC200 Manual • 9 Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. ®... -
Page 14: Wire Checkout
Make sure minimum number of conductors needed for all of the equipment being used in the system are available. Figure 7—SS106 Transformer Installation 10 • IL380 Tek-CARE NC150 & NC200 Manual ® Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. -
Page 15: Wire Connections
LI150B Duty Stations: Push the switch up. tone off IL380 Tek-CARE NC150 & NC200 Manual • 11 Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. ®... -
Page 16: System Checkout And Testing
• The rapidly pulsing audible call tone should be heard. The switch must not cancel the emergency call tone. call placed tone off 12 • IL380 Tek-CARE NC150 & NC200 Manual ® Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. -
Page 17: System Maintenance Instructions
Release and plug will click into place. • To test handset, initiate a call to a remote station. The handset should operate as described above. IL380 Tek-CARE NC150 & NC200 Manual • 13 Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. ®... -
Page 18: Ir150B Staff And Ir155B Patient Stations
Figure 8—NC150N, NC200N Lens, Filter and Lamp Replacement 1 – Lens 2 – Filter 3 – 24V Lamp 4 – Switch Knob 14 • IL380 Tek-CARE NC150 & NC200 Manual ® Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. -
Page 19: Fz151 In-Line Fuse Holder
Replacement Parts There are no user serviceable parts on these stations. Notify qualified service personnel SF155B Emergency and SF156B Code Stations for repair or replacement. There are no user serviceable parts on these stations. Notify qualified service personnel LI150B Duty Stations for repair or replacement. IL380 Tek-CARE NC150 & NC200 Manual • 15 Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. ®... -
Page 20: Li381 Corridor And Li382 Corridor Zone Lights
Call Cord IR151B, IR152B SF302 Dual Call Cord IR151B, IR152B TA150N Handset NC150N Master Station TA200N Handset NC200N Master Station 16 • IL380 Tek-CARE NC150 & NC200 Manual ® Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. -
Page 21: Figure 9-Nc150N, Nc200N Nurse Call Systems Notes And Electrical Ratings
LI382 Corridor Zone Light......24 VDC, .068 amps LI382LED Corridor Zone Light...... 24 VDC, .08 amps PK800A Secondary Power Supply ....24 VAC, 60 Hz IL380 Tek-CARE NC150 & NC200 Manual • 17 Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. ®... -
Page 22: Figure 10-Block Wiring Diagram Without Zone Lamps
TRUNK & DOME SERIES SERIES SERIES LIGHT POINT PAIR STATION STATION STATION IL380 NC150N NC200N Block Diagram 1 Rev4 081214 18 • IL380 Tek-CARE NC150 & NC200 Manual ® Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. -
Page 23: Figure 11-Block Wiring Diagram With Zone Lamps
4 #22 plus POINT PAIR POINT PAIR POINT PAIR DOME SERIES SERIES STATION STATION IL380 NC150N NC200N Block Diagram 2 Rev4 081214 IL380 Tek-CARE NC150 & NC200 Manual • 19 Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. ®... -
Page 24: Figure 12-Nc150N, Nc200N Wiring Diagram
20 • IL380 Tek-CARE NC150 & NC200 Manual ® Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. -
Page 25: Figure 13-Nc150N, Nc200N, Two Stations In Parallel
IL380 Tek-CARE NC150 & NC200 Manual • 21 Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. ®... -
Page 26: Figure 14-Pk153 Wiring Diagram With Smoke Detector
22 • IL380 Tek-CARE NC150 & NC200 Manual ® Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. -
Page 27: Figure 15-Pk153 Wiring Diagram With Sf156B Code Station
IL380 Tek-CARE NC150 & NC200 Manual • 23 Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. ®... -
Page 28: Figure 16-Pk151A Or Pk152 To Pk800A Interconnection
24 • IL380 Tek-CARE NC150 & NC200 Manual ® Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. -
Page 29: Figure 17-Sk151N Switch Board Pcb Assembly
Figure 17—SK151N Switch Board PCB Assembly IL380 Tek-CARE NC150 & NC200 Manual • 25 Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. ®... -
Page 30: Figure 18-Sf337C Cross Reference Diagram
26 • IL380 Tek-CARE NC150 & NC200 Manual ® Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. -
Page 31: Figure 19-Sf339 Cross Reference Diagram
IL380 Tek-CARE NC150 & NC200 Manual • 27 Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved. ®... -
Page 32: Figure 20-Nc110N Hookup To Nc150N, Nc200N
TERMINAL MODULE NC110N PK151A / PK152 SELECTIVE LAMP WIRE ON NC150N, NC200N IL381 NC110N NC150N NC200N Hookup Rev2 100110 1 28 • IL380 Tek-CARE NC150 & NC200 Manual ® Copyright © TekTone Sound & Signal Mfg., Inc. All Rights Reserved.
