- Page 1 Gas Watcher Bluetooth Pressure Gauge & Receiver/Router Installation & Operation Instructions 166 Keystone Drive Montgomeryville, PA 18936 Telephone: 215-641-2700 Fax: 215-641-2714 INT-0332 rev A...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION PAGE NUMBER LIMITED WARRANTY ..........................3 USER RESPONSIBILITY ......................... 4 GENERAL INFORMATION ........................5 QUICK START GUIDE ........................ 5 NORMAL OPERATION ......................6 RECEIVER/ROUTER ........................9 DATA ACCESS ........................... 14 TECHNICAL SUPPORT ......................14 INT-0332 rev A... -
Page 3: Limited Warranty
The foregoing warranties shall not apply if the equipment has been repaired other than by Matheson or a service facility designated by Matheson, or if this equipment has not been operated and maintained in accordance with written instructions provided by Matheson, or has been altered by anyone other than Matheson, or if the equipment has been subject to abuse, misuse, negligence or accident. -
Page 4: User Responsibility
Montgomeryville Pennsylvania or to the nearest Matheson Tri-Gas Branch location. This equipment or any of its parts should not be altered without the prior written approval of Matheson Equipment Engineering Group. The user of this equipment shall have the sole responsibility for any malfunction, which results from improper use, faulty maintenance, damage, improper repair or alteration by anyone other than Matheson Tri-Gas or a service facility designated by Matheson Tri-Gas. -
Page 5: General Information
GENERAL INFORMATION The Gas Watcher™ is a Bluetooth pressure gauge where the pressure can be read not only at the device but also remotely via connection to a web based portal. Gas Watcher™ has the approximate dimensions similar to standard mechanical pressure gauges and can be easily and quickly installed into regulators and manifold arrangements. -
Page 6: Normal Operation
Press and hold PB1 for another 3 seconds will display the firmware revision. Press and hold PB1 for a final 3 seconds to return to the normal display Note: The Gas Watcher™ will return to the normal display if left alone for a few minutes. Normal... - Page 7 Change Cylinders Gas Watcher™ has the ability to transmit the number of cylinders used at a specific location to provide gas usage data. How? As gas pressure drops below 50 psi and then rises above 55 psi, the Gas Watcher™ will display the text message “Chg?” in a blinking (flashing) pattern.
- Page 8 Troubleshooting: Error Codes If there is a failure, the “Error Code” will display for 15 seconds and then the Gas Watcher™ will turn off. The Gas Watcher™ must now be removed from service and returned to MATHESON for diagnosis and repair.
-
Page 9: Receiver/Router
Receiver/Router is packaged in a NEMA 4 enclosure suitable for outdoor installation and is easy to install with its integrated mounting holes. If your local network system supports DHCP – then once the Gas Watcher Router is connected to the network, it will be automatically configured and ready for operation. - Page 10 Wireless Router Installation You can connect each Gas Watcher™ Router by using your cell phone and following the steps below. This process must be performed for each Gas Watcher™ Router within the facility. 3.3.1 Obtain the information listed below from your IT/Network Administrator regarding the wireless network each Gas Watcher™...
- Page 11 10-15 feet of your Gas Watcher Router. 3.3.7 Select the type of internet connection you desire for use with your Gas Watcher Router 3.3.8 If you previously selected a “Wired” network connection and your network uses DHCP – you do not need to perform any further settings, simply touch “Finish”...
- Page 12 Advanced Configuration Settings for Wireless Configuration & Connection To specify/assign a static IP address, or static name-servers to the Gas Watcher™ Router, follow the steps below. Once more, this procedure MUST be performed for each Gas Watcher™ Router installed. INT-0322 rev A...
- Page 13 Once this option is disabled, you will be able to provide (assign), a Static IP Address, Netmask and Gateway for each Gas Watcher™ Router. You can also specify custom name servers at this time. When you are satisfied with your network configuration, press the “Done”...
-
Page 14: Data Access
The Subscription Code for the Router is on a card attached to the router. Technical Support If you have any questions regarding the set-up and operation of the Gas Watcher™ device, please contact MATHESON Tech Support at: 800-416-2505 or by email at: gaswatchersupport@mathesongas.com.
