Anybus Module Objects
10.7

SMTP Client Object (09h)

Category
Extended
Object Description
This object groups functions related to the SMTP client.
Supported Commands
Object:
Instance:
Object Attributes (Instance #0)
# Name
1 Name
2 Revision
3 Number of instances
4 Highest instance no.
11 Max. no. of instances
12 Success count
13 Error count
Instance Attributes (Instance #1)
Instances are created dynamically by the application.
# Name
1 From
2 To
3 Subject
4 Message
®
Anybus CompactCom ™ 40 Common Ethernet Design Guide
Get_Attribute
Create
Delete
Send e-mail from file (see below)
Get_Attribute
Set_Attribute
Send e-mail (see below)
Access Data Type
Get Array of
CHAR
Get UINT8
Get UINT16
Get UINT16
Get UINT16
Get UINT16
Get UINT16
Access Data Type
Get/Set Array of
CHAR
Get/Set Array of
CHAR
Get/Set Array of
CHAR
Get/Set Array of
CHAR
Value
"SMTP Client"
01h
-
-
0006h
Reflects the no. of successfully sent messages
Reflects the no. of messages that could not be delivered
Description
e.g. "someone@somewhere.com"
e.g." someone.else@anywhere.net"
e.g. "Important notice"
e.g."Shut down the system"
82 (104)
HMSI-27–269 2.1
