IMPORTANT MANUAL
OWNER'S MANUAL
MODEL NUMBER:
PO8527ESA

SNOW THROWER

Always Wear Eye Protection During Operation
Do Not Throw Away
WARNING:
Read the Owner's Manual and
fol low all Warnings and Safety
In struc tions. Fail ure to do so
can result in serious injury.
193452 08.19.04 BY
Printed in U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PO8527ESA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Poulan Pro PO8527ESA

Summary of Contents for Poulan Pro PO8527ESA

  • Page 1: Snow Thrower

    IMPORTANT MANUAL OWNER'S MANUAL MODEL NUMBER: PO8527ESA SNOW THROWER Always Wear Eye Protection During Operation Do Not Throw Away WARNING: Read the Owner's Manual and fol low all Warnings and Safety In struc tions. Fail ure to do so can result in serious injury.

  • Page 2: Safety Rules

    Safe Operation Practices for Snow Throwers IMPORTANT: This machine is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury or death. Look for this symbol to point out im- por tant safety precautions.

  • Page 3: Maintenance And Storage

    • Do not put hands or feet near or under rotating parts. Keep clear of the discharge opening and front auger area at all times. • Exercise extreme caution when op er at ing on or cross- ing gravel drives, walks or roads. Stay alert for hidden hazards or traffi...

  • Page 4: Table Of Contents

    SAFETY RULES ... 2-3 PRODUCT SPECIFICATIONS ... 3 CUSTOMER RESPONSIBILITIES... 3 WARRANTY... 32 ASSEMBLY / PRE-OPERATION ... 5-7 OPERATION ... 8-14 PARTS PACKED SEPARATELY IN CARTON MAINTENANCE ... 14-16 MAINTENANCE SCHEDULE ... 14 SERVICE AND AD JUST MENTS ... 16-18 STORAGE ...

  • Page 5: Assembly / Pre-Operation

    ASSEMBLY / PRE-OPERATION Read these instructions and this man u al in its entirety before you attempt to assemble or operate your new snow thrower. Your new snow thrower has been as sem bled at the factory with the ex cep tion of those parts left unassembled for shipping purposes.
  • Page 6 ASSEMBLY / PRE-OPERATION INSTALL TRACTION DRIVE CONTROL ROD (See Figs. 3 and 4) The traction drive control rod has the long loop on the end of the spring as shown. 1. Slide rubber sleeve up rod and hook end of spring into pivot bracket with loop opening down as shown.
  • Page 7 ASSEMBLY / PRE-OPERATION INSTALL DISCHARGE CHUTE / CHUTE ROTATER HEAD (See Fig. 7) NOTE: The multi-wrench provided in your parts bag may be used to install the chute rotater head. 1. Place discharge chute assembly on top of chute base with discharge opening toward front of snow thrower.

  • Page 8: Know Your Snow Thrower

    OPERATION KNOW YOUR SNOW THROWER READ THIS OWNER'S MANUAL AND ALL SAFETY RULES BEFORE OPERATING YOUR SNOW THROWER. Compare the illustrations with your snow thrower to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. These symbols may appear on your snow thrower or in literature supplied with the product.
  • Page 9 SPARK PLUG SAFETY IGNITION CHOKE CON- TROL THROTTLE / ENGINE CONTROL RECOIL POWER (AUXILIARY) CORD STARTER PLUG ELECTRIC HANDLE START BUTTON PRIM ER NOTE: ITEMS ABOVE ARE SHOWN IN THEIR TYPICAL LOCATION ON THE ENGINE. ACTUAL LOCATION MAY VARY WITH THE ENGINE ON YOUR UNIT.
  • Page 10 The operation of any snow thrower can result in foreign objects thrown into the eyes, which can result in severe eye damage. Always wear safety glasses or eye shields while operating your snow thrower or performing any ad just - 00155 ments or repairs.

  • Page 11: To Move Forward And Backward

    CHUTE DEFLECTOR LOW POSITION FIG. 13 TO THROW SNOW (See Fig. 14) The auger rotation is controlled by the auger control lever located on the right side handle. • Squeeze auger control lever to handle to engage the auger and throw snow. •...

  • Page 12: Before Starting The Engine

    POWER STEERING OPERATION (See Fig. 17) Steering triggers are used to assist in steering your snow throw- er. The triggers are located on the underside of each handle. When a trigger is squeezed, it disengages the drive wheel on that side of snow thrower and allows it to turn in that direction. •...
  • Page 13 CHOKE CONTROL THROT TLE SAFETY IG NI TION RECOIL STARTER HANDLE NOTE: ALL ITEMS ARE SHOWN IN THEIR TYPICAL LOCATION. ACTUAL LOCATION MAY VARY WITH ENGINE ON YOUR UNIT. FIG. 20 TO START ENGINE • Be sure fuel shut-off valve is in the OPEN position. Your snow thrower engine is equipped with both a 120 Volt A.C.

  • Page 14: Snow Throwing Tips

    IF RECOIL STARTER HAS FROZEN If the recoil starter has frozen and will not turn the engine, proceed as follows: 1. Grasp the recoil starter handle and slowly pull as much rope out of the starter as possible. 2. Release the recoil starter handle and let it snap back against the starter.

  • Page 15: Lubrication Chart

    LUBRICATION CHART ➀ SAE 30 Motor Oil ➁ See “ENGINE” in Maintenance section ➀ Pivot points ➁ Engine oil SNOW THROWER Always observe the safety rules when performing any main te nance. TIRES • Maintain proper air pressure in both tires (See “PROD- UCT SPECIFICATIONS”...

  • Page 16: Service And Adjustments

    MUFFLER Inspect and replace corroded muffl er as it could cre ate a fi re haz ard and/or dam age. SPARK PLUG Replace spark plug at the beginning of each season or after every 100 hours of operation, whichever occurs fi rst. Spark plug type and gap setting are shown in the “PROD UCT SPEC I FI CA TIONS”...

  • Page 17: Service And Adjustments

    SERVICE AND ADJUSTMENTS TO REMOVE BELT COVER (See Fig. 22) 1. Remove the two screws securing belt cover to frame. 2. Remove belt cover. • Replace belt cover by installing cover and screws and tighten securely. FRAME BELT COVER FIG. 22 TO REPLACE BELTS (See Fig.

  • Page 18: Storage

    SERVICE AND ADJUSTMENTS 12. Install the two (2) hex bolts and lock washers and tighten securely. 13. INSTALL ENGINE PULLEY - Place belt in pulley groove and slide pulley on crankshaft. Install fl at washer, lock- washer and bolt and tighten securely (30-35 ft. lbs. torque).

  • Page 19: Troubleshooting

    3. Pull recoil starter handle slowly a few times to dis trib ute oil. 4. Replace with new spark plug. OTHER • Do not store gasoline from one season to another. • Replace your gasoline can if your can starts to rust. Rust and/or dirt in your gasoline will cause problems.

  • Page 20: Limited Warranty

    The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from de- fects in materials and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we fi...
