- Page 1 Content Content Overview DV304 feature DV304 SYSTEM: Structure Key functions and LED indication Menu setting Operation manual Specification GPS tracker player and instruction...
- Page 2 Overview DV304 is a digital Full HD video recorder with the most advanced technology. It can record the high resolution image with the pixel as high as 1920X1080P FULL HD and take the photo of 3 mega pixels. Using micro card as the storage device, DV301 video recorder can record all the images and sounds during driving.
- Page 3 Features ◎170 degree ultra wide angle lens； ◎1920x1080P30fps high resolution recording； ◎Advanced H.264 video compression technology； ◎2 resolution forms (1080p&720p) can be changed for video recording ◎ 30/60 frames per second for smooth video flow ◎Seamless recoding, will not miss any data between the files. ◎...
- Page 4 DV304-Structure LED lights BUZZER Micro SD card USB port Panic button Photo...
- Page 5 Installation...
-
Page 6: Key Functions
Key functions Panic button During recording: press the panic button, it will protect the files (30s before pressing & 30s after pressing) from overwriting. When powered on and pre-recording mode: press panic button will change from Pre-recording to recording mode, and lock current file (protect current file from over writing). - Page 7 Buzzer Buzzer will working as following conditions: 1) Power ON/OFF : 3 continue beeps; 2) Photo Snapshot : 1 beep 3) GPS positioned : 1 beep 4) Panic button active/ G Sensor active/ Overspeed (when GPS module present) : 2 continue beeps;...
-
Page 8: Menu Setting
Menu setting 1. Click the “DV304 Config.exe”, as the picture below: 2. Configuration Menu setting: * Video Resolution： * Resolution for video recording * Available at 1080P/30fps, 720P/60fps, 720P(30fps) * Default Setting at : 1080P/30fps * Seamless time： * Select the length of each file: 1/3/5 min. - Page 9 * Normal mode : for Normal mode, this will base on "Video Resolution" video recording, for example at 1080P/30fps, 720P/60fps, 720P(30fps); * Event only : for Event mode, the device only recording base on "Video Resolution" when Event activate (including Panic button, G-sesnor trigger, Over-speed), plus there will be have 10 second Pre-recording/ 50 second Post-recording (totally 1 mins Event recording);...
- Page 10 * Time zone : * Time Zone setting * Default Setting at : GMT -5:00 EST * DST (Daylight Saving Time) : * Setup the DST Function mode: * Auto: DST will automatically start from 2nd Sunday of 3rd month in every year/ and finish by 1st Sunday in Novmeber in same year;...
