AquaLiv Water System – Model A500
Usage & Installation Instructions
Welcome to AquaLiv Water and congratulations! You just purchased the most complete and comprehensive water purification and
enhancement system available today.
The AquaLiv Water System produces energized, structured, alkaline water - just as nature intended.
Enjoy the water!
DAILY USE
Some AquaLiv technologies require water to be moving, while others require water to be still. Therefore, it will take 24 hours of normal
use for the system to 'charge up' and up to a week of normal use for maximum power.
After installation, the water may be cloudy or taste heavily of minerals for 2-3 weeks. This is normal as it takes some time for the filters
to become conditioned to the source water. To help alleviate this condition, AquaLiv suggests flushing when an off-taste is noticed or
daily for the first week of use. Simply open the tap fully until the water slows (usually about 3 minutes) and then close. Allow pressure
tank to fill before using again (about 30 minutes).
Cloudiness is the result of two conditions in a newly installed system. The vortex process atomizes air trapped in the system. The other
is hydrogen-bubbles created by the pH/Alkaline/ORP cartridge. The water is safe to drink during this time and the hydrogen bubbles are
actually very healthful! If you do not want to drink the cloudy water, set the glass down and allow the tiny bubbles to rise to the top.
The A500 Purification Module requires filter changes every 12 months. However, each filter set includes a quantity of two
pH/Alkaline/ORP cartridges, as it should be replaced after 6 months of use- don't forget to mark your calendar. The Tubing Adapters
that screw into the cartridge can be reused once. Each set of replacement filters includes a new set of Tubing Adapters.
To order replacement filters, visit shop.aqualiv.com and select Filter Set FS500.
To order replacement or alternative installation parts, visit shop.aqualiv.com and select Parts.
The AquaLiv Water Revitalizer requires no maintenance. Attempts to open the tank may damage the head and sub-assembly. If the
internal tamper seals are broken, the system warranty will be void.
pH TESTING – pH testing drops and paper strips do not work with structured water. Use a digital pH meter.
WARRANTY – Your Warranty begins with the purchase date on your receipt. Do not lose your receipt!
Your AquaLiv Water System is warrantied against material defects and errors in workmanship for a period of two (2) years. Faucets and RO membranes
have a one (1) year warranty. The warranty does not cover property damage, including flood and/or water damage. All plumbing systems should be
inspected periodically after installation to ensure an absence of leaks that may result in damage to surrounding areas. Warranty is void if product failure
or damage results from freezing, neglect, misapplication, fouling with sediment, or failure to operate system in accordance with the recommended
procedures and guidelines: the RO system must be connected to a potable cold water supply; the hardness of the water cannot exceed 7 grains per
gallon or 120 ppm; source water TDS not to exceed 800 ppm; supply pressure must be between 35 and 70 psi; incoming water temperature not to
exceed 90 degrees F.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AquaLiv A500
Summary of Contents for AquaLiv A500
- Page 1 WARRANTY – Your Warranty begins with the purchase date on your receipt. Do not lose your receipt! Your AquaLiv Water System is warrantied against material defects and errors in workmanship for a period of two (2) years. Faucets and RO membranes have a one (1) year warranty.
-
Page 2: Check Your System
(1x) Faucet (if ordered) INSTALLATION OVERVIEW AquaLiv suggests a professional plumber install the AquaLiv Water System. However, anyone with handy-person skills and a few basic tools can accomplish the task. It is best to remove all under-sink contents prior to installation. -
Page 3: Installation
Ensure the preferred position of the Modules is possible within the length of the 36” lengths of tubing. 4) The Pressure Tank also connects to the A500 Purification Module, at the backside of the outlet filter. There are two places to connect the tubing. Depending on whether you choose to mount the A500 Purification Module on the right or left side of the under-sink cabinet, choose the port pointing to the back of the cabinet. - Page 4 STEP #2: Install the Cold Water Connection Tee (do NOT use plumber’s tape) 1) Close the cold water supply valve to the kitchen faucet. Open the cold side of the kitchen faucet to relieve pressure and then close again. 2) Disconnect the cold water supply tube/hose/pipe at the end connected to the kitchen faucet. (Do not remove the tube/hose/pipe from the cold water supply valve) 3) Screw the Cold Water Connection Tee onto the kitchen faucet until you feel resistance, then turn an additional 180°- 360°.
- Page 5 STEP #4: Install the Drain Saddle Drain Saddles are designed to be installed on standard 1-1/2” OD drain-pipe. Install drain saddle above (and before) the trap and on the vertical or horizontal tailpiece. Never install the Drain Saddle close to the outlet of a waste disposal or plugging of the RO drain line may result.
- Page 6 STEP #7: Attach ph/Alkaline/ORP Cartridge to Purification Module, Install 1/4” OD Red Tube 1) Pry the blue plugs from the ends of the Cartridge. 2) Locate the two 3/8” OD Tubing Adapters and screw them into the ends of the Cartridge until o-rings are fully seated. Plumber’s Tape is generally not required on these fittings.
- Page 7 IMPORTANT NOTE Tubing that is not fully seated will result in leaks. STEP #10: Filling and Flushing AquaLiv Water System 1) Open the system faucet fully and then slowly open the cold water supply valve. IMPORTANT: Watch for leaks and be ready to shut off the cold water supply.
- Page 8 The AquaLiv Water System in now installed! IN AN EMERGENCY Should the water supply to the AquaLiv Water System need to be shut off while cold water is wanted at the kitchen faucet: 1) Close the cold water supply valve...
- Page 9 SMALL PART IDENTIFICATION CHART 1/4” OD THREADED ELBOW TUBING ADAPTER 3/8” OD THREADED ELBOW TUBING ADAPTER 1/2” OD COLD WATER CONNECTION TEE 2.5” X 2.5” DOUBLE CLIP DRAIN SADDLE FAUCET ADAPTER 3/8” OD PLUG IN ELBOW 1/4” OD PLUG PRESSURE TANK VALVE 3/8”...
- Page 10 10. Dry the system and undersink area with a towel and inspect for leaks 11. You can now continue to use the AquaLiv system normally. After a bit of use, some air will exit the faucet. This is normal. A bit later you may notice an off-taste. At this point, open the AquaLiv faucet and let the system run until water slows to a trickle, then close the faucet and allow the system to fill (1-2 hours) before using again.
