Appendix C: Certification Information
C.3.3 Noise
The shield of the RJ45 connector is not connected to FE. To pass the CC-Link IE Field noise
test, the Ethernet cable shield has to be connected to the chassis ground at each port.
C.4

CSP+ File Customization

An generic CSP+ file is provided by HMS Industrial Networks AB. This file is based on the ex-
ample application that follows with the Anybus CompactCom 40 Starter Kit, but can be used as
a basis for customizing to any other host application. A tool, "Profile Creation Tool", for modify-
ing the file is available at the CLPA web page (www.cc-link.org, membership is required). Also
available at the CLPA web page is a document containing guidelines for creating CSP+ files,
CC-Link Family System Profile (CSP+) Creation Guidelines.
Open the example file with the Profile Creation Tool, and change the entries given below. The
entries will show as described in the GX Works 2 PLC and network configuration tool.
C.4.1 Fileinfo
In the "Fileinfo" section of the CSP+ file, change the following entries:
• ModDate
• ModTime
C.4.2 DeviceInfo
In the "DeviceInfo" section of the CSP+ file, change the following entries:
Entry
VendorName
DeviceModel
VendorCode
Product ID
Version
DeviceTypeID
C.4.3 CommIfInfo
The "CommIFInfo" section of the CSP+ file, identifies the communcation interface information
list. Change the following entries:
®
Anybus CompactCom ™ 40 CC-Link IE Field Network Guide
Description
Vendor name
Device model name.
The code assigned by CLPA (taken
from the member number).
The device product code (vendor
specific),
Version of the network interface.
Changed when network functionality
change
Defines the profile used for the de-
vice in the GX Works Module list
under your vendor name. PLC corre-
sponds to 0x0001, Generic Device
corresponds to 0x007F).
Note
All devices will be listed under this vendor
name in the Module List window in GX Works
2.
Defines the device model name in the Module
list under the CC IE Field Configuration Mod-
ule window in GX Works 2.
These settings shall comply with any setting
don in the CC-Link Field Network Host Object
(E6h) in the application. The settings are not
validated against the setting in the CSP+ file,
but never the less shall comply. They are vali-
dated in a conformance test.
