OPERATING MANUAL
Thank you for purchasing a TANACOM BULL 1000. To take full advantage of the
reels many useful functions, please read this manual carefully before using. Retain
this manual for future reference.
Reference
Reference

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TanacomBull 1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Daiwa TanacomBull 1000

Summary of Contents for Daiwa TanacomBull 1000

  • Page 1 OPERATING MANUAL Thank you for purchasing a TANACOM BULL 1000. To take full advantage of the reels many useful functions, please read this manual carefully before using. Retain this manual for future reference. Reference Reference...

  • Page 2: Table Of Contents

    Index Caution Useful functions   Various alarms   Precautions   Display light Power source   Breaker display   How to connect the reel to the power source   About the power source Reel Specification   Battery checking displays   Reel Specification list   Counter display Using the Reel   About the counter display Parts List Maintenance Trouble shooting...

  • Page 3: Caution

    Caution Precautions 1. Be careful to keep fingers clear of the levelwind mechanism. It can pinch your fingers and cause injuries. 1. If your sinker or lure is caught on the bottom, cut your line rather than jerk the rod to free it.

  • Page 4: Power Source

    Power source Black How to connect the reel to the power source Attach the cord clips to the battery. Red covered clip is the plus (+), and the black covered clip is the minus (-). Insert the connector into the reel. After this, the display appears as below.

  • Page 5: Using The Reel

    Using the Reel Do not jerk your rod to free a lure or sinker stuck on the bottom. Pull the line taught with a gloved hand and cut it. After maintenance, be sure to loosen the drag and store the reel in a dry place.

  • Page 6: Maintenance

    Maintenance About maintenance This is a washable reel. Wash away salt residue and grit after fishing. Maintenance procedure Wash the reel with a dish washing detergent and a soft sponge. Do not use solvents. Do not use soap or other detergents. Other soaps or solutions may damage the reel both externally and internally.

  • Page 7: Handling And Maintenance Of The Power Cord

    Maintenance Handling and maintenance of the power cord Follow the restrictions below to avoid cord problems. Do not cut or connect your cord by yourself as it can cause unintended problems. Do not hang the reel Do not wind the power by the power cord.

  • Page 8: Names Of The Buttons And The Display

    Names of the buttons and the display MODE BUTTON RESET BUTTON INVERSE COUNTER BUTTON JIG/PICKUP BUTTON Mode display Depth counter Chumming timer (Power indicator, time to wind up, timer display) Jigging display Inverse counter (winding speed display)

  • Page 9: Names Of The Buttons And The Display

    Names of the buttons and the display   MODE BUTTON Press the MODE BUTTON to scroll through the adjustment displays for each reel function. - Use the Power Lever to adjust numeric values. - Pressing the MODE BUTTON sets the numeric values you have adjusted. - Depress and hold the MODE BUTTON to return to the depth display.

  • Page 10: Names And Functions Of Each Part

    Names and functions of each part Free spool adjustment weak strong Power lever loosen tighten Waterproof drag Clutch Levelwind Enclosed items Storage bag Manual CD-R Power cord Levelwind threader Rod Clamp ...

  • Page 11: Names And Functions Of Each Part

    Names and functions of each part Free spool adjustment    - It adjusts brake tension on the spool to prevent backlash or line slack caused by dropping the line with hook and sinker.    Power lever - You can freely adjust winding power, or winding speed, from zero(ON/OFF) to maximum, by 32 steps, by using the lever.

  • Page 12: Line Data Input

    Line data input (When line length is known) This method is used when the line length is known before winding. In the example below, PE 6 – 1000m is wound. Levelwind Guide Run line through the levelwind guide and tie it onto the spool. Main line The levelwind threader makes this process easier.

  • Page 13: Line Data Input

    Line data input (When line length is known) Pull the lever back to the OFF position, after winding. 1.Do not wind the end of the line onto the spool because it causes incorrect length calculation. Move the power lever to OFF, and wind manually when nearing the end of the line.
  • Page 14 Line data input (With backing line) This method requires use of Daiwa braided line that is color coded to show length and has a total length greater than 100 m. Levelwind Guide Run the backing line through the levelwind guide and tie it onto Main line the spool.
  • Page 15 Line data input (With backing line) As indicated by the lineʼs color coding, wind the line up until the remaining line is 100m.  With the power lever moved forward, changes into a tension indicator. Keep line tension between 5 and 7 while winding. 1.Do not allow line to rub against the finger guard while winding as it will scratch the guard.
  • Page 16 Line data input (Backing line 2) This procedure is to enter the line length after it has been wound onto the reel. It is necessary that you know the line length and that it is greater than 100m. Connect the battery to the reel. Press the MODE SET BUTTON for 5 seconds, changing the...
  • Page 17 Line data input (Backing line 2) Pull an additional 50m of line from the spool. Press the RESET BUTTON for 2 seconds to show 100.0 the upper counter. Wind up the 100m of line you pulled from the reel. This completes the procedure.
  • Page 18 Functional setting operation (1. Mode setting display) How to set the many functions available 1.There are many useful functions in the mode 2.Use the power lever to change numerical values on the setting displays for each function. Complete your adjustments and lock in the values by pressing the MODE BUTTON. Press the MODE BUTTON to choose a display.
  • Page 19 Functional setting operation (1. Mode setting display) Use the power lever to set numerical values. Power lever  At its MAX position, numbers count upward rapidly. At the OFF position, numbers count downward rapidly.  Around mid position, numbers change at a slower pace. Press MODE BUTTON to complete the setting.

  • Page 20: Surface Depth Setting

    Functional setting operation (2. Before you begin fishing.) Surface depth setting Before you begin fishing, make sure the counter is set to zero at the waterʼs surface. This is extremely important to ensure accurate fishing depth readings. Connect the reel to the battery, put the line through all the guides, and prepare your terminal rig.

  • Page 21: Auto Stop Setting

    Functional setting operation (3. Auto stop function) Auto stop setting The Auto stop depth may be set to meet your own specific needs. - Auto stop adjusts to operate at depths from 1 m to 5 m (in 10 cm increments). - It prevents accidentally winding swivels, terminal rigs etc.

  • Page 22: Line Feeding Function

    Functional setting operation (4. Line feeding function) Line feeding function The line feeding function lets our line with the motor assisting the spool. - The line feeding mechanism begins to work at a depth of 2.5 m below the pre-set auto stop depth. - If the clutch becomes ON while the reel is furnishing line, the spool begins to rotate to avoid line slack.
  • Page 23 Functional setting operation (5. Pickup speed setting) Pickup speed preference Press MODE BUTTON. If the display is at display, then move the power lever or press RESET BUTTON to show the display shown on the right. Press MODE BUTTON again. This display is the pickup setting display.

  • Page 24: Inverse Counter

    Functional setting operation (6. Inverse counter) Inverse counter Two counters are better than one. This reel has counters from both the surface and from the bottom. The default inverse counter setting is OFF. To turn it ON, see page 26. In the following example, intended fishing range is 94 m, which is 6 m from the bottom.

  • Page 25: Jigging

    Functional setting operation (7. Jigging) Jigging Jigging is an extremely valuable function. After setting your preferences, pressing the JIG/PICKUP BUTTON starts the function. Speed of the jigging can be adjusted with the power lever. Press the MODE BUTTON to show pickup / jigging display. (When jigging is chosen, the pickup function cannot be used.) Jig/pickup Jigging pattern is selected with the power lever.

  • Page 26: Jigging

    Functional setting operation (7. Jigging) Jigging master You can choose the jigging pattern, range, waiting time and length you require. - Pressing the JIG/PICKUP BUTTON, starts jigging, with the display showing the indicator. (Pressing the button once more cease jigging.) The power lever controls jigging speed. - Shifting of jigging speed is done easily with the lever control.

  • Page 27: Jigging

    Functional setting operation (7. Jigging) 3. Waiting time You can choose the waiting time between jigs. The interval time is set in seconds. Example) Three-step jigging Three-step jigging (Preference setting) 5 seconds interval time Interval time (5sec) Three-step jigging Interval time (5sec) (Shown is the interval time set to 5 sec)

  • Page 28: Winding Speed Indicator

    Functional setting operation (8. Winding speed indicator) Winding speed display In the default setting, the lower area counter displays the winding speed. The chumming timer display area shows the remaining time until the auto stop is reached. (p. 27) The inverse counter numbers can be changed to indicate winding speed.

  • Page 29: Remaining Time To Auto Stop

    Functional setting operation (9. Remaining time to auto stop) Displaying of the remaining time to auto stop Two counters are better than one. This reel has counters from both the surface and from the bottom. When the display is set to indicate the actual speed, the chumming timer display portion indicates the remaining time before it reaches the auto stop position.

  • Page 30: Chumming Timer Winding

    Functional setting operation (10. Chumming timer winding) Chumming timer winding The right timing for the best results. After a pre-determined amount of time has passed, the reel starts winding automatically. - After pre-set 5 minutes have passed, the reel automatically winds up.

  • Page 31: Chumming Timer Winding

    Functional setting operation (10. Chumming timer winding) Press MODE BUTTON twice. - When the display goes back to depth counter, then the procedure is completed. - The     indicator is seen on the display. - The time set can be checked by pressing the INVERSE COUNTER BUTTON.

  • Page 32: Display Recalibration

    Functional setting operation (11. Display recalibration) Display revision You can recalibrate the counter should it not indicate an accurate depth compared to depth markings on your line. Example below is the case in which, though the counter shows 103 m, color markings on the line indicate 100 m. Press MODE BUTTON six times to show on the display real...

  • Page 33: How To Fix The Rod Clamp

    Functional setting operation (12. How to fix the Rod Clamp) When you use a metallic bat or for your fishing of a big charge, you should always utilize the Rod Clamp. (sing the Rod Clamp, it is possible to cramp rods with diameter up to 25-34mm) Insert the Bolt in the clamp setting hole, and fix it by tightening the Nut and the Washer.

  • Page 34: Useful Functions

    Useful functions Various alarms Many kinds of information are indicated by audible alarms. Power lever alarm - Placing the Power lever at MAX or OFF positions evokes an alarm. Auto stop alarm - While winding up, starting 6 m below the auto stop depth, an alarm beeps at two meter intervals. Upon reaching the auto stop depth, a long alarm sounds.

  • Page 35: Reel Specification

    Product name TANACOM BULL 1000 Product code 40801001 Gear ratio(manual winding) 2.3 : 1 Weight (g/oz) 1530 g / 54 oz Max Drag power (kg/lb) 22kg/48lb Line Capacity (m) DAIWA BRAIDED MONO BRAIDED PE6(80lb)-1000m(1100yds) 30lb-700m(770yds) 60lb-1000m(1100yds) PE8(100lb)-800m(880yds) 40lb-500m(550yds) 80lb-800m(880yds) PE10(120lb)-600m(660yds) 100lb-600m(660yds)

  • Page 36: Parts List

    Parts List TANACOM BULL1000 (Separate sale) TANACOM BULL1000 Parts No, Parts Name Parts No, Parts Name Parts No, Parts Name 6G379906 IC MODULE L/S PLATE SET 6G811801 MOTOR GEAR(D) 63538705 R/S PLATE SCREW(A) 6E033201 BRAKE CLICK SPRING 6G156801 MOTOR GEAR(D) BALL BEARING 6G405901 R/S PLATE SCREW(B) 6E489621...

  • Page 37: Trouble Shooting

    Trouble shooting Ref. Symptom Possible causes To do page It is a normal function to avoid over The counter displays winding. Press RESET BUTTON 19,20 continue winding. Motor does not Pull the lever to OFF and then move Did not pull the lever to OFF respond to the forward again to start winding.
  • Page 38 DAIWA CORPORATION NAME 12851 MIDWAY PLACE ADDRESS CERRITOS CA 90703 U.S.A (562)-802-9589 TEL NO. COMPANY DAIWA SPORTS LIMITED NAME NETHERTON INDUSTRIAL ESTATE ADDRESS WISHAW ML2 OEY STRATHCLYDE SCOTLAND U.K. TEL NO. 01698 355723 or 01698 357512 COMPANY DAIWA FRANCE S.A.S...
