Wireless Entertainment System
Model xTV-9T Transmitter
Model xTV-9R Receiver
Operation Manual
20031 142nd Ave. NE, P.O. Box 7202
Woodinville, WA 98072-4002
Sales (800) 227-3461
Fax (425) 486-3856
www.cardiotheater.com
www.enercise.tv
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
in
terference, and (2) this device must accept any interference received
,
inclu
ding interference that may cause undesired operat
ion.
Advertisement
Table of Contents
Related Manuals for Cardio Theater xTV-9T
Summary of Contents for Cardio Theater xTV-9T
- Page 1 Wireless Entertainment System Model xTV-9T Transmitter Model xTV-9R Receiver Operation Manual 20031 142nd Ave. NE, P.O. Box 7202 Woodinville, WA 98072-4002 Sales (800) 227-3461 Fax (425) 486-3856 www.cardiotheater.com www.enercise.tv FCC NOTICE This device complies with Part 15 of the FCC Rules. Operation is subject to...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Step 1: Setting Transmitter Number USA & Canada Mode Page 1 Australia Mode Page 2 Step 2: Connecting Transmitter to TV Page 3 Step 3: Installing Receiver Page 4 Step 4: Programming Receiver Page 5 Specifications Page 6 Warranty / Technical Support Page 7-8... -
Page 3: Step 1: Setting Transmitter Number Usa & Canada Mode
STEP 1: SETTING TRANSMITTER NUMBER / USA & CANADA MODE Simply set the left and right dials on the rear of the transmitter to the corresponding numbers below. Example: For Transmitter #1 set left dial to “0” and right dial to “1” Transmitter Left Dial Right Dial... -
Page 4: Australia Mode
STEP 1: SETTING TRANSMITTER NUMBER / AUSTRALIA MODE Warning! End user is responsible for following the number chart below for use in Australia. Setting Transmitter dials to any other number than the ones detailed in the chart below may result in fines and or additional punishment by local authorities. -
Page 5: Step 2: Connecting Transmitter To Tv
TV. 8. Place corresponding number sign under each TV CONNECTING THE xTV-9T TRANSMITTER TO MUSIC COMPONENT: 1. Connect provided patch cable into Left & Right Audio Output Jack on rear of music component and follow steps 2 through 8 above. -
Page 6: Step 3: Installing Receiver
STEP 3: INSTALLING RECEIVER Mounting Receiver The Enercise xTV Receiver is designed to mount to any make or model of cardio equipment. 1. Insert two nylon wire ties (provided) through the holes in the mounting bracket on the rear of the Enercise xTV Receiver. 2. -
Page 7: Step 4: Programming Receiver
3. When Scanning is completed, press channel Up and Down buttons to confirm all transmitters have been programmed. Cardio Theater™ LCS Program Mode (When Using LCS Transmitters): 1. Press Volume "UP & DOWN" simultaneously for 3 seconds. The number 1 With a decimal point on the left side will pop up in display window 2. -
Page 8: Specifications
XTV-9T Specifications Input Sensitivity 100 to 1 volt Input Impedance 10K ohms Level Gain Control -70 dBm to + 10dBm Transmission Frequency 905MHz to 925.6MHz Signal to Noise -70 dBm ref .7 volts RF Output 0.48 mW EIRP Distortion <2 %. - Page 9 Cardio Theater, a return authorization number will be issued. Cardio Theater will not accept returns without a return authorization number. Cardio Theater reserves the right, at their option, to repair or replace the equipment after verification of defect.
-
Page 10: Warranty / Technical Support
20031 142nd Ave. NE, P.O. Box 7202 Woodinville, WA 98072-4002 Notice Due to continuing advancements in technology, Cardio Theater reserves the right to make changes in hardware, packaging, and any accompanying documentation without prior written notice. © 2003 Cardio Theater Holdings, Inc., all rights reserved...
