- Page 1 Installation Guide S95xx Duak Stack Ethernet Switch Manual version: 2.0.04 Firmware version: 6.2.98.0 FoxGate 2012...
-
Page 2: Table Of Contents
Content Content ..................... 2 1.1 O VERVIEW ..............2 1.2 I NTRODUCTION TO RODUCT 1.2.1 Product Overview ..................2 1.2.2 Features and Benefits ..................2 ..............4 1.3 P HYSICAL PECIFICATIONS ..............4 1.4 D ESCRIPTION OF ARDWARE 1.4.1 Front Panel ....................4 1.4.2 Back Panel ..................... -
Page 3: Overview
1.2.2 Features and Benefits Various Interfaces S9524-GS12M2 provides 12 1000Mb fiber ports, 12 1000Mb Combo ports (1000Mb fiber SFP ports/1000Mb copper ports) and 2 slots with the extended cards. S9548-GS4M2 provides 44 fixed 1000Mb fiber ports, 4 1000Mb Combo ports (1000Mb fiber SFP ports/1000Mb copper ports) and 2 slots with the extended cards. -
Page 4: Networking Protocols
S95xx series are up to the mustard of Self-defending security region management strategy according to FoxGate. It is supported interaction with some security system such as firewall, IDS, etc. It can defense the virus and aggress effectively from the extranet and internet. Thus enhance the security and stability of the network-wide. -
Page 5: Physical Specifications
Table 1-1 Physical Specifications 1.4 Description of Hardware 1.4.1 Front Panel S9524-GS12M2 Ethernet switch provides 12 1000Mb fiber ports, 12 1000Mb Combo ports, 8 function LEDs and 1 Console port. Fig 1-7 Front Panel of S9524-GS12M2 S9548-GS4M2 ehternet switch provides 44 1000Mb fiber ports, 4 1000Mb Combo ports, 8... -
Page 6: Back Panel
1 interface with 220V AC power input. Fig 1-16 Back Panel of S9524-GS12M2 Back Panel of S9548-GS4M2 is same with S9524-GS12M2, it supplies 2 interfaces for the extended card, 1 interface with -48V DC power input and 1 interface with 220V AC power input. -
Page 7: Status Leds
RJ45 linker, the number is from 1 to 4, and they correspond four ports of RJ45 linker respectively. The other of its kind is system LEDs, system LEDs of S9524-GS12M2 and S9548-GS4M2 are at the right of the front panel. They are corresponding name for system LEDs with 2*4 array. -
Page 8: Front Panel Interface Description
Introduction Table 1-6 System LEDs Panel Symbol Status Description On (Green) Power is operating normally Power is abnormally On (Green, blink) System is loading DIAG On (Green) System is operating normally On (Green) System is malfunctioning System is operating normally On (Green) System is using DC power System does not use DC power... -
Page 9: M9000-2X / M9000-2S+ / M9000-2S Extended Module Description
Introduction Table 1-7 S9548 interface description Port mode Spec RJ-45 port 10/100/1000Mbps auto negotiation MDI/MDI-X cable mode auto negotiation 5 kinds of UTP: 100 m SFP-SX-L transceiver 1000Base-SX SFP(850nm,MMF,550m) SFP-LX-L transceiver 1000Base-LX SFP(1310nm, SMF, 10km or MMF, 550m) ... - Page 10 Figure 1-22 panel diagram of M9000-2S+ Figure 1-23 panel diagram of M9000-2S Back panel diagram of the switch with extended modules is shown in the following: Figure 1-27 The back panel with extended modules for S9524-GS12M2 / S9548-GS4M2 Extended module„s LED description is the following:...
- Page 11 Introduction Table 1-8 10Gb extended module LED description Status Description Green Ports are at the link state of 10G Link/Activity Blink(Green) Ports are at the active state of 10G No link or the link is failure S95xx series switch supports the following XFP, SFP+ transceivers: Table 1-9 S95xx series XFP, SFP+ transceivers description Spec ...
-
Page 12: Installation Notice
Hardware Installation Chapter 2 Hardware Installation 2.1 Installation Notice To ensure the proper operation of S95xx series and your physical security, please read carefully the following installation guide. 2.1.1 Environmental Requirements The switch must be installed in a clean area. Otherwise, the switch may be damaged by electrostatic adherence. -
Page 13: Temperature And Humidity
Hardware Installation such as SO S, NO , NH and Cl , etc. The table below details the threshold value. Average (mg/m³) Max (mg/m³) 0.006 0.03 0.04 0.15 0.05 0.15 0.01 Table 2-2 Environmental Requirements: Particles 2.1.1.2 Temperature and Humidity Although the switch is designed to use 4 fans, the site should still maintain a desirable temperature and humidity. -
Page 14: Preventing Electrostatic Discharge Damage
Hardware Installation 2.1.1.3 Power Supply Before powering on the power supply, please check the power input to ensure proper grounding of the power supply system. The input source for the switch should be reliable and secure; a voltage adaptor can be used if necessary. The building‟s circuit protection system should include in the circuit a fuse or circuit-breaker of no greater than 240 V, 10 A. -
Page 15: Installation Notice
Hardware Installation Caution！ If a standard 19‟‟ rack is not available, the S95xx series can be placed on a clean level desktop, leave a clearance of 100mm around the switch for ventilation, and do not place anything on top of the switch. 2.1.2 Installation Notice ... -
Page 16: Installation Preparation
Hardware Installation 2.2 Installation Preparation 2.2.1 Verify the Package Contents Please unpack the shipping package and verify carefully the contents inside. 2.2.2 Required Tools and Utilities The required tools and utilities are shown below: Cross screwdrivers Flat-blade screwdriver ... -
Page 17: Connecting Console
Hardware Installation series installation sketch map on the rack Fig 2-2 S9548 Please mount S95xx series on the 19‟‟ rack as below: 1. Attach the 2 brackets on the S95xx series with screws provided in the accessory kit. 2. Put the bracket-mounted switch smoothly into a standard 19‟‟ rack. Fasten the S95xx series to the rack with the screws provided. -
Page 18: Sfp Transceiver Installation
Hardware Installation The connection procedure is listed below: Find the console cable provided in the accessory kit. Attach the Mini-USB end to console port of the switch. Connect the other side of the console cable to a character terminal (PC). Power on the switch and the character terminal. -
Page 19: M9000-2S+ Extended Module Installation
Hardware Installation 2.3.5 M9000-2S+ extended module Installation S95xx series provide 10Gb slots. The procedure for installing the M9000-2S+ module and the SFP+ 10Gb fiber transceiver is shown below: Step 1: Put on an ESD wrist strap (or antistatic gloves). Step 2: Insert the M9000-2S+ module to the guide rail inside the 10Gb module slot. Step 3: Push the M9000-2S+ module along the guide rail gently until it comes into contact with the machine panel. -
Page 20: Ac Power Supply Connection
Hardware Installation Step 1: Insert one end of the Ethernet cable to the RJ-45 Ethernet port in the switch copper cable line card; Step 2: Insert the other end of the Ethernet cable to the RJ-45 Ethernet port of other device; Step 3: Check all status indicators for the corresponding ports;... -
Page 21: Dc Power Supply Connection
Hardware Installation 3. When the switch is powered on, it executes self-test procedure and startups. Caution! The input voltage must be within the required range, otherwise the switch can be damaged or malfunction. Do not open the switch shell without permission. It can cause physical injury. 2.3.9 DC Power Supply Connection Please read the power input specification for the detailed information.
