Page 1: User Manual
16/24 Ports Managed PoE Ethernet Switch 16/24FE POE+2GE User Manual... - Page 2 Preface The user manual mainly introduces the product shape, product positioning, hardware installation, Web management and other related information. Illustration (1)Format of Graphics Interface Format Description < > “<>”means button name， such as “click <Confirm> button”. “[ ]”means window name, menu name and data table, such as“pop out [New user] window”.
-
Page 3: Table Of Contents
Content 1 Product Introduction Management 4 Web . System Status Overview 4.2 Port Configuration Product Feature Board Diagram 4.2.1 Port Settings Specification 4.2.2 Port speed limited . VLAN Setting Installation 4.3.1 VLAN Configuration Shipping List 4.3.2 4.3.2 VLAN forwarding Installation Precautions . -
Page 4: Product Introduction 1 4 Web
1 Product Introduction Back panel 1 1 O verview This item is a 16/24-port managed PoE Ethernet switch, which provides 16/24*100Mbps downlink PoE Ethernet ports, supports IEEE802.3 af/ at and 2*1000Mpbs uplink Ethernet ports. It supports Layer 2 network management and PoE management based on web and provides high-speed data forwarding. -
Page 5: 4 . Specification
1.4 Specification 2 Installation Item Description Caution 16 Ports PoE Ethernet 24 Ports PoE Ethernet Products Products Switch Switch Anti-counterfeiting label is attached to switch's cover. Product damage Power Supply Mains on load caused by unauthorized disassembly is not covered under warranty. ～... -
Page 6: Installation Requirements
2 3 . Installation Way Pull out the power plug before cleaning the switch. Do not use wet cloth nor liquid to wipe or wash the switch; There are 3 installation ways: rack, workbench and wall-hung installation. Do not leave the switch close to water or wet place so as to prevent water or dampness from entering into the switch;... -
Page 7: Workbench Installation
Figure 2-3 Hangers installation diagram (2) Drill holes on the strong position of wall and then drive the rubber plug into the hole; (3) Drive these screws into the hole for the rack and fix the product by aiming at the rubber plug . -
Page 8: 4 . Cable Connection
3 Function Configuration Guide 2.4 Cable Connection 3. 1 Computer Requirements 2 4 1 . . Device Connection U s e c r o s s n e t w o r k c a b l e o r c r o s s - o v e r c a b l e t o c o n n e c t P C o r Make sure the management PC has already been installed with Ethernet adapter;... -
Page 9: Confirm The Network Connection By Ping Command
3.2.2 Confirm the Network Connection by Ping Command (2) Click <property> button, enter "local connection property" window. Operation Steps below: (1) Click <Start> button to enter [Start] menu, select [Run], pop out the dialog. (2) Input "ping 192.168.1.200", click <confirm> button. If there is equipment response show in the pop out dialog, that means network connection succeed, otherwise please check if the network... -
Page 10: 3 . Web Page Configuration Guide
(2) Select “connection” tabs in [Internet Caution option] window, and click [LAN Setting] button. Please follow the steps to check if the switch is installed correctly: (1) Whether the physical connection of the equipment is correct? Use network line to connect the product’s each port with managed computer network card, and ensure the link LED of the port is on. -
Page 11: Common Buttons Introduction
Table 3-2 Default Configuration Options Default Configuration Web English language switching page diagram Username / password admin/admin 3.3.3 Common Buttons Introduction IP Address：192.168.1.200 System IP Address Subnet Mask：255.255.255.0 Table 3-1 Web commonly used function buttons introduction MAC address table aging 300 Seconds time Button... -
Page 12: Restoring The Configuration Information
4 Web Management 3 3 . .5 Web User Timeout When you have left the Web setting page for a while, the system will log out and 4.1 System Status return to the Web dialog box due to system time-out. Please log in again if you want to proceed the operation. -
Page 13: Port Configuration
4.2 Port Configuration Specification Description Display the data forwarding of the port. If a port is off, you Port Enable / 4.2.1 Port setting Disable can not forward the data. Enabled by default. Display the port configuration’s speed rate, including 10M, 16 port switch panel silkscreen port and Web port corresponding table... -
Page 14: Vlan Setting
4.3 VLAN Setting 4 2 . .2 ort speed limit The Equipment provides port- based entry speed limit. Users can restrict Switch supports two VLAN modes: every port traffic flows or cancel port flow restrictions . Users can choose a (1) Port-based VLAN mode: define VLAN members according to device port. -
Page 15: Vlan Forwarding
Configuration Guide： Caution Such as if port 1-10 has connected to a switch respectively, it is necessary to divided port 1-10 into VLAN 20. The default port VLAN and allowed VLAN must be existed VLAN. Enter 1-10 within the port range(or click on the box in front of the ports); Choose Trunk on the menu(Switches connection is generally used with 4. -
Page 16: Rstp
4. .2 RSTP 4.4.2.1 RSTP Uses STP (Spanning Tree Protocol) is established in accordance with IEEE 802.1D standard. It is developed for the elimination of the data link layer loops in the LAN protocol. Devices running this protocol exchange packets with each other to find loops in the network, and choose to block some certain ports. - Page 17 Table 4-7 Designated port status Classification Designated Bridge Designated Port Equipment connecting directly Port used by with switch and responsible to designated bridge to For equipment transfer BPDU message to transfer BPDU switch message to switch Port used by Responsible to transfer designated bridge to Figure 4-6 RSTP For LAN...
-
Page 18: Port Security
Configuration guide： Parameters Description Enable RSTP function to avoid broadcast storm caused by looped network Static MAC address differs from the general dynamic MAC structure among switch A , switch B and switch C 1- 10 port. address. Once a static address is added, the address will MAC Address remain in effect until be deleted and free the maximum aging Enable... -
Page 19: Web Management
In [port security / 802.1X authentication] page, you can modify / 802.1X configuration Guide ： authentication function set, as shown in figure 4-8: EX: Setting port 1-10 to compulsory licensing model, the maximum number of users to 10. Start using 802.1x Certification； Ports Scope choose1-10，... -
Page 20: Email Alarm
Figure 4-10 Email alarm The meanings of main parameters of the pages are as below table. Table 4-12 Parameters description Figure 4-9 SNMP Schematic configuration Parameters Description The meaning of main parameters of the pages are as below. The host computer’s IP address or the host computer that Mail Server Table 4-11 Parameter description provide POP3 mail delivery service to our devices. -
Page 21: Port Mirror
Configuration Guidance: Caution Such as port 3 monitor port 2 Import data traffic Some email service system requires that the " email reply address" Open Port Mirror; should match the"email account”; when sending system test email, the Input3 on monitor port, input 2 on mirror Port, Data collection selected from password should be in plain text. -
Page 22: Network Statistics
Parameter Description Parameters Description IGMP Snooping Opening and Closing Multicast Snooping function ,Default The r eceived address is the number of packets in Receive Frame singlecast On/Off is Close. Package the unicast address. IGMP Inquiry Open IGMP Multicast Inquiry function The received address is the number of packets in Receive Frame multicast... -
Page 23: System Management
The main parameter description are shown as the table. 4.8.2 User Management Table 4-16 Main parameter On this page, you could modify or add one user with password . as figure 4-16. Parameter Description Inquiry by physical Enter detailed physical MAC address to check. port Inquiry by MAC MAC address type consists of static MAC address and... -
Page 24: Log Information
4.8.3 og Information 4.8.4 File Management On [ System management/ File management] page，You could check The log function allows users to access system operation, When this function is configure document, software upgrade, restore factory setting and reboot enabled, corresponding events are recorded to the log: system as shown in the figure 4-18. -
Page 25: Poe Management
4.9 PoE Management Parameter Description Power Determined by built-in power supply module and can not On PoE management page, you could turn on/ off PoE function, set input provided exceed maximum power supply. power , maximum overload, reservation power etc, as shown in figure 4-19 Built-in power supply allows overload rate. -
Page 26: Qos Management
4.10 QoS Management 4.10.2 DSCP/TOS QoS [QoS Setting/ DSCP/TOS QoS] Interface，can modify the setting DSCP/TOS 4.10.1 QoS setting QoS]，figure 4-21 On the QoS management/QoS Settings page, you can modify / 802.1 P QoS function setting, as shown in figure 4-20. Figure 4 - 20 802.1P QoS Figure 4 - 21 DSCP / TOS QoS The meaning of parameters in the page is shown in the following table. - Page 27 Environment protection This product design is environmental friendly and the product should be stored, used and dicarded in accordance with relevant national legal / regulatory requirements.
