- Page 1 Installation Guide S98xx Dual Stack 10G Ethernet Optical Routing Switch Manual version: 2.0.5 Firmware version: 6.2.139.18 FoxGate 2012...
-
Page 2: Table Of Contents
Content Content CONTENT ..................1 1. INTRODUCTION ............... 3 1.1 O ..................... 3 VERVIEW 1.2 I ..............3 NTRODUCTION TO RODUCT 1.2.1 Product Overview ..................3 1.2.2 Features and Benefits................3 1.3 P ..............5 HYSICAL PECIFICATIONS 1.4 D ..............5 ESCRIPTION OF ARDWARE 1.4.1 Front Panel .................... - Page 3 Content 2.3.7 Copper Cable/Fiber Cable Connection ..........20 2.3.8 AC Power Supply Connection ..............21 2.3.9 DC Power Supply Connection ..............21 2.3.10 PoE Power Supply Connection ............22...
-
Page 4: Introduction
S9824-GS12M2 provides 12 1000Mb fiber ports, 12 1000Mb Combo ports (1000Mb fiber SFP ports/1000Mb copper ports) and 2 slots with the extended cards. S9848-GS4M2 provides 44 fixed 1000Mb fiber ports, 4 1000Mb Combo ports (1000Mb fiber SFP ports/1000Mb copper ports) and 2 slots with the extended cards. -
Page 5: Networking Protocols
Introduction CSMA/CD protocol, is a big leap in the evolution of Ethernet. 10Gb Ethernet can be deployed in star or ring topologies. S98xx switches provide broad bandwidth and powerful processing capacity. It is suitable for metropolitan networks and wide area networks. Using S98xx switches, users can simplify network structures and reduce cost of network construction. -
Page 6: Physical Specifications
S9824-GS12M2 Ethernet switch provides 12 1000Mb fiber ports, 12 1000Mb Combo ports, 8 function LEDs and 1 Console port. Fig 1-7 Front Panel of S9824-GS12M2 S9848-GS4M2 ehternet switch provides 44 1000Mb fiber ports, 4 1000Mb Combo ports, 8 function LEDs and 1 Console port. -
Page 7: Back Panel
Fig 1-15 Back S9824-GS12M2 Panel of Back Panel of S9848-GS4M2 is same with S9824-GS12M2, it supplies 2 interfaces for the extended card, 1 interface with -48V DC power input and 1 interface with 220V AC power input. Fig 1-16 Back... -
Page 8: Status Leds
Blink Send or receive the data Note: For S9848-GS4M2, there are four LEDs with the number from the buttom up on the left of RJ45 linker, the number is from 1 to 4, and they correspond four ports of RJ45 linker respectively. -
Page 9: Interface Description Of Front Panel
Introduction Table 1-6 S9824-GS12M2 / S9848-GS4M2 System LEDs Panel Status Description Symbol On (Green) Power is operating normally Power is abnormally On (Green, blink) System is loading DIAG On (Green) System is operating normally On (Green) System is malfunctioning System is operating normally... -
Page 10: M9000-2X/M9000-2S+ Extended Module Description
Introduction Table 1-7 interface descriptions Interface mode Spec RJ-45 port 10/100/1000Mbps auto negotiation MDI/MDI-X cable mode auto negotiation 5 kinds of UTP: 100 m SFP-SX-L transceiver 1000Base-SX SFP(850nm,MMF,550m) SFP-LX-L transceiver 1000Base-LX SFP(1310nm, SMF, 10km or MMF, 550m) ... - Page 11 Figure 1-20 panel diagram of M9000-2X Figure 1-21 panel diagram of M9000-2S+ Figure 1-22 panel diagram of M9000-2S Back panel diagrams of switch with extended modules are shown as follows: Figure 1-26 The back panel with extended modules for S9824-GS12M2 / S9848-GS4M2...
- Page 12 Introduction Extended module„s LED descriptions are in the following: Table 1-8 LED descriptions of 10Gb extended module Status Description Green Ports are at link state with 10G Link/Activity Blink(Green) Ports are at active state with 10G No link or the link is failure Table 1-9 XFP, SFP+ transceivers descriptions of S98xx Spec ...
-
Page 13: Hardware Installation
Hardware Installation 2. Hardware Installation 2.1 Installation Notice To ensure the proper operation for S98xx and your physical security, please read carefully the following installation guide. 2.1.1 Environmental Requirements The switch must be installed in a clean area. Otherwise, the switch may be damaged by electrostatic adherence. - Page 14 Hardware Installation harmful gases will aggravate metal corrosion and the aging of some parts. The site should avoid harmful gases, such as SO S, NO , NH and Cl , etc. The table below details the threshold value. Average (mg/m³) Max (mg/m³) 0.006 0.03...
- Page 15 Hardware Installation may occur during an air-conditioning system failure, and normal operation conditions should be recovered within 5 hours. 2.1.1.3 Power Supply Before powering on the power supply, please check the power input to ensure proper grounding of the power supply system. The input source for the switch should be reliable and secure;...
-
Page 16: Installation Notice
Hardware Installation please ensure good ventilation for the rack. Every device in the rack will generate heat during operation, therefore vent and fans must be provided for an enclosed rack, and devices should not be stacked closely. When mounting devices in an open rack, care should be taken to prevent the rack frame from obstructing the switch ventilation openings. -
Page 17: Installation Preparation
Hardware Installation power immediately. Caution! Potential risk include: Electric leakage, Power supply arcing, Power line breakage, Imperfect earth, Overload circuit and Electrical short circuit. If electric shock, fire, electrical short circuit occurs, please cut off the electricity supply and alarm rapidly. Rescue the injured person in the contingency under inherently safe, give the injured person proper first aid treatment according to the injury state, and seek help from the Medical Emergency using various ways. -
Page 18: Installation Guide
Hardware Installation 2.3 Installation Guide 2.3.1 Installing Switch Fig 2-1 Install sketch map on the rack Please mount S98xx on the 19‟‟ rack as below: 1. Attach the 2 brackets on the S98xx with screws provided in the accessory kit. 2. -
Page 19: Sfp Transceiver Installation
Hardware Installation Fig 2-2 Connecting Console to switch The connection procedure is shown below: Find the console cable provided in the accessory kit. Attach the Mini-USB end to console port of the switch. Connect the other side of the console cable to a character terminal (PC). Power on the switch and the character terminal. -
Page 20: M9000-2S+ Extended Module Installation
Hardware Installation S98xx provide 10Gb slots. The procedure for installing the M9000-2X module and the XFP 10Gb fiber transceiver is shown below: Step 1: Put on an ESD wrist strap (or antistatic gloves). Step 2: Insert the M9000-2X module to the guide rail inside the 10Gb module slot. Step 3: Push the M9000-2X module along the guide rail gently until it comes into contact with the machine panel. -
Page 21: Copper Cable/Fiber Cable Connection
Hardware Installation Step 4: Insert the SFP transceiver to the guide rail inside the M9000-2S. Do not put the SFP transceiver up-side-down. Step 5: Push the SFP transceiver along the guide rail gently until it comes into contact with the M9000-2S. Note: the SFP 1Gb fiber transceiver is hot swappable. -
Page 22: Ac Power Supply Connection
Hardware Installation ports might damage the transceiver or the other ports. When connecting other devices through a fiber cable to the switch, the output power of the fiber cable must not exceed the maximum received power of the corresponding modules. Otherwise, it will damage the fiber transceiver. -
Page 23: Poe Power Supply Connection
Hardware Installation damaged or malfunction. Do not open the switch shell without permission. It can cause physical injury. 2.3.10 PoE Power Supply Connection When using PoE function of S98xx, it needs to connect the external PoE power with 5 holes socket. The connection procedure is described as below: 1.
