Alto-Shaam 1000-BQ2/96 Installation Operation & Maintenance

Banquet carts electric hot food holding
Hide thumbs Also See for 1000-BQ2/96:
Table of Contents

Advertisement

Quick Links

Download this manual
1000-BQ2/96
W164 N9221 Water Street • P.O. Box 450
Menomonee Falls, Wisconsin 53052-0450 U.S.A.
262.251.3800 • 800.558.8744
PHONE:
262.251.7067 • 800.329.8744
FAX:
www.alto-shaam.com
Printed in
.
.
.
u
s
a
1000-BQ2/128
1000-BQ2/192
U.S.A. / CANADA
U.S.A. ONLY
for operation and use.
Hot Food Holding
1000-BQ2/96
1000-BQ2/128
1000-BQ2/192
• Installation
• Operation
• Maintenance
Consult instructions
Banquet Carts
Electric
MN-29578 (Rev. 6) • 04/17

Advertisement

Table of Contents
loading

Related Manuals for Alto-Shaam 1000-BQ2/96

Summary of Contents for Alto-Shaam 1000-BQ2/96

  • Page 1 Banquet Carts Electric Hot Food Holding 1000-BQ2/96 1000-BQ2/128 1000-BQ2/192 1000-BQ2/96 1000-BQ2/128 • Installation • Operation • Maintenance 1000-BQ2/192 W164 N9221 Water Street • P.O. Box 450 Menomonee Falls, Wisconsin 53052-0450 U.S.A. 262.251.3800 • 800.558.8744 PHONE: U.S.A. / CANADA 262.251.7067 • 800.329.8744 FAX: U.S.A.

  • Page 2: Table Of Contents

    Table of Contents Delivery ............... 1 Transportation Damage and Claims ....... 2 Unpacking ..............3 Safety Procedures ............4 Installation ..............6 Dimensions ..............7 Capacities ..............8 Accessories ..............9 Electrical Connection ..........10 Operation ..............12 Cleaning and Preventative Maintenance ...... 15 Troubleshooting ............

  • Page 3: Delivery

    This manual must be read and understood by all people using or installing the appliance. Contact the Alto-Shaam Tech Team Service Department if you have any questions concerning installation, operation, or maintenance. 1-800-558-8744; servicedept@alto-shaam.com...

  • Page 4: Transportation Damage And Claims

    Alto-Shaam will continue our policy of assisting our receiving area. Do not wait until aft er the appliance is customers in collecting claims which have been properly moved to a storage area.

  • Page 5: Unpacking

    Alto-Shaam of all liability. • Remove all protective plastic fi lm, packaging materials, and accessories from the appliance before connecting electrical power. Store any accessories in a convenient place for future use.

  • Page 6: Safety Procedures

    Operating instructions and warnings must WARNING be read and understood by all operators and users. Alto-Shaam recommends regular staff training to avoid Indicates a hazardous situation that, if not avoided, could the risk of accident or damage to the appliance. Operators result in death or serious injury.
  • Page 7 Children should be supervised to ensure that they do not If your appliance makes an especially loud noise warranty and relieve Alto-Shaam of all liability. play with the appliance. when starting up, shut down the appliance and call a qualifi ed and trained service technician.

  • Page 8: Installation

    Clearance Requirements Full perimeter bumper accommodates all clearance requirements. Weight 1000-BQ2/96 1000-BQ2/128 1000-BQ2/192 322 lbs (146 kg) 370 lbs (168 kg) 618 lbs (280 kg) Ship 415 lbs (188 kg)

  • Page 9: Dimensions

    CORD LENGTH 120V - 60" (1525mm) 208-240V - 96" (2438mm) 230V - 96" (2438mm) *International - 29-1/8" (739mm) 1000-BQ2/96 Max. Load Capacity 22-5/16" 240 lbs. (109 kg) 27-5/8" (701mm) (565mm) 240 qts. (304 lt) 45-13/16" (1164mm) CORD LENGTH 120V - 60"...

  • Page 10: Capacities

    Capacities Plate Capacity (16 plates high, 3" plate height) 8" - 8-3/4" 176 Plates 8" - 8-3/4" 9" - 10" 8" - 8-3/4" 128 Plates 128 Plates 256 Plates 9" - 10" 10-1/4" - 11-3/4" 9" - 10" 96 Plates 96 Plates 192 Plates 10-1/4"...

  • Page 11: Accessories

    Accessories Accessories 1000-BQ2/96 1000-BQ2/128 1000-BQ2/192 Plate Carriers, Chrome Plated Capacity Capacity Capacity (each holds four (4) preplated meals) Uncovered “P” Carriers DC-2868 DC-2868 DC-2868 Plate Diameter: Max. 10" (254mm) Min. 7-3/4" (197mm) 24 carriers 32 carriers 48 carriers Vertical rung spacing: 2-5/8" (67mm)

  • Page 12: Electrical Connection

    Electrical Connection CAUTION WARNING Power source must match voltage identified To prevent serious injury, death, or on appliance rating tag. The rating tag property damage: provides essential technical information All electrical connections must be required for any appliance installation, made by a qualified and trained service maintenance or repairs.

  • Page 13: Electrical Specifications

    Electrical Connection Electrical Specifications (Wire diagrams are located inside the bonnet of the unit) ch2-16p bs1363 as/nzs 3112 nema 5-15p nema 6-15p nema 5-20p nema 5-30p cee 7/7 Voltage Phase Amps plug rated plug rated plug rated 15a-125v 15a-250v 20a-125v 30a-125v plug rated plug...

  • Page 14: Operation

    Operation 4. Load the cabinet with hot food only. Heat Digital The purpose of the holding cabinet is to maintain Indicator Light Display hot food at proper serving temperatures. Only hot food should be placed into the cabinet. Before loading the unit with food, use a food thermometer to make certain all food products are at an internal temperature range of 140°F to 160°F (60°C to 71°C).
  • Page 15 Operation Holding Procedure Heat Digital Indicator Light Display 4. Reset the thermostat to desired temperature. After the cart has been completely filled with product, check to make certain the doors are securely closed, and reset the thermostat to the desired holding temperature or the suggested 180°F (82°C).
  • Page 16 Operation General Holding Guideline Holding Temperature Range Chefs, cooks and other specialized food service personnel Meat Fahrenheit Celsius employ varied methods of cooking. Proper holding Beef Roast — Rare 130°F 54°C temperatures for a specific food product must be based on the moisture content of the product, product density, Beef Roast —...

  • Page 17: Cleaning And Preventative Maintenance

    Cleaning and Preventative Maintenance Protecting stainless steel surfaces Cleaning agents It is important to guard against Use non-abrasive cleaning products designed for use on corrosion in the care of stainless stainless steel surfaces. Cleaning agents must be chloride- steel surfaces. Harsh, corrosive, free compounds and must not contain quaternary salts.
  • Page 18 Cleaning and Preventative Maintenance WARNING WARNING To prevent serious personal injury, death, or To prevent serious injury, death, or property damage, always disconnect the appliance property damage: from the power source before cleaning Do not steam clean, hose down or flood the or servicing.
  • Page 19 Cleaning and Preventative Maintenance Food fl avor and aroma are usually so closely related that it Internal Food Product Temperatures is diffi cult, if not impossible, to separate them. There is also Hot Foods an important, inseparable relationship between cleanliness Danger Zone 40°F to 140°F 4°C to 60°C...

  • Page 20: Troubleshooting

    Do not attempt to repair or service the oven beyond this point. Contact Alto-Shaam for the nearest authorized service agent. Repairs made by any other service agents without prior authorization by Alto-Shaam will void the warranty.
  • Page 21 Troubleshooting Error codes Code Description Possible Cause s E-10 Cavity air sensor shorted Cavity air sensor reading < 5°F (-15°C). Verify sensor integrity. E-11 Cavity air sensor open Cavity air sensor reading > 517°F (269°C). Verify sensor integrity. Product probe is shorted E-20 Product probe reading <...

  • Page 22: Service

    Service Service View - 1000-BQ2/128 Shown Part numbers and drawings are subject to change without notice. MN-29578 • Rev 6 • 04/17 • 1000-BQ2 Banquet Cart...
  • Page 23 Service Model > 1000-BQ2/96 1000-BQ2/128 1000-BQ2/192 Item Description Part No. Part No. Part No. Back Panel — — — — 1012121 Cordset See electrical components view Casing Back 1012107 1012145 1012107 Hanger 6-1/2" Rope Cleat 7/16 Black Nylon E2097HR E2097HR...
  • Page 24 Service Electrical Components Part numbers and drawings are subject to change without notice. Item Description Part No. Qty* Item Description Part No. Qty* Bushing, Strain Relief BU-3964 Switch Cover (230V only) CV-38297 Cordset 120V, 15 Amp (NEMA 5-15P) CD-3232 Switch, Rocker, 125-277V, 20A SW-34769 120V, 20 Amp (NEMA 5-20P) CD-3397...
  • Page 25 Service Split Door (factory installed option) - 1000-BQ2/192 Doors Shown Part numbers and drawings are subject to change without notice. Model > 1000-BQ2/96 1000-BQ2/128 1000-BQ2/192 Item Description Part No. Part No. Part No. Front Trim, Inside Mullion 1015133 1015133 1015133...
  • Page 26 Service Trailer Hitch (factory installed option) - 1000-BQ2/96 Shown Trailer Hitch Safety • No more than (3) carts are to be attached to either a dedicated “golf cart” or bicycle. • Speed limits should be kept to a maximum of 5 mph (8km/h) to avoid potential employee injury.
  • Page 27 Cable Heating Replacement Service Kit ...... 4880 1000-BQ2/96 (125V) requires one (1) kit (129' of cable) 1000-BQ2/192 (125V) requires one (1) kit for one (1) cavity or two (2) kits for both cavities (129' of cable per cavity) Service kit includes: CB-3045 Cable Heating Element ...........
  • Page 28 Service MN-29578 • Rev 6 • 04/17 • 1000-BQ2 Banquet Cart...
  • Page 29 Service MN-29578 • Rev 6 • 04/17 • 1000-BQ2 Banquet Cart...
  • Page 30 Service MN-29578 • Rev 6 • 04/17 • 1000-BQ2 Banquet Cart...
  • Page 31 Service MN-29578 • Rev 6 • 04/17 • 1000-BQ2 Banquet Cart...
  • Page 32 Service MN-29578 • Rev 6 • 04/17 • 1000-BQ2 Banquet Cart...
  • Page 33 Service MN-29578 • Rev 6 • 04/17 • 1000-BQ2 Banquet Cart...
  • Page 34 Service MN-29578 • Rev 6 • 04/17 • 1000-BQ2 Banquet Cart...
  • Page 35 Service MN-29578 • Rev 6 • 04/17 • 1000-BQ2 Banquet Cart...
  • Page 36 Service MN-29578 • Rev 6 • 04/17 • 1000-BQ2 Banquet Cart...

  • Page 37: Limited Warranty

    This warranty is exclusive and is in lieu of all other warranties, express or implied, including the implied warranties of merchantability and fi tness for a particular purpose. In no event shall Alto-Shaam be liable for loss of use, loss of revenue or profi t, or loss of product, or for any indirect, special, incidental, or consequential damages.
