AquaLink
Wireless Handheld Remote
For use with AquaLink PDA, RS and Z4 Systems
FOR YOUR SAFETY - This product must be installed and serviced by a contractor
who is licensed and qualified in pool equipment by the jurisdiction in which the
product will be installed, where such state or local requirements exist. In the event
no such state or local requirement exists, the maintainer must be a professional with
sufficient experience in pool equipment installation and maintenance, so that all of
the instructions in this manual can be followed exactly. Before installing this product,
read and follow all warning notices and instructions that accompany this product.
Failure to follow warning notices and instructions may result in property damage,
personal injury, or death. Improper installation and/or operation will void the warranty.
Improper installation and/or operation can create unwanted electrical hazard which
can cause serious injury, property damage, or death.
®
WARNING
INSTALLATION AND
OPERATION MANUAL
ENGLISH
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Jandy AquaLink
Summary of Contents for Jandy AquaLink
- Page 1 ® AquaLink Wireless Handheld Remote For use with AquaLink PDA, RS and Z4 Systems WARNING FOR YOUR SAFETY - This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the product will be installed, where such state or local requirements exist.
- Page 2 Page 2 ENGLISH Wireless Handheld Remote | Installation and Operation Manual...
-
Page 3: Table Of Contents
Page 3 ENGLISH Wireless Handheld Remote | Installation and Operation Manual TABLE OF CONTENTS Section 1. Important Safety Instructions ........4 Section 2. Product Description ...........7 Basic Functions ................7 Remote and Transceiver J-box Dimensions ........ 7 Section 3. Installation ..............8 Transceiver J-Box Connection to Power Center PCB ....8 Handheld Remote Installation .............9 Changing the Frequency Channel ..........9 Section 4. -
Page 4: Section 1. Important Safety Instructions
Page 4 ENGLISH Wireless Handheld Remote | Installation and Operation Manual SECTION 1. IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS All electrical work must be performed by a licensed electrician and conform to all national, state, and local codes. When installing and using this electrical equipment, basic safety precautions should always be followed, including the following: ATTENTION... - Page 5 Page 5 ENGLISH Wireless Handheld Remote | Installation and Operation Manual WARNING Risk of electric shock, which could result in severe injury or death - Install the power center at least five (5) feet (1.52m) from the inside wall of the pool and/or hot tub using non-metallic plumbing.
- Page 6 Page 6 ENGLISH Wireless Handheld Remote | Installation and Operation Manual WARNING • Do not use drugs or alcohol before or during the use of a spa or hot tub to avoid unconsciousness and possible drowning. • Do not use a spa or hot tub immediately following strenuous exercise. •...
-
Page 7: Section 2. Product Description
(UI). 1-800-822-7933. If the Wireless Handheld remote These instructions must be is part of an AquaLink RS or Z4 followed exactly. Read through system, setup and programming the instructions completely before will need to be performed from the operating the equipment. -
Page 8: Section 3. Installation
900 MHz minimizes interference. frequency items may inhibit or WARNING Potentially high voltages in AquaLink Power Centers can create ® dangerous electrical hazards, possibly causing death, serious injury or property damage. Turn off power at the main circuit feeding the Power Center to disconnect the Power Center from the system. -
Page 9: Handheld Remote Installation
(2) screws removed in Step 2. UM-3/R6/AA BATTERY 1.5V x 2 UM-3/R6/AA Cover 3.3 CHANGING THE FREQUENCY CHANNEL If your AquaLink Handheld ® Remote system is operating at undesignated times, another nearby SET RF CHANNEL RF CHANNEL: remote system may be using the same or similar channel. -
Page 10: Section 4. Handheld Remote Operation
Page 10 ENGLISH Wireless Handheld Remote | Installation and Operation Manual 1. On the Handheld Remote, press 7. Slide the Learn Switch inside the and hold both the UP and DOWN Transceiver J-Box to OFF. arrows simultaneously for three (3) 8. -
Page 11: Menus And Functions
(Rotate for spa return) (UI). -Heater If the Wireless Handheld remote is part of an AquaLink RS or Z4 system, setup (Will heat to set point for spa) and programming will need to be performed from the system UI. The Wireless Handheld Remote can then be used to activate and deactivate the equipment, programs and settings. - Page 12 EQUIPMENT INFORMATION RECORD DATE OF INSTALLATION _________________________________________ INSTALLER INFORMATION _______________________________________ INITIAL PRESSURE GAUGE READING (WITH CLEAN FILTER) ___________________________________________ PUMP MODEL __________________ HORSEPOWER ______________ FILTER MODEL _________________ CONTROL PANEL MODELSERIAL NUMBER _________________________ NOTES: _______________________________________________________ _______________________________________________________________ _______________________________________________________________ Zodiac Pool Systems, Inc. 2620 Commerce Way, Vista, CA 92081 1.800.822.7933 | www.ZodiacPoolSystems.com Zodiac Pool Systems Canada, Inc.
Need help?
Do you have a question about the AquaLink and is the answer not in the manual?
Questions and answers
just opened pool after the winter. My Jandy Aqua Link remote R0687300 turns on but then says "waiting" and that"s as far as it goes
If the Jandy AquaLink remote R0687300 turns on but displays "waiting," possible steps to troubleshoot include:
1. Check the indoor control center (J-box). If only the red light is on and the green light flashes rarely, it may indicate a communication issue.
2. Try pressing the reset button on the J-box. If this does not resolve the issue, continue troubleshooting.
3. Confirm that the remote has fresh batteries, which you have already done.
4. Power cycle the system by turning it off and back on. If the remote still shows “waiting,” the system is not establishing a connection.
5. Inspect the antenna or wireless transmitter for damage or disconnection.
If the problem continues, professional service may be required to diagnose or replace faulty communication components.
