Maintenance Procedures
Replace Cam Assembly (continued)
2.When tightening the Tension Shaft Holder, tighten the screws in numerical
order shown on the tensioner. Tighten the two screws marked 1 then the
two marked 2 and so on.
Tension Screws
Tighten screws in order
1&1, 2&2, 3&3, then 4&4.
Tension Shaft Holder
Bowflex Revolution
Service Manual
™
21
