Please follow the installation steps below to ensure your appliance operates correctly.
1. Power
The appliance must be installed so the plug is accessible.
●
●
To ensure that the appliance is not accidentally switched off, connect your refrigerator
●
●
to its own power point. Do not plug in any other appliance at this power point or use
extension cords and double adaptors, as the combined weight of both power cords can
pull the double adaptor from a wall outlet socket.
For power requirements, refer to the information on the serial plate located at the front
●
●
bottom right-hand side of the refrigerator when the door is open.
It is essential that the appliance is properly grounded (earthed).
●
●
2. Location
Your refrigerator should not be located in direct sunlight or next to any heat generating
●
●
appliance such as a cooktop, oven or dishwasher.
3. Ice & Water and Automatic Ice models
Your Ice & Water and Automatic Ice refrigerator must be installed by an authorized
●
●
plumber or Fisher & Paykel trained and supported service technician as incorrect
plumbing can lead to water leaks.
Fisher & Paykel Appliances does not accept responsibility for damage (including water
●
●
damage) caused by faulty installation or plumbing.
INSTALLATION INSTRUCTIONS
7
Advertisement
Related Manuals for Fisher & Paykel ActiveSmart RF135B
Summary of Contents for Fisher & Paykel ActiveSmart RF135B
- Page 1 INSTALLATION INSTRUCTIONS Please follow the installation steps below to ensure your appliance operates correctly. 1. Power The appliance must be installed so the plug is accessible. ● ● To ensure that the appliance is not accidentally switched off, connect your refrigerator ●...
- Page 2 INSTALLATION INSTRUCTIONS 4. Product and cabinetry dimensions If integrating your refrigerator, please follow installation instructions provided with the integration kits. PLAN VIEW FLUSH WITH REFRIGERATOR CHASSIS – FULL DOOR ROTATION Freezer door models (RF135B and RF170B) (Ice & Water, Automatic Ice and non-Ice & Water models) PLAN VIEW FLUSH WITH REFRIGERATOR CHASSIS –...
-
Page 3: Product Dimensions
INSTALLATION INSTRUCTIONS RF135B RF170B PRODUCT DIMENSIONS inches (mm) inches (mm) Overall height of product 67 3/4” (1720) 67 3/4” (1720) Overall width of product 25” (635) 31 1/8” (790) Overall depth of product (excludes handle, includes rear 27 3/8” (695) 27 3/8” (695) compartment cover) CABINETRY DIMENSIONS (including minimum clearances) inches (mm) inches (mm) - Page 4 INSTALLATION INSTRUCTIONS 4. Product and cabinetry dimensions If integrating your refrigerator, please follow installation instructions provided with the integration kits. Freezer drawer models (RF170W, RF170A, RF201A) (Ice & Water, Automatic Ice and non-Ice & Water models) RF170W RF170A, RF201A Flush with refrigerator chassis — full door rotation Flush with refrigerator chassis — full door rotation Flush with refrigerator door — full door rotation Flush with refrigerator door — full door rotation...
-
Page 5: Cabinetry Dimensions
INSTALLATION INSTRUCTIONS RF170W RF170A RF201A PRODUCT DIMENSIONS inches (mm) inches (mm) inches (mm) Overall height of product 67 3/4” (1720) 67 3/4” (1720) 70 11/16” (1795) Overall width of product 31 1/8” (790) 31 1/8” (790) 35 7/16” (900) Overall depth of product (excludes 27 3/8” (695) 27 3/8”... - Page 6 INSTALLATION INSTRUCTIONS 5. Rear compartment cover dimensions 110VAC cord and water inlet dimensions RF170B RF135B RF170W RF170A RF201A 110VAC AND WATER INLET DIMENSIONS inches (mm) inches (mm) inches (mm) inches (mm) Power cord 40” (1016) 40” (1016) 40” (1016) 40” (1016) Water inlet to bottom 5”...
-
Page 7: Installation Precautions/Warning
INSTALLATION INSTRUCTIONS 6. Connecting water (Ice & Water and Automatic Ice models) Contents of filter kit 13ft (4m) long x 1/4” (6mm) tubing 1 x 8” (200mm) short 1/4” (6mm) tubing 1 x pressure reducing valve (PRV) 1 x adhesive foam pad 2 x locking keys 1 x water filter cartridge and head 1 x tap connection — 7/16”... - Page 8 INSTALLATION INSTRUCTIONS Installation instructions: Ensure the refrigerator is NOT plugged into a power supply. Locate a cold water supply/feed only suitable for a water connection. Tee and tap fitting is not supplied. Connect the 8” (200mm) tubing to the outlet of Diagram 1 the PRV (blue collet) and the inlet connection PRV connection...
- Page 9 INSTALLATION INSTRUCTIONS Attach adhesive foam pad to the back of the water filter head as shown in PART: 838587 DRAWING: 838587 Diagram 5. Write the date to be replaced on the filter (date installed + 6 months). Diagram 5 Remove the double sided foam backing and attach the filter to the desired PART: 838587 Double sided foam...
- Page 10 INSTALLATION INSTRUCTIONS IMPORTANT! All connections must be checked for leaks. ● ● Ensure 1/4” (6mm) tubing is routed away from sharp objects, sharp corners (beware ● ● of kinking the tube as this will stop water flow), clear of the refrigerator rear compartment and not in a location where it can be kinked or squashed.
- Page 11 INSTALLATION INSTRUCTIONS Before you start using the Ice & Water or Automatic Ice function Check your refrigerator is switched on. ● ● Check that the isolation tap has been connected and turned on. ● ● Allow at least 2 hours for your refrigerator to cool before use. ●...
- Page 12 INSTALLATION INSTRUCTIONS 7. Installation (all models) Your Fisher & Paykel ActiveSmart™ refrigerator is fitted with front and rear rollers, designed for moving the product in the forwards and backwards direction. Avoid moving the product in a sideways direction as this may damage the rollers or the floor Raise the front of the refrigerator covering/surface.
- Page 13 INSTALLATION INSTRUCTIONS 9. What to do if your product is unstable Gently push the refrigerator back until the rear rollers contact the floor. Example only Measure the gap under the front foot, which has ● ● come off the floor. Obtain some solid packing material (hardwood, ●...
- Page 14 INSTALLATION INSTRUCTIONS Before placing food in the fresh food or freezer compartments Remove all internal packaging. Ensure that all transit clips are removed from the ● ● refrigerator. These are small rubber stoppers located at the back of the shelves. Clean the inside of the appliance with a mix of warm water and a small amount of liquid ●...
