Service Manual
Microwave Oven
Model: KOR-63B50P
Caution

: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
S/M No. : R63B50S001
KOR-86B50P
http://svc.dwe.co.kr

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KOR-63B50P and is the answer not in the manual?

Questions and answers

Related Manuals for DAEWOO ELECTRONICS KOR-63B50P

Summary of Contents for DAEWOO ELECTRONICS KOR-63B50P

  • Page 1 : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CO., LTD. http://svc.dwe.co.kr...

  • Page 2: Table Of Contents

    PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICING TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not operate or allow the oven to be operated w ith the door open. (b) M ake the following safety checks on all ovens to be serviced before activating the m agnetron or other m icrowave source, and m ake repairs as necessary: (1) Interlock operation, (2) Proper door closing, (3) Seal and sealing surfaces (arcing, wear, and other dam age), (4) Dam age to or loosening of hinges and latches, (5) Evidence of dropping or abuse.

  • Page 3: Safety And Precautions

    SAFETY AND PRECAUTIONS 1. FOR SAFE OPERATION Damage that allows the microwave energy (that cooks or heats the food) to escape will result in poor cooking and may cause serious bodily injury to the operator. IF ANY OF THE FOLLOWING CONDITIONS EXIST, OPERATOR MUST NOT USE THE APPLIANCE. (Only a trained service personnel should make repairs.) 1) A broken door hinge.

  • Page 4: Specifications

    SPECIFICATIONS KOR-6305 M O DEL KO R-6305 PO W E R SUPPLY 220V-60HZ, SING LE PHASE W ITH EARTHING M ICRO WAVE 1200W G RILL PO W E R CO NS UM PTIO N CO M BINATIO N M ICRO WAVE ENERG Y O UTPUT 800W M ICRO WAVE FREQ UENCY 2450M Hz...

  • Page 5: External View

    EXTERNAL VIEW 1. OUTER DIMENSION (KOR-6305/KOR-8605) Fig.1 Front view Fig.2 Side view 2. FEATURE DIAGRAM 1. Safety interlock system 2. Door viewing screen - Allows viewing of food. The screen is designed so that light can pass through, but not the microwave. 3.

  • Page 6: Installation

    INSTALLATION 1. Steady, flat location This microwave oven should be set on a steady, flat surface. This microwave oven is designed for counter top use only. 2. Leave space behind and side All air vents should be kept a clearance. If all vents are covered during operation, the oven may overheat and, eventually, cause failure.

  • Page 7: Operations And Functions

    OPERATIONS AND FUNCTIONS 1. Connect the main lead to an electrical outlet. NOTE 2. After placing the food in a suitable container, open the oven 1. When setting timer for less than 2 minutes, turn the door and put it on the glass tray. The glass tray must always timer past 2 minutes and then return to the correct timer setting.

  • Page 8: Disassembly And Assembly

    DISASSEMBLY AND ASSEMBLY Cautions to be observed when trouble shooting Unlike many other appliances, the microwave oven is high-voltage, high-current equipment. It is completely safety during normal operation. However, carelessness in servicing the oven can result in an electric shock or possible danger from a short circuit. You are asked to observe the following precautions carefully.
  • Page 9  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) DISASSEMBLY AND ASSEMBLY 1.
  • Page 10  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) DISASSEMBLY AND ASSEMBLY KOR-86B5 REF.NO P ART CODE...
  • Page 11  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) DISASSEMBLY AND ASSEMBLY 5.
  • Page 12 DISASSEMBLY AND ASSEMBLY (1) Remove the screw which secure the control panel, push up two snap fits and draw forward the control panel assembly. (2) Remove the door open lever from the control panel. (3) Remove two screws which secure the timer assembly. (4) Remove the timer assembly.
  • Page 13 DISASSEMBLY AND ASSEMBLY 7. To remove magnetron (1) Remove a screw which secure the magnetron. (2) Remove the magnetron. (3) Reverse the above steps for reassembly. NOTE Never install the magnetron without the metallic gasket plate which is packed with each magnetron to prevent microwave leakage.
  • Page 14 DISASSEMBLY AND ASSEMBLY 8. To remove wind guide assembly (1) Remove a screw which secure the wind guide assembly. (2) Draw forward the wind guide assembly. (3) Pull the fan from the motor shaft. (4) Remove two screws which secure the motor shaded pole. (5) Remove the motor shaded pole.

  • Page 15: Interlock Mechanism And Adjustment

    INTERLOCK MECHANISM AND ADJUSTMENT The door lock mechanism is a device which has been specially designed to completely eliminate microwave radiation when the door is opened during operation, and thus to perfectly prevent the danger resulting from the leakage of microwave. 1.

  • Page 16: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE Following the procedures below to check if the oven is defective or not 1. Check grounding before checking trouble. 2. Be careful of the high voltage circuit. 3. Discharge the high voltage capacitor. 4. When checking the continuity of the switches, fuse or high voltage transformer, disconnect one lead wire from these parts and then check continuity with the AC plug removed.
  • Page 17 TROUBLE SHOOTING GUIDE Does the fan m otor work when you shut the door and turn the timer? Does the oven lamp light? Replace or repair oven lam p, Does the turntable turn? turntable m otor. Norm al reading should be approx.

  • Page 18: Measurement And Test

    MEASUREMENT AND TEST 1. MEASUREMENT OF THE MICROWAVE POWER OUTPUT Microwave output power can be checked by indirectly measuring the temperature rise of a certain amount of water exposed to the microwave as directed below. PROCEDURE 1. Microwave power output measurement is made with the microwave oven supplied at rated voltage and operated at its maximum microwave power setting with a load of 1000 ±...

  • Page 19: Microwave Radiation Test

    MEASUREMENT AND TEST 2. MICROWAVE RADIATION TEST WARNING • M ake sure to check the m icrow ave leakage before and after repair of adjustm ent. • A lw ays start m easuring of an unknow n field to assure safety for operating personnel from m icrow ave energy. •...

  • Page 20: Component Test Procedure

    MEASUREMENT AND TEST 3. COMPONENT TEST PROCEDURE High voltage is present at the high voltage terminal of the high voltage transformer during any cooking cycle. It is neither necessary nor advisable to attempt measurement of the high voltage. Before touching any oven components or wiring, always unplug the oven from its power source and discharge the capacitor. 1.

  • Page 21: Wiring Diagram

    WIRING DIAGRAM...

  • Page 22: Exploded View And Parts List

    EXPLODED VIEW AND PARTS LIST 1. DOOR ASSEMBLY Refer to Disassembly and assembly. 2. CONTROL PANEL ASSEMBLY Refer to Disassembly and assembly. 3. TOTAL ASSEMBLY...
  • Page 23  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) EXPLODED VIEW AND PARTS LIST (1) KOR-63050P REF.
  • Page 24  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) EXPLODED VIEW AND PARTS LIST (2) KOR-86050P REF.
