AU
GRÄNSLÖS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GRANSLOS and is the answer not in the manual?

Questions and answers

Related Manuals for IKEA GRANSLOS

Summary of Contents for IKEA GRANSLOS

  • Page 1 GRÄNSLÖS...
  • Page 2 ENGLISH Please refer to the chapter IKEA GUARANTEE for contact details of the after sales customer service centre.
  • Page 3 ENGLISH...

  • Page 4: Table Of Contents

    Before first use Technical data Daily use ENVIRONMENTAL CONCERNS Microwave mode IKEA GUARANTEE Clock functions Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages.

  • Page 5: General Safety

    ENGLISH Children shall not carry out cleaning and user maintenance of • the appliance without supervision. Children aged 3 years and under must be kept away from • this appliance when it is in operation at all times. General Safety Only a qualified person must install this appliance and •...

  • Page 6: Conditions Of Use

    ENGLISH Metallic containers for food and beverages are not allowed • during microwave cooking. This requirement is not applicable if the manufacturer specifies size and shape of metallic containers suitable for microwave cooking. Only use utensils that are suitable for use in microwave •...

  • Page 7: Safety Instructions

    ENGLISH Safety instructions • Do not let mains cables touch or come Installation near the appliance door, especially Warning! Only a qualified when the door is hot. person must install this • The shock protection of live and appliance. insulated parts must be fastened in such a way that it cannot be removed without •...
  • Page 8 ENGLISH • Do not use the appliance as a work Care and Cleaning surface or as a storage surface. Warning! Risk of injury, fire, or • Open the appliance door carefully. The damage to the appliance. use of ingredients with alcohol can cause a mixture of alcohol and air.

  • Page 9: Installation

    ENGLISH • Do not heat empty or nearly empty Disposal glassware in microwave, or overheat oil Warning! Risk of injury or or butter in microwave (use minimum suffocation. amount of cooking time). Allow hot glassware to cool on a cooling •...

  • Page 10: Product Description

    ENGLISH For the section of the cable refer to the total Total power (W) Section of the cable power on the rating plate. You can also (mm²) refer to the table: maximum 3680 3 x 1.5 Total power (W) Section of the cable (mm²) The earth cord (green / yellow cable) must be 2 cm longer than phase and neutral...

  • Page 11: Daily Use

    ENGLISH To open the oven door with the child lock Preheating installed, pull the child lock handle up as Preheat the empty appliance before first shown in the picture. use. For microwaves you can leave only wire shelves inside. The microwave bottom glass plate must be removed.

  • Page 12: Microwave Mode

    ENGLISH A. Time and temperature Display B. Heat-up and residual heat indicator C. Microwave function D. Core temperature sensor (selected models only) E. Door lock (selected models only) F. Hours / minutes G. Clock functions Buttons Button Function Description MICROWAVE To set the Microwave function.
  • Page 13 ENGLISH burst. With fried eggs, pierce the yolks Defrosting butter, portions of gateau, first. quark: • Pierce skin or peel of potatoes, tomatoes, • Do not fully defrost in the appliance, but sausages and similar types of food with let them defrost completely at a room a fork several times before cooking so temperature.
  • Page 14 ENGLISH Cookware / Material Microwave Grilling Defrosting Heating Cooking Heat-resistant plastic up to 200 °C Cardboard, paper Clingfilm Roasting film with microwave safe closure Roasting dishes made of metal, e.g. enamel, cast iron Baking tins, black lacquer or silicon- coated Wire shelf Microwave glass bottom plate Browning cookware, e.g.
  • Page 15 ENGLISH Result Remedy The food is still not defrosted, hot or Set longer cooking time or select higher micro- cooked after the end of cooking time . wave power. Note that taller dishes generally need longer cooking time. Stir or turn food during cooking.
  • Page 16 ENGLISH When the Microwave function is running When you use the Microwave you can: function with the function Duration for more than 7 minutes • change the power settings. and in Combi mode, the • check the power settings. Press Microwave power cannot be When you open the oven door, more than 600 W.

  • Page 17: Clock Functions

    ENGLISH Clock functions Clock functions table Clock function Application TIME OF DAY To show or change the time of day. You can change the time of day only when the appliance is off. DURATION To set how long the appliance operates. Use only when an oven function is set.

  • Page 18: Using The Accessories

    ENGLISH acoustic signal sounds for 2 minutes. Time Setting the END function during cooking setting flash in the display. The oven stops. function 4. Press any button or open the oven door 1. Press again and again until starts to stop the acoustic signal. to flash.

  • Page 19: Additional Functions

    ENGLISH Put the accessory on the bottom of the Small indentation at the top cavity. Put the food on the microwave increase safety. The indentations bottom glass plate. are also anti-tip devices. The high rim around the shelf Always use the microwave bottom glass prevents cookware from slipping plate when the microwave function is on.

  • Page 20: Hints And Tips

    ENGLISH overheating. To prevent this, the oven has a power supply. The oven activates again safety thermostat which interrupts the automatically when the temperature drops. Hints and tips • Leave the meat for approximately 15 General information minutes before carving so that the juice •...
  • Page 21 ENGLISH Microwave cooking table Put the food on the bottom of the cavity on a plate or in a container if not specified differently. Food Power Quantity Time (min) Standing Comments (Watts) time (min) Whole fish 500 g 8 - 10 Cook covered, turn con- tainer several times dur- ing cooking.

  • Page 22: Care And Cleaning

    ENGLISH Food Power Tempera- Time (min) Shelf posi- Comments (Watts) ture (°C) tion Roast pork Turn in between, 10 neck (1100 g) min standing time. Defrosting table Food Power Quantity (g) Time (min) Standing Comments (Watts) time (min) Whole cuts of 10 - 12 10 - 15 Turn halfway...

  • Page 23: Troubleshooting

    ENGLISH • Clean stubborn dirt with a special oven cleaner. • Clean all accessories after each use and let them dry. Use a soft cloth with warm water and a cleaning agent. • If you have nonstick accessories, do not clean them using aggressive agents, sharp-edged objects or a dishwasher.
  • Page 24 ENGLISH What to do if... Problem Possible cause Remedy The oven does not heat up. The oven is deactivated. Activate the oven. The oven does not heat up. The clock is not set. Set the clock. The oven does not heat up. The necessary settings are Make sure that the settings not set.

  • Page 25: Technical Data

    ENGLISH the front frame of the appliance cavity. Do Service data not remove the rating plate from the If you cannot find a solution to the problem appliance cavity. yourself, contact an Authorised Service Centre. The necessary data for the service centre is on the rating plate.

  • Page 26: Ikea Guarantee

    For Western Australian and South 84006270757 or at Cebas Pty Ltd, ABN 15 Australian customers please contact: 009 156 003 (Both Trading as IKEA) unless the appliance is named LAGAN in which Cebas Pty Ltd case two (2) years of guarantee apply. The...
  • Page 27 • Repairs not carried out by our appointed Australia. service providers and/or an authorized What will IKEA do to correct the problem? service contractual partner or where non-original parts have been used. IKEA appointed service provider will exam- •...
  • Page 28 You can find out more information about The IKEA after sales customer service centre the Australian Consumer Law on the ACCC will assist you on the phone with basic website: www.accc.gov.au...
  • Page 29 ENGLISH...
  • Page 30 ENGLISH...
  • Page 31 ENGLISH...
  • Page 32 21552 © Inter IKEA Systems B.V. 2016 AA-1755543-4...
