Mobile Sit-Stand Desk
STSCART
FR: Guide de l'utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l'uso - it.startech.com
For the latest information, technical specifications, and support for
this product, please visit www.StarTech.com/STSCART.
Manual Revision: 11/21/2017
*actual product may vary from photos
Advertisement
Table of Contents
Related Manuals for StarTech.com STSCART
Summary of Contents for StarTech.com STSCART
- Page 1 Mobile Sit-Stand Desk STSCART *actual product may vary from photos FR: Guide de l’utilisateur - fr.startech.com DE: Bedienungsanleitung - de.startech.com ES: Guía del usuario - es.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com IT: Guida per l’uso - it.startech.com For the latest information, technical specifications, and support for this product, please visit www.StarTech.com/STSCART.
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Warning Statements
Warning statements Dichiarazioni di avvertenza Make sure that you assemble this product according to the instructions. Assicurarsi di Assemblare il prodotto secondo le istruzioni. Read the entire manual and make sure that you understand the instructions before you start to assemble Leggere l’intero manuale e assicurarsi di aver compreso tutte le istruzioni prima di iniziare ad assemblare and use this product. - Page 4 Warnhinweise Beachten Sie bei der Montage dieses Produkts die Montageanweisungen. Bevor Sie dieses Produkt montieren und verwenden, lesen Sie das gesamte Handbuch und vergewissern Sie sich, dass Sie die Anweisungen verstanden haben. Gestatten Sie Kindern nicht, auf das Produkt zu klettern oder das Produkt ohne Aufsicht zu benutzen. Dieses Produkt ist nur zum Gebrauch in Innenräumen vorgesehen und sollte nicht im Freien verwendet werden.
-
Page 5: Table Of Contents
Table of Contents Warnings ..............................i Product dimensions ................1 Product diagram ..................2 Technical specifications ................3 Package contents ...................4 Assembly ....................7 Attach the casters to the base ......................7 Attach the column to the desktop ...................... 9 Attach the column assembly to the base assembly ..............11 Using the mobile sit-stand desk ............12 Lock the locking casters .......................... -
Page 6: Product Dimensions
Product dimensions 800 mm (31.5 in.) 600 mm (24 in.) 970 mm (38 in.) 750 mm to 1150 mm (29.5 in. to 45 in.) 586 mm 703.5 mm (23 in.) (28 in.) Instruction manual... -
Page 7: Product Diagram
Product diagram Desktop Adjustment lever Column Base Back Front Locking caster Caster Locking caster Instruction manual... -
Page 8: Technical Specifications
Technical specifications Type of measurement Measurement 400 mm (16 in.) Lift 4.5 kg (10 lb.) Note: If you add more than 4.5 kg of weight to the desktop, you will need to exert some manual force to raise the desktop. Lift capacity 50 kg (110 lb.) Static load capacity... -
Page 9: Package Contents
Package contents Base Casters Qty: One Qty: Two Locking casters Column Qty: Two Qty: One Desktop Covers Qty: One Qty: Four Instruction manual... - Page 10 M6x15 mm socket-head screws M6x15 mm flat-head screws Qty: Eight Qty: Twelve M4 hex key M5 hex key Qty: One Qty: One Cable clips Keys Qty: Four Qty: Two Instruction manual...
- Page 11 Instruction manual Qty: One Instruction manual...
-
Page 12: Assembly
Assembly Attach the casters to the base Tip! The back edge of the base is labeled on the underside of the base. 1. Position one of the non-locking casters in line with the assembly holes in one corner of the back edge of the base. 2. - Page 13 3. Use the M4 hex key to tighten the screws. (figure 2) figure 2 M4 hex key 4. Repeat steps 1 to 3 to attach the second non-locking caster to the other corner of the back edge of the base. 5.
-
Page 14: Attach The Column To The Desktop
6. Snap a cover over all four corners of the base. (figure 4) figure 4 Cover Attach the column to the desktop The desktop includes a wire cable with an end connector that you use to connect to the spring release in the column. 1. - Page 15 3. Place the end connector attached to the wire cable into the circular opening in the spring release in the column. 4. Thread the wire cable through the opening in the spring release and along the circular projection. (figure 6) 5.
-
Page 16: Attach The Column Assembly To The Base Assembly
Attach the column assembly to the base assembly 1. Position the base assembly so that the front of the base is in line with the front of the desktop. 2. Insert four of the M6x15 mm socket-head screws through the base assembly and into the column assembly. -
Page 17: Using The Mobile Sit-Stand Desk
Using the mobile sit-stand desk Move the desktop up or down Warning! Before you move the desktop up or down, make sure that the equipment on the desktop is secure. If your equipment is not stable, it could fall off of the desktop as you move it and the equipment could be damaged. -
Page 18: Lock The Locking Casters
Lock the locking casters • To prevent the mobile sit-stand from moving, press the locking pedals located on the two locking casters at the front of the mobile sit-stand. (figure 12) • Press the black tabs on the locking casters to release the locking pedals. figure 12 Locking pedal Instruction manual... -
Page 19: Manage Your Cables
Manage your cables 1. Snap the cable clips into the grooves located on the bottom half of the column at the back or front of the mobile sit-stand. 2. Position your cables down the column and through the cable clips. (figure 13) figure 13 Cable clips Instruction manual... -
Page 20: Technical Support
Limitation of liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 21 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
