Zenoah G230RC Owner's Service Manual

Hide thumbs Also See for G230RC:

See also: Owner's Service Manual

OWNER'S SERVICE MANUAL

G230RC/G260RC

T2070-93111 (307)

WARNING

• This engine is designed

for the radio controlled

car use. Komatsu Zenoah

assumes that no

responsibility for this

engine that is modified or

used for any other

applications.

Purchaser has all

responsibility against any

laws and regulations

existing in the country,

Komatsu Zenoah is

exempt from such law

and regulations.

• Read this OWNER'S

SERVICE MANUAL before

operating this engine.

Table of Contents

Need help?

Do you have a question about the G230RC and is the answer not in the manual?

Page 1 T2070-93111 (307) OWNER’S SERVICE MANUAL G230RC/G260RC WARNING • This engine is designed for the radio controlled car use. Komatsu Zenoah assumes that no responsibility for this engine that is modified or used for any other applications. Purchaser has all responsibility against any...
Page 3: Specifications
1. Specifications Engine Type G230RC G260RC Overall Size (L x W x H) 167 x 204 x 195mm Weight 2.07kg Displacement 22.5cm 25.4cm Clutch Engagement 6000rpm (STD Spring) Carburetor Type WT-603A Spark Plug CHAMPION RZ7C Spark Plug Gap 0.65mm Rotating Direction Counter-Clockwise (View From PTO) 2.
Page 4 Check/Cleaning ✔ ✔ ↑ Bearings Check/Cleaning ✔ ↑ Crank Shaft Check/Alignment 2) SPECIFICATIONS AND TECHNICAL DATA Items Unit G230RC G260RC Remarks Bore x Stroke 32 x 28 34 x 28 Displacement 22.5 25.4 Effective Compression Ratio ← Type Walbro WT Carburetor ←...
