Seascape BV
De Hoogjens 22
4254 XW Sleeuwijk
The Netherlands
Phone: +31-183-307900
Email: info@novasub.com
www.novasub.com
www.seascape.nl
Operations Manual
SCC-1DR(VL)
video camera & light control.
The Novasub 1 diver communication radio range is a
small, low-cost portable hard-wire radio in a
ruggedized case.
– 1 Diver radio optional with
Version:
Date:
1.65
Preliminary
7-Apr-15
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Novasub SCC-1DR
Summary of Contents for Novasub SCC-1DR
- Page 1 Operations Manual SCC-1DR(VL) – 1 Diver radio optional with video camera & light control. The Novasub 1 diver communication radio range is a small, low-cost portable hard-wire radio in a Seascape BV ruggedized case. De Hoogjens 22 4254 XW Sleeuwijk...
-
Page 2: Table Of Contents
SCC-1DR(VL) MANUAL Version: 1.65 Date:7-Apr-15 1 of 22 Index HELP & SUPPORT ....................................3 SAFETY MEASUREMENTS..................................4 ..................................... 4 AFETY PRECAUTIONS MAINTENANCE ....................................5 3.1.1 Maintenance by authorized dealer or distributor ........................5 ..................................5 AINTENANCE SCHEME WARRANTY.......................................6 ....................................6 ARRANTY ERIOD ................................. 6... -
Page 3: Disposal Of The Device
SCC-1DR(VL) MANUAL Version: 1.65 Date:7-Apr-15 2 of 22 YOU MUST READ the SCC-1DR(VL) manual before using the SCC-1DR(VL). Failure to do so WARNING may lead to improper use, serious injury or death. Care should be taken to follow the instructions... -
Page 4: Help & Support
First please read this manual thoroughly. Further details about a Warranty Statement can be found at the chapter 4 - Warranty. For technical support contact your local a Novasub Authorized Service Center or Seascape BV. Seascape BV De Hoogjens 22... -
Page 5: Safety Measurements
Safety precautions Do not attempt to use the SCC-1DR(VL) without reading this instruction manual in its entirety, including all the warnings. Make sure that you fully understand the use, displays and limitations of the instrument. If you have any questions about the manual or the SCC-1DR(VL), contact your Novasub Authorized Service Center before using the SCC-1DR(VL). -
Page 6: Maintenance
5 of 22 3 Maintenance The SCC-1DR(VL) is a semi ruggedized case. Although it is designed to withstand rough circumstances, you must treat it with the same proper care and caution as any other electronic instrument. 3.1.1 Maintenance by authorized dealer or distributor Have your SCC-1DR(VL) serviced by a Novasub Authorized Service Center. -
Page 7: Warranty
Warranty Period The Limited Warranty Period starts at the date of original retail purchase. The Warranty Period is two (2) years for the SCC-1DR(VL). Warranty applies only on manufacturing defaults. The Warranty Period is one (1) year for accessories, including mounting hardware and connector cables. -
Page 8: Glossary
The SCC-1DR is standard fitted with NiMH rechargeable batteries with a smart charger. The built in Microphone makes it able to have a crystal clear audio at the diver end. The SCC-1DR models are supplied with an external power supply. -
Page 9: Models
SCC-1DR(VL) MANUAL Version: 1.65 Date:7-Apr-15 8 of 22 Models SCC-1DR, 1 Diver Radio Ruggedized Surface control Case, 1 Diver communication radio. Including: Banana sockets for diver comms (2 & 4 wire) Multipin UTS connector Mic/Headset connector ... -
Page 10: General Specifications
Light control 0-100 % dimmable light control for the Int. Power supply 12 vdc NiMh 2,3 Ah battery with (Only L and VL Novasub Lux3R or 6R and up to 20 watt (Battery) battery condition monitoring LED’s versions) halogen 12v lights... -
Page 11: Optional
Headset with Mic Handheld Mic BoBox ; Breakout Box for remote comms control with both divers, 50 m cable. Novasub Camera and lights Hand Mic Headset Bobox LUXR 3&6 Led lights NSBCB camera 5.3.1 BOBOX The Bobox can be ordered at new order or post ordered for integration on previously built systems. -
Page 12: General Functions
SCC-1DR(VL) MANUAL Version: 1.65 Date:7-Apr-15 11 of 22 6 General Functions The SCC-1DR(VL) has the following control function and connections. Audio in Comms Camera Light Speaker Batt. Status Mode Switch Dimmer Switch LED’s Main Power Switch Volume Diver Microphone Volume... -
Page 13: Main Power
The system can be powered with 12-24 vdc and requires 25 to 65 watts. The units is standard supplied with a 100-240 vac to 24 vdc 25 watt Power Supply unit for the SCC-1DR and 65 watts for the SCC-1DR(VL). -
Page 14: Diver Communications
The divers can only speak to each other when the surface operator pushes the cross-talk switch to the desired direction. The SCC-1DR(VL) can be set for 4 wire communication (duplex). The audio In can be used and the diver can listen to the audio input from a Smart Phone or MP3 player or any other audio device. -
Page 15: Comms Volume Control
Another option is to us the headset/mic connector for an optional MIC with PTT to talk to the divers. The internal speaker can be switched of if required. When the Headset with Mic or the MIC only are connected, the internal MIC is automatically switched off. MIC-PTT and Headset/Mic are optional Novasub products... -
Page 16: Main Operating
SCC-1DR(VL) MANUAL Version: 1.65 Date:7-Apr-15 15 of 22 7 Main Operating This chapter describes the main basic operations to be able to start the system, have a live camera view, control the light and record the video. Also we explain how to playback and backup your files. -
Page 17: Camera And Light Control (Only Land Vl Models )
7.2.2 Light controller The SCC-1DR(VL) is standard fitted with a LED light controller that matches the Novasub LUX3 and LUX6 lights. The LED controller regulates the Ampere from 0-1,6 A at 24 vdc. An Halogen light bulb up to max. 25/30 watts can also be controlled directly from the LED-controller. -
Page 18: Panel Connections
Version: 1.65 Date:7-Apr-15 17 of 22 8 Panel Connections The SCC-1DR(VL) has connectors on the front panel and at the backside. The following connectors are on the front panel. Head/Mic The Mic/Headset connector can be used to connect the Mic/headset or only a handheld MIC. Multipin connector for a Headset wit Mic or Handheld Mic with PTT. -
Page 19: Back Connections
SCC-1DR(VL) MANUAL Version: 1.65 Date:7-Apr-15 18 of 22 9 Back connections The SCC-1DR(VL) is fitted standard with 4 connectors which are at the backside of the case. Video Out Audio Out Light Comms Comms Mic Multi-pin Power supply Head connector Power supply The Power supply connector is a standard IEC C14 connector socket. -
Page 20: Main Cable Connection
The camera and light connector is a multipin connector. Different types and makes can be used, depending on the clients requirements. 9.2.1 Standard connector, SCC-04-09a The SCC-1DR(VL) is standard fitted with a 10 pins multipin connector. Diver SCC 04-09a Type... -
Page 21: Comms Banana Sockets
SCC-1DR(VL) MANUAL Version: 1.65 Date:7-Apr-15 20 of 22 9.2.1 Comms Banana sockets Parallel to the Comms MIC and Head are the banana sockets connected. These can be used in a 2 or 4 wire configuration to connect the divers comms cable without the use of the Multipin connector. -
Page 22: Optional Extra Connectors
Version: 1.65 Date:7-Apr-15 21 of 22 Optional extra connectors The following extra connectors can be fitted on the back of the SCC-1DR(VL). 9.3.1 BoBox The Bobox connector is needed to connect the BoBox, the comms break-out box. SCC break-out Box...
