KVMSwitchTech AB-4140 Instruction Manual

4x4 vga matrix switcher
Hide thumbs

Advertisement

Quick Links

Download this manual
VGA Matrix Switcher
INSTRUCTION MANUAL
MODEL : AB-4140
4X4 VGA Matrix Switcher
VGA Matrix Switcher Series
Thank you for purchasing the AB-4140 VGA Matrix Switcher. You will find this unit easy to install and highly
reliable but it is essential that you read this manual thoroughly before attempting to use this switcher.

Advertisement

loading
Need help?

Need help?

Do you have a question about the AB-4140 and is the answer not in the manual?

Questions and answers

Related Manuals for KVMSwitchTech AB-4140

Summary of Contents for KVMSwitchTech AB-4140

  • Page 1 VGA Matrix Switcher Series Thank you for purchasing the AB-4140 VGA Matrix Switcher. You will find this unit easy to install and highly reliable but it is essential that you read this manual thoroughly before attempting to use this switcher.
  • Page 3 VGA video input and output cables. The AB-4140 is useful for Matrix signals from VGA source devices (such as: Personal computer, Set Top Box, and Satellite Receivers, etc.) To VGA destination devices (Such as LCD Monitors, VGA Monitors, Plasma LCD TV, VGA Projectors, etc.). Selection of inputs is made via the front panel push buttons or an Infrared Remote Control unit or RS-232 control by a computer.

  • Page 4: Specifications

    FEATURES  Supports 4x inputs VGA to 4x VGA outputs Matrix Switcher  Input signal type VGA (RGBHV)  Output Signal type VGA to VGA Monitor display  Higher Video Bandwidth 325MB each path R,G,B signals.  Supported HD high de nition resolutions XGA, SXGA, UXGA, WSXGA, WUXGA ...
  • Page 7 Before making any connections to the AB-4140. Observe the following: Ensure the mains voltage supply matches the label on the supplied plug- Pack (+/- 10%). Ensure that the power switch is OFF. Ensure that all system grounds (earth) are connected to a common point.
  • Page 9 VIDEO - VGA (RGBHV), connector with HD-15p (D-Sub) OUTPUT 1 - 4 PORT VGA CONNECT TO DISPLAY MONITOR SIGNALS: VIDEO - VGA(RGBHV), connector with HD-15p (D-Sub) AB-4140 SUPPORTS VGA FOUR INPUTS MATRIX TO FOUR SWITCH OUTPUTS SUPPORT CONTROL IR & RS-232 INTERFACE FROM A PC.

  • Page 10: Limited Warranty

    LIMITED WARRANTY KVMSwitchTech WARRANTY KVMSwitchTech warrants this product against defects in materials and workman ship for a period of 3 years from the date of purchase. Should this product, in KVMSwitchTech’s opinion, Prove defective within this warranty period, KVMSwitchTech, at its option, will repair this product without charge, to whatever extent it shall deem necessary to restore said product to proper operation condition.
  • Page 11 118 W. Streetsboro St., Suite 125 | Hudson, OH 44236 1-866-865-7737 1-234-380-5708 sales@kvmswitchtech.com www.kvmswitchtech.com...
