Rockwell powerflex 700H Programming Manual

Hide thumbs Also See for powerflex 700H:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
PowerFlex 700H AC Drives
PROGRAMMING MANUAL
High Power - Firmware Versions x.xxx - 3.001

Advertisement

Table of Contents
loading

Related Manuals for Rockwell powerflex 700H

Summary of Contents for Rockwell powerflex 700H

  • Page 1 PowerFlex 700H AC Drives PROGRAMMING MANUAL High Power - Firmware Versions x.xxx - 3.001...

  • Page 2: Important User Information

    Burn Hazard labels may be located on or inside the equipment (e.g., drive or motor) to alert people that surfaces may be at dangerous temperatures. PowerFlex, DriveExplorer, DriveExecutive, DPI, and SCANport are either trademarks or registered trademarks of Rockwell Automation, Inc.
  • Page 3 Summary of Changes Manual Updates This information summarizes the changes to the Programming Manual - PowerFlex 700H Adjustable Frequency AC Drive - High Power, publication 20C-PM001…, since the January 2007 release. Change See page... Updated “How Parameters are Organized” to include new parameters Added note that parameter 46 [Mtr NP Pwr Units] does not get changed with “Reset to Defaults”.
  • Page 4 Summary of Changes Change See page... Updated the “Fault/Alarm Cross Reference” tables to include the new items Added additional “Technical Support” information 3-12 Updated the “Sleep/Wake Mode” function to reflect the new “Invert” mode B-14...

  • Page 5: Table Of Contents

    Table of Contents Important User Information ..........1-2 Summary of Manual Updates .
  • Page 6 toc-2 Table of Contents Appendix B Application Notes External Brake Resistor ........... B-1 Minimum Speed.

  • Page 7: Preface

    What Is Not in this Manual The PowerFlex 700H Programming Manual is designed to provide basic start-up, programming and fault information. For installation information, refer to the PowerFlex 700S/700H Adjustable Frequency AC Drives Installation Instructions, publication PFLEX-IN006….

  • Page 8: Manual Conventions

    Online at . . . Allen-Bradley Drives Technical Support www.ab.com/support/abdrives • In this manual we refer to the PowerFlex 700H Adjustable Frequency Manual Conventions AC Drive as; drive, PowerFlex 700H or PowerFlex 700H Drive. • To help differentiate parameter names and LCD display text from other text, the following conventions will be used: –...
  • Page 9 Overview ATTENTION: To avoid an electric shock hazard, verify that the voltage on the bus capacitors has discharged completely before servicing. Check the DC bus voltage at the Power Terminal Block by measuring between the +DC and -DC terminals, between the +DC terminal and the chassis, and between the -DC terminal and the chassis.
  • Page 10 Overview Notes...

  • Page 11: Chapter 1 Start Up

    Chapter Start Up This chapter describes how you start up the PowerFlex 700H Drive. Refer to Appendix A for a brief description of the LCD HIM (Human Interface Module). For information on . . . See page . . .

  • Page 12: Status Indicators

    Start Up Applying Power to the Drive ❏ 4. Apply AC power and control voltages to the drive. If any of the six digital inputs are configured to “Stop – CF” (CF = Clear Fault) or “Enable,” verify that signals are present or reconfigure [Digital Inx Sel].

  • Page 13: Start-Up Routines

    Start Up Start-Up Routines The PowerFlex 700H is designed so that start up is simple and efficient. If you have an LCD HIM, two start-up methods are provided, allowing the user to select the desired level needed for the application.

  • Page 14: Running An Assisted Start Up

    Start Up Running an Assisted Start Important: This start-up routine requires an LCD HIM. The Assisted start-up routine asks simple yes or no questions and prompts you to input required information. Access Assisted Start Up by selecting “Start Up” from the Main Menu. To perform an Assisted Start-Up Step Key(s)

  • Page 15: About Parameters

    Chapter Programming and Parameters Chapter 2 provides a complete listing and description of the PowerFlex 700H parameters. The parameters can be programmed (viewed/edited) using an LCD HIM (Human Interface Module). As an alternative, programming can also be performed using DriveExplorer™ or DriveExecutive™...
  • Page 16 Programming and Parameters ➊ ➋ ➌ ➍ ➎ ➏ Parameter Name & Description Values 198 [Load Frm Usr Set] Default: “Ready” Loads a previously saved set of Options: “Ready” parameter values from a selected user set “User Set 1” location in drive nonvolatile memory to “User Set 2”...

  • Page 17: How Parameters Are Organized

    Programming and Parameters How Parameters are The LCD HIM displays parameters in a File-Group-Parameter or Numbered List view order. To switch display mode, access the Main Menu, press ALT, Organized then Sel while cursor is on the parameter selection. In addition, using [Param Access Lvl], the user has the option to display all parameters, commonly used parameters or diagnostic parameters.
  • Page 18 Programming and Parameters Advanced Parameter View Parameter 196 [Param Access Lvl] set to option 1 “Advanced.” File Group Parameters Monitor Metering Output Freq Output Power DC Bus Memory 013 Commanded Speed002 Output Powr Fctr 008 Analog In1 Value 016 M o n it Output Current Elapsed MWh Analog In2 Value 017...
  • Page 19 Programming and Parameters File Group Parameters Communication Comm Control Drive Logic Rslt Drive Ramp Rslt 273 DPI Port Value Drive Ref Rslt DPI Port Sel C o m m u n ic a ti o n Masks/Owners Logic Mask Fault Clr Mask Reference Owner 292 Start Mask MOP Mask...

  • Page 20: Monitor File

    Programming and Parameters Monitor File Parameter Name & Description Values 001 [Output Freq] Default: Read Only Output frequency present at U/T1, V/T2 & Min/Max: –/+[Maximum Freq] W/T3. Units: 0.1 Hz 002 [Commanded Speed] Default: Read Only Value of the active Speed/Frequency Min/Max: –/+[Maximum Speed] Reference.

  • Page 21: Motor Control File

    Programming and Parameters Parameter Name & Description Values 022 [Ramped Speed] Default: Read Only Value of commanded speed after Accel/ Min/Max: –/+320.0 Hz Decel, and S-Curve are applied. –/+19200.0 RPM Units: 0.1 Hz 0.1 RPM 023 [Speed Reference] Default: Read Only Summed value of ramped speed, process Min/Max: –/+320.0 Hz...
  • Page 22 Programming and Parameters Parameter Name & Description Values 046 [Mtr NP Pwr Units] Default: Drive Rating Based Selects the motor power units to be used. Options: 0 “Horsepower” “kiloWatts” “Convert HP” = converts all power units to “Convert HP” Horsepower. “Convert kW”...
  • Page 23 Programming and Parameters Parameter Name & Description Values 057 [Flux Up Mode] Default: “Manual” Flux is established for [Flux Up Time] Options: “Manual” before acceleration. 058 [Flux Up Time] Default: 0.2 Secs Sets the amount of time the drive will use Min/Max: 0.0/5.0 Secs to try and achieve full motor stator flux.
  • Page 24 2-10 Programming and Parameters Parameter Name & Description Values 069 [Start Boost] Default: Based on Drive Rating 0.0/[Motor NP Volts] × Sets the voltage boost level for starting Min/Max: and acceleration. Refer to parameter 083 Units: 0.25 [Overspeed Limit]. 0.1 VAC [Motor NP Volts] ×...

  • Page 25: Speed Command File

    Programming and Parameters 2-11 Speed Command File Parameter Name & Description Values 079 [Speed Units] Default: “Hz” Selects the units to be used for all speed Options: “Hz” related parameters. Options 0 & 1 “RPM” indicate status only. Options 2 & 3 will “Convert Hz”...
  • Page 26 2-12 Programming and Parameters Parameter Name & Description Values 087 [Skip Freq Band] Default: 0.0 Hz Determines the bandwidth around a skip Min/Max: 0.0/30.0 Hz frequency. [Skip Freq Band] is split, Units: 0.1 Hz applying 1/2 above and 1/2 below the actual skip frequency.
  • Page 27 Programming and Parameters 2-13 Parameter Name & Description Values 096 [TB Man Ref Sel] Default: “Analog In 1” Sets the manual speed reference source Options: “Analog In 1” when a digital input is configured for “Analog In 2” “Auto/Manual.” “Reserved” “MOP Level”...
  • Page 28 2-14 Programming and Parameters Parameter Name & Description Values 118 [Trim Out Select] Specifies which speed references are to be trimmed and allows you to trim the speed reference based on a percentage or the frequency of the input signal. Note: Added bit 2 “Add or %”...
  • Page 29 Programming and Parameters 2-15 Parameter Name & Description Values 126 [PI Reference Sel] Default: “PI Setpoint” thru Selects the source of the PI reference. Options: “PI Setpoint” “Analog In 1” “Analog In 2” “Reserved” “MOP Level” “Master Ref” 11-17 “Preset Spd1-7” 18-22 “DPI Port 1-5”...

  • Page 30: Dynamic Control File

    2-16 Programming and Parameters Parameter Name & Description Values 138 [PI Output Meter] Default: Read Only thru Present value of the PI output. Min/Max: –/+100.0 Hz –/+100.0% Units: 0.1 Hz 0.1% 460 [PI Reference Hi] Default: 100.0% Scales the upper value of [PI Reference Min/Max: –/+100.0% Sel] of the source.
  • Page 31 Programming and Parameters 2-17 Parameter Name & Description Values 149 [Current Lmt Gain] Default: 10000 Sets the responsiveness of the current Min/Max: 0/32767 limit. Units: 150 [Drive OL Mode] Default: “Both-PWM 1st” Selects drive response to increasing drive Options: “Reserved” temperature.
  • Page 32 2-18 Programming and Parameters Parameter Name & Description Values 159 [DC Brake Time] Default: 0.0 Secs thru Sets the amount of time DC brake current Min/Max: 0.0/90.0 Secs is “injected” into the motor. Units: 0.1 Secs 160 [Bus Reg Ki] Default: Sets the responsiveness of the bus Min/Max:...
  • Page 33 Programming and Parameters 2-19 Parameter Name & Description Values 169 [Flying Start En] Default: “Disabled” Enables/disables the function which Options: “Disabled” reconnects to a spinning motor at actual “Enabled” RPM when a start command is issued. 174 [Auto Rstrt Tries] Default: Sets the maximum number of times the Min/Max:...
  • Page 34 2-20 Programming and Parameters Parameter Name & Description Values 178 [Sleep Wake Mode] Default: “Disabled” Enables/disables the Sleep/Wake Options: “Disabled” function. Important: When enabled, the “Direct” (Enabled) following conditions must be met: “Invert” • A proper minimum value must be programmed for [Sleep Level].
  • Page 35 Programming and Parameters 2-21 Parameter Name & Description Values 182 [Sleep Level] Default: 5.000 mA, 5.000 Volts Defines the analog input level that will Min/Max: 4.000 mA/[Wake Level] stop the drive. 0.000 Volts/[Wake Level] Units: 0.001 mA 0.001 Volts 183 [Sleep Time] Default: 0.0 Secs Defines the amount of time at or below...

  • Page 36: Utility File

    2-22 Programming and Parameters Utility File Parameter Name & Description Values 190 [Direction Mode] Default: “Unipolar” thru Selects the method for changing drive Options: “Unipolar” direction. “Bipolar” “Reverse Dis” Mode Direction Change thru Unipolar Drive Logic Bipolar Sign of Reference Reverse Dis Not Changeable 192 [Save HIM Ref]...
  • Page 37 Programming and Parameters 2-23 Parameter Name & Description Values 197 [Reset To Defalts] Default: “Ready” thru Resets parameters to the factory defaults Options: “Ready” except parameters [Mtr NP Pwr Units], “Factory” [Speed Units], [Language], and [Param “Low Voltage” Access Lvl] (parameters 46, 79, 196 and “High Voltage”...
  • Page 38 2-24 Programming and Parameters Parameter Name & Description Values 209 [Drive Status 1] Read Only Present operating condition of the drive. 1 =Condition True 0 =Condition False x =Reserved Bit # Bits Bits 15 14 13 12 Description 11 10 9 Description Ref A Auto Port 0 (TB)
  • Page 39 Programming and Parameters 2-25 Parameter Name & Description Values 213 [Speed Ref Source] Default: Read Only Displays the source of the speed Options: 0 “PI Output” reference to the drive. “Analog In 1” “Analog In 2” “Reserved” “MOP Level” “Jog Speed 1” 11-17 “Preset Spd1-7”...
  • Page 40 2-26 Programming and Parameters Parameter Name & Description Values 220 [Motor OL Count] Default: Read Only Accumulated percentage of motor Min/Max: 0.0/100.0% overload. Continuously operating the Units: 0.1% motor over 100% of the motor overload setting will increase this value to 100% and cause a drive fault.
  • Page 41 Programming and Parameters 2-27 Parameter Name & Description Values 230 [Alarm 2 @ Fault] Read Only Captures and displays [Drive Alarm 2] at the time of thru the last fault. Note: Bits 14 and 15 were added for firmware version 2.001. 1 = Condition True 0 = Condition False x = Reserved...
  • Page 42 2-28 Programming and Parameters Parameter Name & Description Values [Fault 1 Time] Default: Read Only [Fault 2 Time] Min/Max: 0.0000/429496.7295 Hr [Fault 3 Time] Units: 0.0001 Hr [Fault 4 Time] [Fault 5 Time] [Fault 6 Time] [Fault 7 Time] [Fault 8 Time] The time between initial drive power up and the occurrence of the associated trip fault.

  • Page 43: Communication File

    Programming and Parameters 2-29 Communication File Parameter Name & Description Values 271 [Drive Logic Rslt] Read Only The final logic command resulting from the combination of all DPI and discrete inputs. This parameter has the same structure as the product-specific logic command received via DPI and is used in peer to peer communications.
  • Page 44 2-30 Programming and Parameters Parameter Name & Description Values 277 [Start Mask] [Logic Mask]. thru Controls which adapters can issue start commands. 278 [Jog Mask] [Logic Mask]. thru Controls which adapters can issue jog commands. 279 [Direction Mask] [Logic Mask]. thru Controls which adapters can issue forward/reverse direction commands.
  • Page 45 Programming and Parameters 2-31 Parameter Name & Description Values 293 [Accel Owner] [Stop Owner]. Adapter that has exclusive control of thru selecting [Accel Time 1, 2]. 294 [Decel Owner] [Stop Owner]. Adapter that has exclusive control of thru selecting [Decel Time 1, 2]. 295 [Fault Clr Owner] [Stop Owner].

  • Page 46: Inputs/Outputs File

    2-32 Programming and Parameters Inputs/Outputs File Parameter Name & Description Values 320 [Anlg In Config] Selects the mode for the analog inputs. 1 =Current 0 =Voltage x =Reserved Bit # Factory Default Bit Values 321 [Anlg In Sqr Root] Enables/disables the square root function for each input. 1 =Enable 0 =Disable x =Reserved...
  • Page 47 Programming and Parameters 2-33 Parameter Name & Description Values 341 [Anlg Out Absolut] Selects whether the signed value or absolute value of a parameter is used before being scaled to drive the analog output. 1 =Absolute 0 =Signed x =Reserved Bit # Factory Default Bit Values [Analog Out1 Sel]...
  • Page 48 2-34 Programming and Parameters Parameter Name & Description Values [Anlg1 Out Setpt] Default: 0.000 mA, 0.000 Volts [Anlg2 Out Setpt] Min/Max: 0.000/20.000mA Sets the analog output value from a –/+10.000V communication device. Example: Set Units: 0.001 mA [Data In Ax] to “377” (value from 0.001 Volt communication device).
  • Page 49 Programming and Parameters 2-35 Parameter Name & Description Values [Digital In1 Sel] Default: “Stop – CF” [Digital In2 Sel] Default: “Start” [Digital In3 Sel] Default: “Auto/ Manual” [Digital In4 Sel] Default: “Speed Sel 1” [Digital In5 Sel] Default: “Speed Sel 2” [Digital In6 Sel] Default: “Speed Sel 3”...
  • Page 50 2-36 Programming and Parameters Parameter Name & Description Values 379 [Dig Out Setpt] Sets the digital output value from a communication device. Example Set [Data In B1] to “379.” The first three bits of this value will determine the setting of [Digital Outx Sel] which should be set to value 30 “Param Cntl.”...
  • Page 51 Programming and Parameters 2-37 Parameter Name & Description Values Selected Option Definitions – [Analog Outx Sel], [Digital Inx Sel], [Digital Outx Sel] Option Description Related At Speed Relay changes state when drive has reached commanded speed. 380 384 388 Excl Link Links digital input to a digital output if the output is set to “Input 1-6 Link.”...

  • Page 52: Parameter Cross Reference - By Name

    2-38 Programming and Parameters Parameter Cross Reference Parameter Name Number Group Page Parameter Name Number Group Page Drive Ramp Rslt Comm Control 2-29 – by Name 20C-DG1 Remove 358 Digital Inputs 2-34 Drive Ref Rslt Comm Control 2-29 20C-DG1 Status Digital Inputs 2-34 Drive Status X...
  • Page 53 Programming and Parameters 2-39 Parameter Name Number Group Page Parameter Name Number Group Page Output Power Metering TB Man Ref Hi Speed Reference 2-13 Output Powr Fctr Metering TB Man Ref Lo Speed Reference 2-13 Output Voltage Metering TB Man Ref Sel Speed Reference 2-13 Overspeed Limit...

  • Page 54: Parameter Cross Reference - By Number

    2-40 Programming and Parameters Parameter Cross Reference Number Parameter Name Group Page PI Configuration Process PI/Trim 2-14 Number Parameter Name Group Page – by Number PI Control Process PI/Trim 2-14 Output Freq Metering PI Reference Sel Process PI/Trim 2-15 Commanded Speed Metering PI Setpoint Process PI/Trim 2-15...
  • Page 55 Programming and Parameters 2-41 Number Parameter Name Group Page Number Parameter Name Group Page Fault Frequency Diagnostics 2-26 380, 384, Digital OutX Sel Digital Outputs 2-36 Fault Amps Diagnostics 2-26 381, 385, Dig OutX Level Digital Outputs 2-37 Fault Bus Volts Diagnostics 2-26 227, 228 Status X @ Fault...
  • Page 56 2-42 Programming and Parameters Notes...

  • Page 57: Chapter 3 Troubleshooting

    Chapter Troubleshooting This chapter provides information to guide you in troubleshooting the PowerFlex 700H. Included is a listing and description of drive faults (with possible solutions, when applicable) and alarms. For information on… See page… Drive Status Faults and Alarms Manually Clearing Faults Fault &...

  • Page 58: Faults And Alarms

    Troubleshooting HIM Indication The LCD HIM also provides visual notification of a fault or alarm condition. Condition Display Drive is indicating a fault. F- > Faulted Auto The LCD HIM immediately reports the fault condition by displaying the following. — Fault — F •...

  • Page 59: Manually Clearing Faults

    Troubleshooting Manually Clearing Faults Step Key(s) 1. Press Esc to acknowledge the fault. The fault information will be removed so that you can use the HIM. 2. Address the condition that caused the fault. The cause must be corrected before the fault can be cleared.
  • Page 60 Troubleshooting No. Name Description Action (if appropriate) ➁ ➊ The heatsink temperature has HeatsinkOvrTp 1. Verify that the maximum ambient exceeded the maximum temperature has not been allowable value. exceeded. 85 degrees C = Alarm 2. Check the fans (including the ASIC 90 degrees C = Fault board on frame 10 and higher drives).
  • Page 61 Troubleshooting No. Name Description Action (if appropriate) ➁ 21 OutPhasMissng There is zero current in one of 1. Check the motor wiring. the output motor phases. 2. Check the motor for an open phase. ➋ The “fan/pump” mode is selected in [Motor Cntl Sel] and the ratio of 22 NP Hz Cnflct parameter 43 [Motor NP Hertz] to 55 [Maximum Freq] is greater than ➋...
  • Page 62 3. Replace the option board. Refer to Appendix E -“Instructions for ATEX Approved PowerFlex 700H Drives in Group II Category (2) Applications with ATEX Approved Motors” in the PowerFlex 700H/S High Power Drives Installation Manual, publication PFLEX-IN006… for information on installing this option board.
  • Page 63 Troubleshooting No. Name Description Action (if appropriate) ➁ 71 Periph Loss The communications card has 1. Check the DPI device event queue a fault on the network side. and corresponding fault information for the device. ➁ 81 Port DPI Loss The DPI port has stopped 1.
  • Page 64 Troubleshooting No. Name Description Action (if appropriate) ➁ 113 Fatal App A Fatal Application error has 1. Replace the Main Control board. occurred. ➁ 114 AutoT Enable Autotune is enabled but has Press the Start key within 20 seconds not started. of enabling autotune.
  • Page 65 Troubleshooting No. Name Description Action (if appropriate) ➊ The Wake timer is counting toward a value that will start the drive. 149 Waking ➋ Sleep/Wake configuration error. With parameter 178 [Sleep Wake 150 Sleep Config Mode] = “Direct,” possible causes include: drive is stopped and parameter 180 [Wake Level] <...

  • Page 66: Clearing Alarms

    3-10 Troubleshooting Clearing Alarms Alarms are automatically cleared when the condition that caused the alarm is no longer present. Common Symptoms and Drive does not Start from Start or Run Inputs wired to the terminal block. Corrective Actions Cause(s) Indication Corrective Action Drive is Faulted Flashing red status light Clear fault.
  • Page 67 Troubleshooting 3-11 Drive does not respond to changes in speed command. Cause(s) Indication Corrective Action No value is coming from the source LCD HIM Status Line 1. If the source is an analog input, of the command. indicates “At Speed” check wiring and use a meter to and output is 0 Hz.

  • Page 68: Technical Support Options

    3-12 Troubleshooting Drive will not reverse motor direction. Cause(s) Indication Corrective Action Digital input is not selected for None Check [Digital Inx Sel], page 2-35. Choose reversing control. correct input and program for reversing mode. Digital input is incorrectly wired. None Check input wiring.
  • Page 69 Troubleshooting 3-13 What You Need When You Call Tech Support When you contact Technical Support, please be prepared to provide the following information: • Order number • Product catalog number and drives series number (if applicable) • Product serial number •...
  • Page 70 3-14 Troubleshooting Notes...

  • Page 71: Him Overview

    LCD Display Elements ALT Functions Menu Structure Viewing and Editing Parameters Removing/Installing the HIM External and Internal The PowerFlex 700H provides a number of cable connection points Connections ➊ To Drive Control (DPI Interface Board) ➎ HIM panel opens to allow access to DPI ➋...

  • Page 72: Lcd Display Elements

    HIM Overview LCD Display Elements Display Description Direction⎥ Drive Status⎥ Alarm⎥ Auto/Man⎥ Information F- > Power Loss Auto Commanded or Output Frequency Main Menu: Diagnostics Programming / Monitoring / Troubleshooting Parameter Device Select ALT Functions To use an ALT function, press the ALT key, release it, then press the programming key associated with one of the following functions: Table A.A ALT Key Functions ALT Key and then …...

  • Page 73: Menu Structure

    Faults View Fault Queue Status Info Drive Status 1 Clear Faults Device Items Drive Status 2 Clr Fault Queue PowerFlex 700H Device Version Drive Alarm 1 Product Data Reset Device HIM Version Drive Alarm 2 Control Board Speed Ref Source...
  • Page 74 Reset User Dspy Return all the options for the User Display to factory default values. The PowerFlex 700H drive is initially set to Basic Parameter View. To view all parameters, set parameter 196 [Param Access Lvl] to option 1 “Advanced”.

  • Page 75: Viewing And Editing Parameters

    HIM Overview Viewing and Editing LCD HIM Parameters Step Key(s) Example Displays 1. In the Main Menu, press the Up Arrow or Down Arrow to scroll to “Parameter.” FGP: File 2. Press Enter. “FGP File” appears on the top Monitor line and the first three files appear below it.

  • Page 76: Removing/Installing The Him

    HIM Overview Removing/Installing the HIM The HIM can be removed or installed while the drive is powered. Important: HIM removal is only permissible in Auto mode. If the HIM is removed while in Manual mode or the HIM is the only remaining control device, a fault will occur.

  • Page 77: External Brake Resistor

    Appendix Application Notes For information on . . See page . . For information on . . See page . . External Brake Resistor Process PI Minimum Speed Reverse Speed Limit B-11 Motor Control Technology Skip Frequency B-12 Motor Overload Sleep Wake Mode B-14 Overspeed...

  • Page 78: Motor Control Technology

    Application Notes Motor Control Technology Within the PowerFlex family there are several motor control technologies: • Torque Producers • Torque Controllers • Speed Regulators Torque Producers Volts/Hertz This technology follows a specific pattern of voltage and frequency output to the motor, regardless of the motor being used. The shape of the V/Hz curve can be controlled a limited amount, but once the shape is determined, the drive output is fixed to those values.

  • Page 79: Motor Overload

    Speed regulation and torque regulation must be separated to understand drive operation. The PowerFlex 70/700 with Standard Control and the PowerFlex 700H can be programmed to regulate speed using the slip compensation feature. Slip compensation reacts to load changes by adjusting the drive output frequency to maintain motor speed.
  • Page 80 Application Notes of FLA for 60 seconds. These values assume the drive is operating above [Motor OL Hertz], and that [Motor OL Factor] is set to 1.00. Operation below 100% current causes the temperature calculation to account for motor cooling. Motor Overload Curve 100000 Cold...

  • Page 81: Overspeed

    Application Notes [Motor NP FLA] is multiplied by [Motor OL Factor] to select the rated current for the motor thermal overload. This can be used to raise or lower the level of current that will cause the motor thermal overload to trip. The effective overload factor is a combination of [Motor OL Hertz] and [Motor OL Factor].

  • Page 82: Power Loss Ride Through

    Application Notes The Overspeed Limit is entered in Hertz and added to Maximum Speed and the sum of the two (Speed Limit) limit the output frequency. This sum (Speed Limit) must is compared to Maximum Frequency and an alarm is initiated which prevents operation if the Speed Limit exceeds Maximum Frequency.
  • Page 83 Application Notes energized, or no input is programmed, the drive will recognize a power loss at 80% of [DC Bus Memory]. If a digital input is programmed for “Pwr Loss Lvl” and the input is energized, a power loss will be recognized at the value of [Power Loss Volts].

  • Page 84: Process Pi

    Application Notes Process PI The internal PI function of the PowerFlex 700H provides closed loop process control with proportional and integral control action. The function is designed for use in applications that require simple control of a process without external control devices. The PI function allows the microprocessor of the drive to follow a single process control loop.
  • Page 85 Application Notes The PI function reads a process variable input to the drive and compares it to a desired setpoint stored in the drive. The algorithm will then adjust the output of the PI regulator, changing drive output frequency to try and make the process variable equal the setpoint.
  • Page 86 B-10 Application Notes The drive must be running for the PI loop to be enabled. The loop will be disabled when the drive is ramping to a stop (unless “Stop Mode” is configured in [PI Configuration]), jogging or the signal loss protection for the analog input(s) is sensing a loss of signal.

  • Page 87: Reverse Speed Limit

    Application Notes B-11 Reverse Speed Limit Figure B.4 [Rev Speed Limit], parameter 454 set to zero [Maximum Speed] Reverse Forward Speed Speed Minimum [Maximum Speed = 0 Speed] –10V [Maximum Speed] Minimum Speed 0 Reverse Forward Speed Speed Minimum [Maximum Speed 0 Speed] –10V...

  • Page 88: Skip Frequency

    B-12 Application Notes Skip Frequency Figure B.6 Skip Frequency Frequency Command Frequency Drive Output Frequency Skip + 1/2 Band 35 Hz Skip Frequency 30 Hz Skip – 1/2 Band 25 Hz Time Some machinery may have a resonant operating frequency that must be avoided to minimize the risk of equipment damage.
  • Page 89 Application Notes B-13 Skip Frequency Examples The skip frequency will have Max. Frequency hysteresis so the output does not toggle between high and low values. Three distinct bands can Skip Band 1 Skip Frequency 1 be programmed. If none of the skip bands touch or overlap, each band has its own high/low limit.

  • Page 90: Sleep Wake Mode

    B-14 Application Notes Sleep Wake Mode This function stops (sleep) and starts (wake) the drive based on separately configurable analog input levels rather than discrete start and stop signals. by default, this function is disabled. The following Sleep/Wake modes are available: •...
  • Page 91 Application Notes B-15 Is Sleep-Wake Working? Have these conditions been met? 1. [Sleep-Wake Ref] must be set to the analog input that will control "Start/Stop" functions. Meet all Conditions! 2. [Sleep-Wake Mode] must = "1, Direct" (Enable) or "2, Invert (Enable)." 3.

  • Page 92: Start At Powerup

    B-16 Application Notes Start At PowerUp A powerup delay time of up to 30 seconds can be programmed through [Powerup Delay], parameter 167. After the time expires, the drive will start if all of the start permissive conditions are met. Before that time, restart is not possible.

  • Page 93: Stop Modes

    Application Notes B-17 Stop Modes Mode Description Coast Output Voltage Output Current Motor Speed Time Coast Time is load dependent Stop Command This method releases the motor and allows the load to stop by friction. 1. On Stop, the drive output goes immediately to zero (off). 2.
  • Page 94 B-18 Application Notes Mode Description Hold Output Voltage Output Voltage Output Current Output Current Motor Speed Motor Speed Output Current Output Voltage Brake Level Time Stop Zero Re-issuing a Command Command Start Command Speed This method combines two of the methods above. It uses drive output reduction to stop the load and DC injection to hold the load at zero speed once it has stopped.
  • Page 95 Index Numerics Autotune, 2-9 20C-DG1 Remove, 2-34 20C-DG1 Status, 2-34 Before Applying Power, 1-1 Brake Dynamic, 2-18 Accel Mask, 2-30 Break Frequency, 2-10 Accel Owner, 2-31 Break Voltage, 2-10 Accel Time x, 2-16 Bus Capacitors, Discharging, P-2 Alarm & Fault Types, 3-2 Bus Reg Kd, 2-18 Alarm 1 @ Fault, 2-26 Bus Reg Ki, 2-18...
