Page 5
3. Install and Disassemble a. Remove the battery cover (as shown in the figure), align the battery pins with the direction of the lens, and insert the battery. To remove the battery, gently pull the handle bar on the battery. b.
4. Battery Charging a. You can use a 5V 1A power adapter, PC, or mobile power bank to charge the camera via a data cable. It is recommended to turn off the camera during charging. b. The front indicator is solid red while charging, and turns off automatically when the battery is fully charged.
Page 7
5. Operating Instructions a. Power-on/Power-off Power-on: Press and hold the function button for about 3 seconds, followed by a power-on sound. Power-off: Press and hold the function button for about 3 seconds, followed by a power-off sound. b. Photo Select the photo mode, and press the function button to take photos. c.
Page 8
d. Operating screen The preview page is displayed after the camera is powered on (in screen lock mode, you can double-tap the screen or press the function button to wake up the camera). Camera setup On the preview page, slide down to enter setup page. Slide the screen in the reverse direction or press the function button to return to the preview page.
6. Quick Setup Control your device and interact it with other smart home devices in Mi Home App. a. Download Mi Home App Scan the QR code or go to App store to download and install Mi Home App. b. Add and connect a Mi Action Camera 4K Tap "My devices"...
Note: The GPS must be activated for some certain phones when searching for the Mi Action Camera 4K via Wi-Fi. After the App is connected to the camera successfully, Android phones disconnect the Internet and a prompt indicating no Internet connection is displayed on some certain phones.
8. Speci cations Product name: Mi Action Camera 4K Model: YDXJ01FM Dimensions: 71.5 mm x 42.7 mm x 29.5 mm Aperture: F2.8 Net weight: 99 g (including battery) Focal length: 3.2 mm Operating temperature: 0℃~45℃ Wide angle: 145° Storage temperature: -20℃~60℃ Bluetooth: Bluetooth 4.1 Wireless connections: Wi-Fi IEEE 802.11b/g/n Recording: dual microphone...
CAUTION RISK OF EXPLOSION IF BATTERIES IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCIONS. Environmentally friendly disposal Old electrical appliances must not be disposed of together with the residual waste, but have to be disposed of separately. The disposal at the communal collecting point via private persons is for free.
Page 13
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 14
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired opera- tion of the device.Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
Page 15
This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. End user must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The portable device is designed to meet the requirements for exposure to radio waves established by the ISED.
Page 16
Principal: Xiaomi Communications Co., Ltd. Manufacturer: Beijing FIMI Technology Co., Ltd. For further information, please go to http://www.mi.com/en/ Address: No.348, Floor 3, 1# Complex Building, Yongtaijiayuan, Qinghe, Haidian District, Beijing, China...
