- Page 1 CP183 CP183 CP183 CP183 Business Radio Business Radio Business Radio Business Radio User Manual User Manual User Manual User Manual...
-
Page 2: General Information
1. GENERAL INFORMATION Introduction The CP183 Business Radio combines quality and versatility into a compact, light and portable two-way radio with state-of-the-art design and easy-to-use features. Key Features 53 CTCSS and 104 DCS S.Q. Level control with 5 steps VOX Level control and On / Off D.W (Dual Watch) -
Page 3: Controls And Indicators
2. CONTROLS AND INDICATORS FEATURE REMARKS Indicates the Vox On OFF / LOW / HIGH Indicates the Beep Sound ON ON / OFF Indicates when the keypad is locked ON / OFF T4, T5 Indicates the CTCSS / DCS is on CTCSS / DCS Indicates the Power Saving is on Indicates the Dual Watch is activated... -
Page 4: Charging The Battery
3. CHARGING THE BATTERY 3.1 Charging the Battery 1. Plug the AC adaptor into the AC power outlet. 2. Connect the mini USB cable into the mini USB jack of the unit 3. Charge the radio. It will take 3 to 5 hours for full charging 1. -
Page 5: Lcd Back Lighting
In this case, you need to change the channel number to others when you transmit. 4. OPERATION 4.6 Monitor Press and hold key for longer that 2 sec. to monitor weak radio signal and release Key to stop the monitor. The Monitor key works to skip the channel as well during Scan or DW, if you short press it. -
Page 6: Squelch Level
4. OPERATION 4.14 Squelch Level Enter MENU mode by press and hold the “MODE” button longer than 2 sec. and select the SQL mode by press “MODE” button continuously. Its SQL will be blinking on the LCD. Press ▲ / ▼ key to increase or decrease squelch level from 1 to 5. In case, setting the radio to the tight squelch level, you can avoid unwanted signal or noise, but you may not receive a weak signal. -
Page 7: Technical Specifications
TECHNICAL SPECIFICATIONS General Channels FRS 22 CHs / PMR 8 CHs Temp. range - +55 FRS 462.5500 ~ 467.7125 MHz Frequency range Frequency stability +/-2.5ppm PMR 446.00625~446.09375MHz Battery type Lithium – Polymer Size (W x H x D) 44 x 74 x 16.8mm Battery capacity 750mAh Weight inc. -
Page 8: Channel Frequency Chart
CHANNEL FREQUENCY CHART C h a n n e l N o . F r e q u e n c y （ M H Z ） C a n n e l N o . F r e q u e n c y （ M H Z ） 4 6 2 . - Page 9 Office B, 15/F, King Palace Plaza, 55 King Yip Street, Kwun Tong, Kowloon, Hong Kong Tel: (852) 2185 7888 Fax: (852) 2187 3111 Website: www.cps-telecom.com 普 普 普 Contrad (Huizhou) Limited 快 快 快 快 惠 惠 有 有 有 有...
- Page 10 Never use cleaners or solvents to clean your device. Use a dry, lint-free cloth to clean the battery contacts. Do not submerge the unit in water. NOTE: CPS Telecom Limited is not responsible for any changes or modifications not expressly approved by the party responsible for compliance.
