Introducing the USB SoundWave Optical
The USB SoundWave Optical 5.1 transforms your PC into
a home theatre system with multi-channel surround
sound.
Features and Benefits
•
Compliant with USB 1.1 specification v1.1 and USB
Audio specification v1.0
•
Compatible with Microsoft USB Multi-channel
driver and all standard Windows games
•
True plug-n-play compatibility
•
Delivers 5.1 surround sound to all Microsoft
DirectSound and DirectSound3D enabled games
•
Supports DVD, MP3, Wave, Audio CD, MIDI audio
formats and many others
System Requirements
•
Pentium III 450 MHz or equivalent PC with an
available USB port
•
Windows 98SE/ME/2000/XP/Server 2003
•
128 MB RAM or above
•
Powered-speakers (5.1-channel speaker system
required for 5.1-channel sound effects)
04-0355A
USB SoundWave
Optical 5.1
Quick Installation Guide
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SIIG JU-IC5112-S2
Summary of Contents for SIIG JU-IC5112-S2
- Page 1 USB SoundWave Optical 5.1 Quick Installation Guide Introducing the USB SoundWave Optical The USB SoundWave Optical 5.1 transforms your PC into a home theatre system with multi-channel surround sound. Features and Benefits • Compliant with USB 1.1 specification v1.1 and USB Audio specification v1.0 •...
- Page 2 Package Contents • USB SoundWave Optical 5.1 • USB cable • Fiber optic cable • WinDVD software CD • This quick installation guide Layout USB (input) Connection/Activity Analog (output) Toslink optical (output) Figure 1: Layout Note: The Analog output jack is available for connecting stereo headphones or stereo speakers.
- Page 3 Hardware Installation Plug the included USB cable into the USB input port on the rear of the USB SoundWave Optical 5.1. Plug the other end of the USB cable into an available USB port. Plug the included Fiber optic cable into the Toslink optical output port of the USB SoundWave Optical 5.1.
- Page 4 Windows ME Install the sound card and start your system. At the Add New Hardware Wizard, click Next. Click Finish to complete the installation. Windows 2000/XP/Server 2003 Windows 2000/XP/Server 2003 automatically detects and installs the correct driver for the USB SoundWave Optical 5.1 when connected.
- Page 5 WinDVD Installation WinDVD is the premiere DVD software player for the Windows platform, providing you with the finest video and audio playback. Insert the WinDVD Installation CD. The setup program should start-up automatically. If not, click Start, Run, type in D:\Setup.exe, then click OK.
- Page 6 Blank Page...
- Page 7 The 5-year manufacturer warranty supplied with this product is offered by SIIG, Inc. If you should happen to encounter any problems with this product, please follow the procedures below.
- Page 8 Fremont, CA 94538-3152 USB SoundWave Optical 5.1 is a trademark of SIIG, Inc. SIIG and SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation. Other names used in this publication are for identification only and may be trademarks of their respective companies.
