- Page 1 OBSIDIAN SERIES ® 750D Obsidian Series 750D Full-Tower PC Case ® INSTALLATION GUIDE...
- Page 2 Short fan screws SSD/ODD screws OBSIDIAN SERIES ® 750D The 750D has a clean, elegant exterior that dispenses with arbitrary plastic add-ons in exchange for the beauty of brushed aluminum and solid steel. This rigid, rugged exterior surrounds a frame that has ample room for high-performance components and the sophisticated cooling you’ll need if you’re...
- Page 3 OBSIDIAN SERIES 750D FULL-TOWER PC CASE OBSIDIAN SERIES 750D FULL-TOWER PC CASE ® ® (x3) Corsair AF140L fans included Top triple 120mm or dual 140mm fan mounts compatible with 240/280/360mm radiators Rear 120/140mm fan mounts compatible with 120/140mm radiators Front dual 120/140mm fan mounts compatible with 240/280mm radiators (x2) USB 3.0, (x2) USB 2.0, Headphone/Mic, Power/Reset...
- Page 4 OBSIDIAN SERIES 750D FULL-TOWER PC CASE OBSIDIAN SERIES 750D FULL-TOWER PC CASE ® ® Built-in cable routing cutouts with grommets (x3) Tool-free removable optical drive bays Tool-free 3.5" hard drive cages with 2.5" compatibility (x4) Tool-free 2.5" SSD removable caddies (x9) Expansion slots for GPUs Removable front and bottom low restriction dust filters...
-
Page 5: Installing The Motherboard
(see your motherboard’s manual for guidance). > Align the motherboard with the stando s in the case. Note: Corsair recommends removing both side panels and setting > Secure with the included screws (MBD/HDD screws). them aside when building your system to avoid accidental damages. - Page 6 Installing the power supply (PSU) Installing the PCI-E/PCI cards > Remove thumbscrews and corresponding slot cover(s). > Seat the PSU on the bottom of the case. > Install the add-on card and secure with thumbscrews. > Align holes and secure the PSU with screws. Note: PSU can be installed in either fan up or fan down orientations.
- Page 7 Installing a 5.25" drive/devices (ODD) > Remove the front panel 5.25" drive bay cover. > Insert the ODD into the drive bay until the tool-free latch clicks, securing the drive. > To remove, push the tool-free tab to release the ODD drive and remove.
- Page 8 Installing a 3.5" HDD/ 2.5" SSD Installing a 2.5" SSD into tool-free expandable SSD cage > Remove the tool-free 3.5" HDD tray. > Pull down the tab and place the SSD into > Insert the HDD into the HDD tray. the tool-free cage until you feel it secure.
- Page 9 Removing the front and bottom dust filters > To remove the front panel dust filter, first remove the solid front panel by pushing the top corners of the aluminum cover. > The front solid panel will pop out for access to the front dust filter. >...
-
Page 10: Installing The Front I/O Connectors
Attach case fan cables to motherboard headers Installing the front I/O connectors > See your motherboard’s manual for front panel header locations and pin-outs. > See your motherboard’s manual for fan header locations. USB 3.0 USB 2.0 POWER SW HDD LED POWER LED –... - Page 11 How to remove the SSD caddy How to remove the HDD cage > Locate and remove the two screws securing the > To remove the SSD caddy, locate the center tab to the right cage to the base on the bottom of the case. of the caddy and then pull the tab in and lift to release the caddy.
