GRAPHITE
S E R I E S
®
GRAPHITE SERIES
INSTALLATION GUIDE
GUIDE D'INSTALLATION
n
GUIDA DI INSTALLAZIONE
Corsair Components Inc
Landing Parkway
Fremont • California •
• USA
corsair com
730T
730T FULL-TOWER PC CASE
®
INSTALLATIONSHANDBUCH
n
GUÍA DE INSTALACIÓN
n
n
安装指南
インストールガイド
n
n
© 2014 Corsair Components, Inc.
All rights reserved. Corsair, the sails logo and Graphit Series are registered trademarks of Corsair
in the United States and/or other countries. All other trademarks are the property of their respective
owners. Product may vary slightly from those pictured. / rev AB
