Universal Wireless AV Adapter
USER MANUAL
8820-00867 Rev. A00
F7D4550v1
Ok mk 7/27/11
TABLE OF CONTENTS
Getting Started
What's in the Box
How to Set It Up
Where to Place Your Universal Wireless AV Adapter
Getting to Know Your Universal Wireless AV Adapter
Front Panel
Back Panel
Technical Details
Technical Features
System Requirements
Using Your Universal Wireless AV Adapter
Updating the Firmware via the Web Interface
Resetting the Universal Wireless AV Adapter
Restoring your Universal Wireless AV Adapter to Factory Defaults
Troubleshooting, Support, and Warranty
Troubleshooting
Technical Support
Belkin International, Inc., Limited 2-Year Product Warranty
Regulatory Information
FCC Statement
Getting Started
What's in the Box
Universal Wireless AV Adapter
Advertisement
Related Manuals for Belkin F7D4550
Summary of Contents for Belkin F7D4550
- Page 1 Resetting the Universal Wireless AV Adapter Restoring your Universal Wireless AV Adapter to Factory Defaults Troubleshooting, Support, and Warranty Troubleshooting Technical Support Belkin International, Inc., Limited 2-Year Product Warranty Regulatory Information FCC Statement Getting Started What’s in the Box Universal Wireless AV Adapter...
- Page 2 Ethernet Cable Power Supply Quick Installation Guide Belkin CD with User Manual How to Set It Up To get started, you will need: Wireless router, with its network name and password Personal Computer Web Browser 1) Connect your Adapter’s Ethernet cable to your PC’s Ethernet port.
-
Page 3: Available Options
Note: Default language is English. You may change languages by clicking on the language icon and choosing from the available options. a. Click the “Get Started” button to begin the setup process. b. Follow the directions on your browser to set up your device. 3) Once the Adapter has successfully joined the wireless network, disconnect it from the PC, and unplug the power supply. - Page 4 4) Connect your Adapter’s Ethernet cable to your TV’s Ethernet port*. Plug the Adapter’s power supply into a wall outlet. *You can connect up to 4 Ethernet-enabled devices. Where to Place Your Universal Wireless AV Adapter For the best results, place the Universal Wireless AV Adapter (the Adapter) next to your TV or AV equipment in an open location away from large metal objects and magnets such as those found in speakers.
- Page 5 Modify the diagram to remove the line below “A” A) Universal Wireless AV Adapter Status Light Your Adapter’s status is shown by the light on the front. Off: The Adapter is not plugged into a power source. Blinking Blue: The Adapter is starting up. Blinking Blue/Amber: Indicates the Adapter needs to be set up.
- Page 6 Back Panel Modify the diagram to • Remove the “dot” above USB port (C) • Remove connectors A, C and re-label A) Wired (LAN) Connectors Connect up to four AV devices such as Internet-Enabled TVs. Blu- ray™ players, gaming consoles, or other Ethernet-enabled devices to these ports using Ethernet cables.
- Page 7 Note: Your PC needs to be wired to the Adapter in order to access the web interface. Open an Internet browser and type: http://belkin.universal into the address bar. The following steps show you how to update your Adapter’s firmware using its web...
- Page 8 Resetting the Universal Wireless AV Adapter Restart your Adapter Reset Button The “Reset” button is used in rare cases when the Adapter may function improperly. Resetting the Adapter will restore the Adapter’s normal operation while maintaining the programmed settings. You can also restore the factory default settings by using the “Reset” button.
- Page 9 Resetting the Universal Wireless AV Adapter Push and release the “Reset” button. The light on the Adapter will momentarily flash and then become solid again, indicating the reset is complete. Restoring Your Adapter to Factory Defaults Press and hold the “Reset” button for at least 10 seconds, and then release it. The light on the Adapter will become blue/amber in an alternating flash pattern indicating that the Adapter is ready to be set up again.
-
Page 10: Troubleshooting, Support, And Warranty
Troubleshooting, Support, and Warranty Troubleshooting Belkin Setup cannot find my Universal Wireless AV Adapter. If Belkin Setup is not able to communicate with your Adapter during the installation process, please make sure that the wireless router is turned on and has Internet connectivity. - Page 11 (metal is generally the worst culprit) are obstructions such as walls and metal appliances. Note also that connection speed may decrease as you move your Adapter farther away from the router. Technical Support http://www.belkin.com/support http://www.belkin.com/uk/support Australia http://www.belkin.com/au/support New Zealand http://www.belkin.com/au/support...
- Page 12 What is not covered by this warranty? All above warranties are null and void if the Belkin product is not provided to Belkin for inspection upon Belkin’s request at the sole expense of the purchaser, or if Belkin determines that the Belkin product has been improperly installed, altered in any way, or tampered with.
- Page 13 Your Belkin Customer Service Representative will then instruct you on how to forward your receipt and Belkin product and how to proceed with your claim. Belkin reserves the right to review the damaged Belkin product. All costs of shipping the Belkin product to Belkin for inspection shall be borne solely by the purchaser.
- Page 14 DECLARATION OF CONFORMITY WITH FCC RULES FOR ELECTROMAGNETIC COMPATIBILITY We, Belkin International, Inc., of 12045 E. Waterfront Drive, Playa Vista, CA 90094, declare under our sole responsibility that the device, F7D4550v1, complies with Part 15 of the FCC Rules. Operation is subject to the following two...
- Page 15 Caution: Exposure to Radio Frequency Radiation. The device shall be used in such a manner that the potential for human contact normal operation is minimized. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body.
-
