  • Page 1 ® TV ADAPTER FOR INTEL WIRELESS DISPLAY SCREENCAST User Manual F7D4501 8820ed00810 English...
  • Page 2: Table Of Contents

    Where to Place Your ScreenCast TV Adapter . . . . . . . . . . . . . . . . .
  • Page 3: Getting Started

    TV . Before the ScreenCast TV Adapter, you may have needed a long cable or simply crowded around your laptop screen to share movies, pictures, and surf the Web .
  • Page 4: What's In The Box

    PC vendor on which generation of WiDi your PC supports . • User Manual on CD • A TV with an available HDMI or RCA input port • B elkin recommends a 1080p-capable TV and HDMI • One HDMI Cable ® for the best picture and sound possible . If you use the ScreenCast TV Adapter with an older model TV that only has RCA (component) inputs, you will only be able to view standard-definition (480p) content.
  • Page 5: What Else Should I Know

    O nce connected, your laptop operates in all the standard Windows 7 multiple monitor modes: duplicate (mirror) ® images, extended (a second screen for more desktop space), or projector (laptop screen off and duplicate screen on). • I ntel WiFi hardware and Intel My WiFi Technology (Intel MWT) software allows both an easy connection to the ScreenCast TV Adapter and a standard connection to a wireless access point for Internet connectivity . • W ith Intel Wireless Display, you can watch videos on your HDTV while surfing the Web on your laptop .
  • Page 6: Adapter Setup

    WiDi laptop (sold separately)—this will help ensure that your TV receives the best possible signal and you get the most out of your ScreenCast TV Adapter . • The ScreenCast TV Adapter will be most effective within 30 feet of your laptop, but range will depend on...
  • Page 7: Software-First-Time Setup

    1 . Turn on your TV and switch it to the A/V input where your ScreenCast TV Adapter is connected . Then push the power button on the back of the Adapter . You should then see a screen that looks like this:...
  • Page 8 adaPTEr sETUP 2 . On your WiDi laptop, launch the Intel Wireless Display software . On some laptop PCs, this may be a switch at the top of the keyboard . Other PCs may require you to start a program from a shortcut on the desktop or in the system tray .
  • Page 9 3 . When you click to connect to the ScreenCast TV Adapter, a screen will appear on your TV with a 4-digit security code . A similar screen appears on your PC requesting that code . Enter the 4-digit code into the appropriate box on your laptop screen .
  • Page 10 4 . Name the ScreenCast TV Adapter . Naming it will allow you to easily find it in a list of available adapters should you have more than one within range . Use a name that is easy to remember like “Living Room WiDi”...
  • Page 11 ScreenCast TV Adapter with Belkin to receive updates and support . 6 . Once you have the display configured the way you want and you’ve registered your product, click “Complete .”...
  • Page 12: Using Your Screencast

    . The ScreenCast TV Adapter should appear on this list . • If you don’t see the ScreenCast TV Adapter on the list, you may need to move your laptop closer to the ScreenCast TV Adapter for a better signal .
  • Page 13: Options For Using The Tv Screen

    Using YOUr sCrEEnCasT Options for Using the TV screen You have three basic options for how to use your TV and laptop screens . • Mirroring or “cloning” (displaying the same content on both • Extended monitor—this allows you to keep using your laptop screen screens)—useful for when you want to use your laptop’s while sending content over to your TV for a larger group to see .
  • Page 14: What Else Do I Need To Know

    Bandwidth Digital Copyright Protection (HDCP). This support happens between the PC and the ScreenCast TV Adapter and between the ScreenCast TV Adapter and the TV . If any part of this chain is broken, the content may not play on the TV screen . Protected content playback is enforced by the software media player running on the PC .
  • Page 15: Using The Reset Button

    DESIGNER: [AH] the reset button shown in the diagram . a short press of this button (less than one second) will allow you to cycle between ALL DIMENSIONS IN MM. different language options for the ScreenCast TV Adapter . SCALE 1:1 hard reset of security profile LABEL MATERIAL: Mylar with matte PP finish • If you press the reset button for more than 5 seconds ,...
  • Page 16: Information

    Of COnfOrMiTY WiTh fCC rUlEs • Reorient or relocate the receiving antenna. fOr ElECTrOMagnETiC COMPaTibiliTY We, Belkin International, Inc ., of 12045 E . Waterfront Drive, Playa • Increase the distance between the equipment and the receiver. Vista, CA 90094, declare under our sole responsibility that the product, f7d4501, to which this declaration relates, complies with • C onnect the equipment to an outlet on a circuit different...
  • Page 17: European Compliance Statement

    European Compliance statement: Belkin International hereby declares that this F7D4501 ScreenCast TV Adapter for Intel Wireless Display is in compliance with the essential requirements and other revelant provisions of the RTT&E Directive 1999/5/EC, the EMC Directive 2004/108/EC, and the Low Voltage Directive 2006/5/EC . Conformity was assessed using a Technical Construction File .
  • Page 18: Belkin International, Inc ., Limited 2-Year Product Warranty

    What is not covered by this warranty? 2-Year Product Warranty All above warranties are null and void if the Belkin product is not provided to Belkin for inspection upon Belkin’s request at the sole expense of the purchaser, or if Belkin determines that the Belkin product has been improperly installed, altered in any way, or tampered What this warranty covers .
  • Page 19 Belkin reserves the right to review the damaged Belkin product . Some states do not allow limitations on how long an implied All costs of shipping the Belkin product to Belkin for inspection warranty lasts, so the above limitations may not apply to you .
  • Page 20: Technical Support

    You can find technical-support information on our website, RUSSIA 495 580 9541 www .belkin .com/networking/ www .belkin .com, by navigating to the tech-support section . SLOVAKIA 08000 04614 www .belkin .com/networking/ If you want to contact technical support by phone,...
  • Page 21 © 2011 Belkin International, Inc . All rights reserved . All trade names are registered trademarks of respective manufacturers listed . Windows is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries. HDMI is a trademark or registered trademark of HDMI Licensing LLC in the United States and other countries. Intel Wireless Display requires a compatible laptop PC, a TV adapter featuring Intel Wireless Display, and a TV with an available HDMI or Composite AV input. Compatible...
