PERCo WMD-06 Assembly And Operation Manual

Motorized electromechanical swing gate
Hide thumbs Also See for WMD-06:
Table of Contents

Advertisement

Quick Links

Download this manual
Motorized Electromechanical
Swing Gate
WMD-06
ASSEMBLY AND OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WMD-06 and is the answer not in the manual?

Questions and answers

Related Manuals for PERCo WMD-06

Summary of Contents for PERCo WMD-06

  • Page 1 Motorized Electromechanical Swing Gate WMD-06 ASSEMBLY AND OPERATION MANUAL...
  • Page 2 Motorized Electromechanical Swing Gate WMD-06 Assembly and Operation Manual...

  • Page 3: Table Of Contents

    CONTENTS 1 APPLICATION.........................3 2 OPERATION CONDITIONS ....................3 3 TECHNICAL SPECIFICATIONS ..................4 4 DELIVERY SET.......................5 4.1 Standard delivery set ....................5 4.2 Additional equipment supplied on request ............5 5 PRODUCT DESCRIPTION .....................6 5.1 Main features ......................6 5.2 Design........................6 5.3 RC panel .......................9 5.4 Parameters of input and output signals...............11 5.5 Operation contingences during gate operation ...........14 6 MARKING AND PACKAGING ..................15...

  • Page 4: Application

    Being an up- market model, it is recommended for fitting the highest requirements for design and comfort. It can be installed together with other turnstiles and barriers produced by PERCo or it can be used as a separate device.

  • Page 5: Technical Specifications

    Assembly and Operation Manual TECHNICAL SPECIFICATIONS DC operating voltage ..................24 V ±10% Current ........................ max. 4.4 А Power consumption ................... max.105 W Throughput rate in single passage mode............. 12 persons/min Passage modes ......................... 3 Passageway width: with AGG-650 swing panel................700 mm with AGG-900 swing panel................

  • Page 6: Delivery Set

    Motorized Electromechanical Swing Gate WMD-06 DELIVERY SET 4.1 Standard delivery set Basic equipment: Gate post ........................1 Glass panel ....................... 1 Note: Type of panel (AGG-650 or AGG-900) is chosen by the customer. RC panel with cable ....................1 Hex-nut wrench S1.5 ....................1 Gate installation kit: PFG IH 10 («SORMAT», Finland) anchor bolt with washer and nut M10 ....

  • Page 7: Product Description

    Assembly and Operation Manual PRODUCT DESCRIPTION 5.1 Main features  The swing gate can be operated autonomously from the RC panel or WRC as well as from an access control system (ACS). There are two variants of the gate control –...
  • Page 8 Motorized Electromechanical Swing Gate WMD-06 Figure 2. Overall view of the gate 1 – stationary base; 2 – housing; 3 – cover; 4 – glass panel; 5 – metal ring; 6 – control board;7 – rotary support; 8 – screw M3 (3 units); 9 – anchor; 10 – nut M10;...
  • Page 9 Assembly and Operation Manual Figure 3. External view of the control board XT1, XT2 – connector blocks; 1 – power cable +24 V; 2 – control cable (from RC panel / WRC unit / ACS controller); 3 – cable jumper (installed on default); 4 –...

  • Page 10: Rc Panel

    Motorized Electromechanical Swing Gate WMD-06 Table 1. Contacts of the control board Connector № Item Function of the contact block +24 V Connection of external power supply Light A relay contacts – connection of remote indicator for direction А Light B relay contacts – connection of remote indicator ХТ1...
  • Page 11 Assembly and Operation Manual Figure 4. General view and dimensions of the RC panel 1, 2, 3 – LEFT, RIGHT, STOP buttons for mode setting; 4, 5 – green indicators «Left», «Right»; 6 – red indicator «Stop»; 7 – cable Figure 5.

  • Page 12: Parameters Of Input And Output Signals

    Motorized Electromechanical Swing Gate WMD-06 Table 2. Connection of RC panel cable to XT2 connector block in standard and reversed orientation of the RC panel Orientation Number Title Standard Reversed Fire Alarm black black Unlock A white green Stop blue...
  • Page 13 Assembly and Operation Manual Figure 6. ACS control element, normally open relay contact Figure 7. ACS control element, open drain output scheme The device that sends Fire Alarm emergency unblocking signal is connected to Fire Alarm control input. Emergency unblocking is performed by turn-off of the low-level signal at Fire Alarm contact and GND contact on XT2 connector block.
  • Page 14 Motorized Electromechanical Swing Gate WMD-06 PASS outputs PASS A (Pass A and Common contacts of XT1 connector block), PASS B (Pass В and Common contacts of XT1 connector block) outputs are basically a relay. If the power is turned off, control board relays are normally open. In such case Common contact is not connected to the negative terminal of the gate's power supply (see Fig.

  • Page 15: Operation Contingences During Gate Operation

    Assembly and Operation Manual Output stages for Light A (Light B) are relay transfer contacts with the following signal specifications: maximum switching DC voltage ................ 30 V maximum switching AC voltage ................. 42 V maximum switching AC / DC ................3 A resistance of closed contact .............

  • Page 16: Marking And Packaging

    Motorized Electromechanical Swing Gate WMD-06 MARKING AND PACKAGING The swing gate has a marking in the form of label located inside rotary post under the cover. The label contains trademark and contact details of the manufacturer, the manufacture date, power voltage and power consumption. To get access to the marking take off the post cover by unscrewing three 3 screws using S1.5 wrench.

  • Page 17: Safety Requirements

    Assembly and Operation Manual SAFETY REQUIREMENTS 7.1 Installation safety Installation should be performed by qualified personnel only, in strict accordance with the Manual and general electrical safety requirements for electrical and installation work. Attention!  All the connections should be performed only after the control unit is disconnected from the power supply.

  • Page 18: Assembly And Installation

    Motorized Electromechanical Swing Gate WMD-06 ASSEMBLY AND INSTALLATION Observe safety requirements given in Section 7.1 during installation. 8.1 General recommendations Proper installation is critical to performance and serviceability of the swing gate. We advise you to study this Manual before installation work and follow the instructions to the latter.

  • Page 19: Installation Sequence

    Assembly and Operation Manual 8.4 Installation sequence Attention! The manufacturer shall not be liable for any damage caused in the result of improper installation and declines any claims arising thereof in case if the installation is not in compliance with the instructions provided in this Manual. Item numbers in the installation sequence are given according to Fig.
  • Page 20 Motorized Electromechanical Swing Gate WMD-06 Figure 11. Electrical connection layout Table 3. List of elements of electrical connection layout Legend Item Comments А1 Control board  Power supply unit of the swing gate +24V DC; 4А А2  Power supply unit of external indicators А3...
  • Page 21 Assembly and Operation Manual 6. Unscrew screws (8) and take off the cover (3) of the gate post. 7. Take off the housing (2) and the metal ring (5) by moving it up carefully along the axis of the post. 8.
  • Page 22 Motorized Electromechanical Swing Gate WMD-06 Figure 12. Glass panel mounting 1 – bolt M10; 2 – plastic bushing; 3 – nut M10; 4 – spring washer; 5 – expanded washer; 6 – glass panel; 7 – rotary support...

  • Page 23: Operation

    Assembly and Operation Manual OPERATION Observe safety requirements given in Section 7.2. Warning!  Do not move any objects through the passageway dimensions of which exceed the width of the passageway.  Do not hit elements of the swing gate so as to prevent their mechanical damage. ...

  • Page 24: Potential Control Mode

    Motorized Electromechanical Swing Gate WMD-06 Table 4. Operation modes in pulse control mode (jumper on Imp/Pot connector is installed) Operation Your actions on RC panel RC panel indication Panel position mode “Always Red indicator above STOP Panel sets in “Closed”...

  • Page 25: Emergency Situations

    ±90º angle, making the passage free. 9.5 Troubleshooting Possible faults to be corrected by the user themselves are listed in Table 6. In an unlikely event of other faults please consult the PERCo Technical Support Department. Table 6. Troubleshooting guide Most plausible Fault...

  • Page 26: Maintenance

    Motorized Electromechanical Swing Gate WMD-06 MAINTENANCE Technical maintenance of the swing gate should be performed only at PERCo service centre. We recommend using liquid non-abrasive cleansers containing ammonia to clean a swing gate post and a glass panel when dirty.

  • Page 27: Appendix A. Control Signal Algorithm In Pulse Control Mode

    Assembly and Operation Manual APPENDIX A. Control signal algorithm in pulse control mode The command is a signal active front (signal transfer from the high level to the low level) at any of the contacts at presence of the corresponding signal levels at the other contacts. Note: RC panel: ...

  • Page 28: Appendix B. Control Signal Algorithm In Potential Control Mode

    Motorized Electromechanical Swing Gate WMD-06 APPENDIX B. Control signal algorithm in potential control mode Note: For ACS controller outputs:  high level – either contacts of the output relay are broken or the output transistor is closed,  low level – either contacts of the output relay are closed or the output transistor is open.
  • Page 29 PERCo Polytechnicheskaya str., 4, block 2 194021, Saint Petersburg Russia Tel: +7 812 247 04 64 E-mail: export@perco.com support@perco.com www.perco.com...
  • Page 30 www.perco.com...
