High Resolution 360°Network Camera
NUD360-F
Model:
Local Storage Manual
Issued: 2017/7/20
Revision: Rev.1.0
Contents
1. Introduction .......................................................................... 2
2. Surveillance Solutions Using Local Storage ................................ 2
3. Required Hardware .............................................................. 10
4. Setting Up the Recording System ........................................... 11
Thank you for purchasing the ZOOM product.
Please read this manual carefully and use it correctly and safely.
Please read "Safety Instructions" before use.
Please keep this manual in a safe place.
Product operation and setting methods are described in the IP Utility and Web
Configurator instructions that are included in the CD-ROM provided with the product.
Note: In order to read the PDF file, Adobe Reader of Adobe Systems Corporation is
necessary.
Local Storage Manual
© OPT Corporation 2016
1
Rev.1.0
Advertisement
Related Manuals for Zoom NUD360-F
Summary of Contents for Zoom NUD360-F
- Page 1 2. Surveillance Solutions Using Local Storage ........ 2 3. Required Hardware .............. 10 4. Setting Up the Recording System ........... 11 Thank you for purchasing the ZOOM product. Please read this manual carefully and use it correctly and safely. ...
-
Page 2: Introduction
In addition, please install a web browser for the Internet in advance on the 2. Surveillance Solutions Using Local Storage The local storage system in NUD360-F is based on MicroSDHC memory cards. Below is the list of possible scenarios where the local storage could be used. - Page 3 Local Storage Manual Rev.1.0 Network Live Stream (for recording) Download Since the recording speed of MicroSDSC/SDXC is not as fast as Hard Disk, therefore one should keep in mind that MicroSDHC/SDXC based Camera Local Storage recordings may sometimes have less frames recorded compared to HDD recordings, while the quality of a single frame is just as good as in case of HDD recordings.
- Page 4 Local Storage Manual Rev.1.0 Disadvantages of “Local Storage Only” solution: Risk of dropped frames. When the amount of data is big, there is a risk that MicroSDHC cannot record them all in real-time speed, because it is not a hard disk. In such case, some of the video frames may be discarded by storage system.
- Page 5 Local Storage Manual Rev.1.0 Normal Situation FTP Storage in Cloud (idle) Network Local Storage Failure (damaged, removed, etc). FTP Storage in Cloud (recording) Network Live Stream (for recording) Download The FTP Server in this solution would be WAN based third party FTP hosting (Cloud FTP). Although it is also possible to use self-installed LAN or WAN-based FTP server, it would not be an economical decision –...
- Page 6 Local Storage Manual Rev.1.0 Advantages of “Local Storage + FTP Server” solution: Cost efficient. Compared to NVR solution, this solution is more budget friendly. Nowadays there are many FTP hosting plans that are totally free of charge. Easy to maintain. You don’t need to maintain the cloud FTP hosting by yourself – the owner of the hosting would do it.
- Page 7 Local Storage Manual Rev.1.0 2-3. LOCAL STORAGE + NVR SERVER This is the most professional solution – to have the NVR server continuously record the best quality video from the camera while the local storage of the camera is being used for backup recording at the same time to have the redundant video evidence in case of NVR server failure (for example power loss of server PC, unexpected Windows OS reboot, network link failure between camera and NVR, etc.).
- Page 8 Local Storage Manual Rev.1.0 Advantages of “Local Storage + NVR” solution: Video backup. Camera’s local storage can act as a video backup system. The user does not have to invest into an additional backup server computer. Besides, the remote backup server would still be useless if the network connection from the camera fails, whereas the local storage based backup system does not require network connection.
- Page 9 Local Storage Manual Rev.1.0 2-3. Solution Comparison Table There are surveillance projects that require the highest degree of recorder security and reliability, such as banks, while some others merely need basic video evidence and prefer cost-efficient solutions, such as construction sites, pet hotels, residential, etc. The following comparison table gives a simple and clear overview of each recording solution and their value to the customer.
-
Page 10: Required Hardware
ACTi local storage standard for cameras is MicroSDHC/SDXC interface. The camera package does not include the memory card, therefore the user would have to purchase one by oneself, depending on project requirements. Supported storage format of NUD360-F: Speed Class Local Storage... -
Page 11: Setting Up The Recording System
Local Storage Manual Rev.1.0 4. Setting Up the Recording System Recording system setup consists of 2 parts – storage preparation and recording rule configuration, to let the camera know under which condition and what kind of data is to be recorded. - Page 12 Local Storage Manual Rev.1.0 When the storage has been properly mounted to the camera, the “File Management” page would become accessible - it is no longer grayed out. You can later use “File Management” to search, download or delete the recordings. At first, the “File Management”...
- Page 13 Local Storage Manual Rev.1.0 Decide whether the camera should record video clips or snapshots. Video configuration Snapshot configuration The camera has the capability to buffer up to 3 With the settings above, it would create 1 seconds of video at any time, so that we can include snapshot within 1 second from the moment these 3 seconds of video to the file, to capture the of triggered event.
- Page 14 Local Storage Manual Rev.1.0 If you want to implement “Local Storage + FTP” solution, then you need to create one more Upload Configuration – push video to FTP, and later connect this rule with local storage failure or removal condition. In such case, you may use “Upload/video/snapshot2” item to fill in the additional configuration.
- Page 15 Local Storage Manual Rev.1.0 Decide whether the camera should record continuously or by specific schedule or only when the events occur. Scheduled or Continuous Recording Event Recording By choosing Triggered by Scheduler it is By choosing Triggered by Motion it is possible to define the exact time of possible to let the recording begin only recording.
- Page 16 Local Storage Manual Rev.1.0 In case of “Local Storage + FTP” solution, you also need to create 1 more rule, to handle the local storage failure or removal. In this example, we use rules 4 and 5 for that. Push video to FTP Server Upon Local Push video to FTP Server Upon Local Storage Failure Storage Removal...
- Page 17 Local Storage Manual Rev.1.0 4-3．Downloading Recordings There are several ways to view the list of recordings and download them. MANAGE FILES BY WEB CONFIGURATOR It is possible to manage the recordings conveniently by Web Configurator’s “File Management”. You can search, download or delete recordings.
- Page 18 Local Storage Manual Rev.1.0 The largest possible recording file is approximately 30 minutes. You can see the length of each file in the file list. In case of snapshots, the length is not available. Under continuous recording mode, the camera will make sure that the file size would not exceed 30-31 minutes –...
- Page 19 Local Storage Manual Rev.1.0 View and Download Snapshots By clicking on the snapshot file name in file list it is possible to view the snapshot within Web Configurator. To download the snapshot, right click on the picture and save it to the computer.
