U-Prox Keypad MF User Manual

Integrated Technical Vision Ltd.
U-Prox-Keypad MF.
Mifare reader. User manual
Introduction
The Mifare U-Prox-Keypad MF reader with built in keypad is
intended to be applied in different access control systems, using
RS232, Wiegand 26,
Wiegand 40, Wiegand 42 and Touch Memory interface.
The direct and reverse ID bytes order supported. Secure mode with
reader and cards serialization available.
The interface type is to be changed by special PC program. If you need to change the
interface type, please call your distributor. The reader placed in elegant plastic case with
bicolor LED indicator and keypad on front panel.
Types of cards
Integrated Technical Vision ltd manufactures readers operating with various kinds of Mifare
cards: MIFARE
®
MIFARE CLASSIC 1k, MIFARE
Features
Case
Material
Color
Dimensions
Weight
Ambient Conditions
Oper. temp.
Stor. temp
Humidity
Electrical
Voltage
Max current
Voltage ripple
Read Range
Typical read range is 40...50 mm and depends on tag type used.
Wiring
Reader has 8 wire cable for connecting to the access control panel.
Table 1. The wires assignment.
Color
Green
White
Red
Black
Brown
Orange
Blue
Yellow
AWG22 multiwire signal cable is recommended.
Using this cable the maximum length of 150
meters can be obtained
When you connect the reader to the interface
TouchMemory (iButton), and it does not work
consistently (for example, does not transmit the
*
Not for RS232 interface
http://www.itvsystems.com.ua
Wiegand 32, Wiegand 34, Wiegand 37,
®
Standard, MIFARE
®
Classic 4k, MIFARE
ABS plastic
black
119.4 х 65.4 х17.5
240 g
-0°C . . . +60°C
-0°C . . . +80°C
100% rel. at +25
+9. . . +16 VDC
up to 75 mA
up to 500 mV
Wiegand
Data 0
Data 1
+V
GND
Red Led
Green Led
Beep
Hold
*
.
®
Hi-Memory, MIFARE
®
CLASSIC 7UID.
mm
0
C
.
p-p
RS232 (reader)
Function
Rx
Tx
+V
GND
-
-
-
Hold
Figure 1
®
Ultralight, MIFARE
DB-9 (computer)
3
2
5
®
®
DESFire,
1
