How to transfer the contents of the memory to a PC?
To transfer the contents of the memory you must connect the reader switched off to the USB port of the PC directly or via
an USB cable. Run the Realtrace Terminal software.
Make sure in the Menu "Options" that the choice "Shows all data"is not
Push the button without relaxing the pressure until to hear a "Beep", in order to enter to setting "LANGUAGE" or
"MEMORY" mode. Stop to push the button. When the display shows "MEMORY". Push promptly again the button while
"MEMORY" is displayed. The display shows "SEND" . If you select "SEND" pushing promptly the button, all numbers
of tags stored in the memory of the reader will be transferred to the Realtrace Terminal window and the reader switch off
automatically. Then the display shows "ERASE"
Select "ERASE" pushing promptly the button. All data are erased of the memory and the reader will swich off
automatically. Then you can disable the memory
removed and the reader switch off automatically.
Without selecting a function, after three cycles, the reader switch off automatically.
*Don't forget to install the RT10M driver.
This software is a tool provided for free to all users of the RFID Realtrace V8BT, RT10M and RT250 readers.
After installing the software on your PC, the setting is normally automatic. However with some PCs you must do it
manually. In this case you have to go to " File " then " Connection Properties " then " Enter the port number " that has
been allocated either automatically or by your PC.
Choose your language.
You can choose between French, English, Spanish, and Chinese.
Select the data you want to appear:
With the RT10M it is not possible to select all datas
- If you do not select "All Data" only the ISO number of the "chip", or 15 numeric characters (FDXB and HDX), or 10
Hexadecimal characters (FDX A) will be displayed.
Do not forget to declare the type of keyboard you use - AZERTY or QWERTY - if not you risk having
inconsistent signs being displayed on the PC screen.
Using the "Realtrace Terminal"
Initial setup of the "RealTrace Terminal "software
The correct settings are:
- bits per second: 9600
- data bits: 8
- stop bits: 1
- parity: none
- flow control: none
"Options" menu
Example: 939 000004095425
activated.
selecting "DISABLE MEMORY".
The memory function is
