Information
•
Do not violate or infringe the copyright law and other
international copyright laws while using this player for
recording.
•
The copyright law forbids unauthorized reproduction of
copyrighted music for any other purpose other than self-
entertainment without the author's permission.
•
For the purpose of self-entertainment, it is strictly prohibited to
compile and disseminate copyrighted music to a third party
without the author's permission.
•
If copyrighted music is intentionally disseminated by means of
information network without the author's permission, the
infringer will violate "the right of communications to the public"
and "the right of distribution" and shall be subject to the
criminal charges.
•
The Company, and the manufacturers, distributors and dealers
of this player are not liable for any of the above infringement
acts.
•
The Company shall not be liable for any loss or damage
(whether anticipated or unanticipated loses) of customers or
other third parties due to the usage of the player.
•
Before introducing or using the player, please back-up all
essential information stored in PCs. The Company shall not be
liable for any loss or damage due to the usage of the player.
1
Advertisement
Table of Contents
Related Manuals for Odys Talky BT100
Summary of Contents for Odys Talky BT100
- Page 1 Information • Do not violate or infringe the copyright law and other international copyright laws while using this player for recording. • The copyright law forbids unauthorized reproduction of copyrighted music for any other purpose other than self- entertainment without the author’s permission. •...
-
Page 2: Safety Rules
Safety Rules • Please follow the rules depicted in this manual closely to ensure your safety. Before using the player, we would strongly encourage you to read through this user manual • Be more wary of any edges, uneven surfaces, metal parts, accessories and its packaging so as to prevent any possible injury or damage. - Page 3 • Turn down the volume before/while using this player as sudden loud sounds may damage your ear drums. • Refrain from dropping the player as well as any collision with other objects. • When plugging in/out the headphone/earphones or wires please hold the player and jacks firmly to prevent the wires from breaking and the player from dropping.
-
Page 4: Operation Procedures
Connecting to a PC Operation Procedures 1) Use the USB cable provided to connect to computer and it will be recognized as a USB Mass Storage Class and it can be found in “My Computer. 2) The files stored on the player can be managed through Windows File Explorer or “My Computer”... -
Page 5: Removing Hardware
Removing hardware 1) Double-click using the left button of your mouse on the icon that says “safely remove hardware”, as can be seen from the image below. This icon is located at the lower right hand corner of your computer screen. 2) When the icon appears, click the “Stop”... - Page 6 Copying music files to the player 1. Please refer to the previous section -“Connecting to a PC” to connect a PC to the player using a USB cable or a USB adapter. 2. If the connection is successful, a removable drive icon (F:\) will appear in “My Computer.”...
- Page 7 Features • Supports MP3 and WMA music file. • LED Indicator • Plug-and-Play USB Flash Disk function. • Normal or Random mode for music play. • • USB2.0 Full speed Supports Bluetooth Headset (HSP) and Hands-free (HFP) profile. FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference...
- Page 8 External View of Product and Features Headset Socket Vol + Previous Vol - Next Play/ Pause(On/ Off) USB Port...
-
Page 9: Connection Diagram
Connection Diagram Inline Control: Bluetooth Control Button... -
Page 10: Basic Function
Basic Function Switching the Bluetooth On • Press and hold the Bluetooth button on the Earphone • The Player takes about 5 sec to start up • Once it has started, a “beep” sound will be played Switching the Bluetooth Off Hold the Bluetooth button on the Earphone until you hear the shutdown “beep”... -
Page 11: Resetting The Player
Resetting the player For resetting the player, please use a stick or something that is able to press the RESET button which is at the end of the headphone jack. Press the RESET button ONCE. NOTE: Only use this button when the player has totally hanged and is not able to function. -
Page 12: Mp3 Mode
Hold (2 sec) 1. Bluetooth Power On and automatically when it is at pair and connect to the last paired Power Off mobile phone State 2. Continue holding for another 5 sec at startup to enter pairing (Note: This is the only way to enter pairing mode) Hold (5 sec) Power Off when it is at standby mode... -
Page 13: Led Indicator
LED Indicator Whenever Bluetooth is on, LED indication is as below. State LED status Standby & Connected Blue LED blinks once every 2 sec Standby & Not connected Blue LED blinks once every 1 sec Starting Up Blue LED light up Shutting Down Red LED light up until shutdown Pairing Mode... -
Page 14: Operating In Music Mode
Operating in Music Mode Once the player is turned on, press the NEXT or PREV button to search for the desired track. Press the PLAY button to play the current track, press again to pause playing, follow by battery level indication. Normal playing operation •... - Page 15 If you wish to enter pairing mode, continue holding for another 5 sec until there is a double “BEEP”. Once Enter Pairing, use your handphone to look for this Device (ODYS BT 100) Once it is found, select this device and key in the password: “0000”.
-
Page 16: Power Charge
Operating as a USB Drive Shutdown the player first. Use the USB cable provided to connect to your computer The computer will recognize it as a USB Mass Storage Class and it can be found in “My Computer” Power Charge •... -
Page 17: Troubleshooting
Trouble Shooting There is no sound when playing. Check to find if the volume is adjusted too low. If it is too low, turn it up. Make sure that the earphones are properly connected, or they are working properly. Sometimes abnormity occurs on the PC when disconnecting the player. - Page 18 Odys products are covered by a 24 month warranty. We will resolve damages or defects on Odys products free of charge within 12 months of the purchase date under the following warranty conditions. For any damage or defect determined later than 12 months after the purchase date, proof of a manufacturing fault must be submitted for repair under warranty.
- Page 19 warranty obligation in the event of marginal differences compared to the target appearance and workmanship provided these have a negligible effect on the product's fitness for use, in the event of damage caused by chemical or electrochemical effects, by water or generally from abnormal conditions.
- Page 20 work is carried out by unauthorized persons or if our products are equipped with additional parts or accessories that are not approved for our products. Warranties that have been activated do not cause the warranty period to be extended, nor do they trigger a new warranty period.
- Page 21 the AXDIA Service Center by e-mail, fax or phone (see below for contact details). You can also use the service form on our website or on the back of the warranty conditions. AXDIA Service Center will try to diagnose and solve your problem.
- Page 22 in such a way that it is visible and clearly legible. You must enclose a copy of the sales slip as proof of purchase. Once AXDIA has received the product, it will meet its warranty obligations in accordance with the warranty conditions and will return the product to the sender with carriage and insurance paid.
- Page 23 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
