ODYS MP3 player X30

Table of contents

1 Contents of package ....................................................2
2 Introduction ..................................................................4
3 Getting started .............................................................6
3.1
Controls.........................................................................6
3.2
Battery status ................................................................7
3.3
Installing the driver ........................................................8
3.4
3.5
Transferring files MP3 player - PC.................................9
3.6
DRM Protected Files ................................................... 13
3.7
Disable the MP3 Player from the PC ........................... 15
4 Operation ...................................................................16
4.1
Switching the MP3 player on and off ........................... 16
4.2
Music Mode ................................................................. 17
4.3
Photo Mode ................................................................. 22
4.4
Digital audio recording (Voice Mode)........................... 23
4.5
System settings (Setup) .............................................. 25
4.6
Deleting files (File)....................................................... 28
5 Troubleshooting .........................................................29
6 Specifications.............................................................31
7 Safety instructions......................................................32
Warranty conditions....................................................29
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Odys X30

Summary of Contents for Odys X30

  • Page 1: Table Of Contents

    ODYS MP3 player X30 Table of contents 1 Contents of package ............2 2 Introduction ..............4 3 Getting started .............6 Controls.................6 Battery status ..............7 Installing the driver ............8 Load the battery via the USB connection.......8 Transferring files MP3 player - PC.........9 DRM Protected Files ...........

  • Page 2: Contents Of Package

    ODYS MP3 player X30 Contents of package Please ensure that the following items are included in the box. If the package is not complete, please contact your dealer: USB cable Headphones ODYS MP3-Player X30 CD-ROM (driver and User manual Warranty card application software) 3.5mm Adaptor...
  • Page 3 ODYS MP3 player X30...

  • Page 4: Introduction

    ODYS MP3 player X30 Introduction Thank you for choosing our product. Please read this manual carefully before use to make best use of all functions of the product and to guarantee that it has a long service life. Please store the manual in a safe place for later reference.
  • Page 5 Any firmware updates for this MP3 player are also made available on our website. If you have questions or problems, please read the FAQs on our website or contact our customer support service support@odys.de.

  • Page 6: Getting Started

    ODYS MP3 player X30 Getting started Controls Familiarise yourself with the controls of your MP3 player before use. On/Off Display MENU PLAY Microphone PREV << NEXT >> Headphone USB - connector connection Line-In Key Functions PLAY : On/off, play, pause, stop, end the menu...

  • Page 7: Battery Status

    The internal battery may be charged by connecting to a free PC USB- Port or by using an optional power pack / charger (included with X30 Plus) sold seperatly (see Chapter 3.5). The power pack / charger is available and may be ordered from our web site www.odys.de.

  • Page 8: Installing The Driver

    ODYS MP3 player X30 If not to be used for longer periods, switch the player off using the main switch, otherwise the batteries may discharge quickly. Installing the driver When using Windows 98SE, you must first install the correspondding driver found on the CD-ROM before connecting the MP3 player to your computer.

  • Page 9: Transferring Files Mp3 Player - Pc

    ODYS MP3 player X30 If not to be used for longer periods, switch the player off using the main switch, otherwise the batteries may discharge quickly. Please charge the battery fully before using for the first time. Charging an empty battery will take approximately 3-4 hours.
  • Page 10 ODYS MP3 player X30 MSC Mode MTP Mode For transfering data For transfering data For syncronizing DRM Secured files Only standard folders can be used We suggest using the MSC Mode when using non-DRM files Please note that the player cannot recognize DRM files...
  • Page 11 ODYS MP3 player X30 Please do not use this folder to save MP3 or WMA files. Please note that only WAV files using IMADPCM coding can be used when in the voice playback mode. Please use the Music Playback mode to playback MP2 and WMA files.
  • Page 12 ODYS MP3 player X30 The device creates automatically a folder using the file format "DIR". Voice recordings which were created by the device using the file format WAV can be found in this folder. Please do not use this folder to save MP3 or WMA files.

  • Page 13: Drm Protected Files

    ODYS MP3 player X30 DRM Protected Files What is a DRM file? DRM stands for “Digital Rights Management”. WMA files that are legally downloaded from the internet are generally protected by DRM. These files contain a license that directs how the file may be used. All licenses are controlled by the Windows Media®...
  • Page 14 ODYS MP3 player X30 Note: To view the license information, right click the selected file and click on “PROPERTIES”. Copying an Audio CD Select “COPY” from the Windows Media® Player menu. All tracks must me copied to the PC when using the Windows Media® Player.

  • Page 15: Disable The Mp3 Player From The Pc

    ODYS MP3 player X30 Disable the MP3 Player from the PC Disable the digital MP3 player from the operating system correctly using the “Remove Hardware Safely” option Click the task bar on the right-hand side below the symbol and select the “Remove USB Mass Storage Device –...

  • Page 16: Operation

    ODYS MP3 player X30 Operation Switching the MP3 player on and off Switching the MP3 player on Use the ON/OFF Switch at the top to switch the player on. Hold the PLAY key down for approx. one second until the Display illuminates and a greeting is displayed.

  • Page 17: Music Mode

    ODYS MP3 player X30 Switching the MP3 player off Press and hold the PLAY key for approximately three seconds until the Display illumination deactivates. This is true irrespective of the current operating state of the player. If not to be used for longer periods, switch the player off using the main switch, otherwise the batteries may discharge quickly.
  • Page 18 ODYS MP3 player X30 Playback, forwards/back, pause, stop Insert one set of headphones in the headphone connections and turn the player on. The player is now in stop status. Press the PLAY button to play the track showed. The track information (ID3 tag) is scrolled on the Display.
  • Page 19 ODYS MP3 player X30 Repeat mode While in music playback, pause or stop state, briefly press the MENU button and use to select the Repeat mode (Repeat). Briefly press PLAY to switch to the Repeat sub-menu. to select the desired mode Confirm using the PLAY button again.
  • Page 20 ODYS MP3 player X30 Lyric Function Your player supports synchronous lyric display when playing MP3 files. The file name of the separate lyric files (*.lrc) must coincide with the file name of the relevant mp3 file (*.mp3) and the lyric file must be in the same folder.
  • Page 21 ODYS MP3 player X30 A/B repeat (Replay) This function allows you to repeat a specific section of a music file by setting the starting and finishing point of the section during playback. File: Track01 Briefly press the VOL key during playback to mark the beginning of the section (A).

  • Page 22: Photo Mode

    ODYS MP3 player X30 Photo Mode Implement to browse the JPEG picture and to support the format of JPEG in common use. Press the PLAY key of the turned-on player for approx. 1 sec. to switch to the main menu.

  • Page 23: Digital Audio Recording (Voice Mode)

    ODYS MP3 player X30 Digital audio recording (Voice Mode) Your MP3 player can also be used as a digital dictaphone. This allows you to record important ideas or thoughts when away from home, so you don’t forget them. Press the MENU key of the turned-on player for approx. 1 sec. to switch to the main menu.
  • Page 24 ODYS MP3 player X30 For deleting files please have a look on Chapter 4.6. You can also delete files or folders using your computer’s file manager when the MP3 player is connected to the PC via the USB connection. The device creates automatically a folder using the file format "DIR".

  • Page 25: System Settings (Setup)

    ODYS MP3 player X30 System settings (Setup) The mode Setup allows you to change important system settings for your MP3 player. It contains a total of 5 options. Press the MENU key of the turned-on player for approx. 1 sec. to switch to the main menu.
  • Page 26 ODYS MP3 player X30 If the Always on option is deactivated, the player will shutdown at the end of the set shutdown duration even if music is being played (Sleep Timer). Language Briefly press PLAY to switch to the Language sub-menu.
  • Page 27 ODYS MP3 player X30 Voice Recording Quality (Record) Briefly press PLAY to switch to the Record sub-menu. Quality keys are used to set the desired speech quality (High, Normal and Low). Confirm the setting with the PLAY key. Recording Device ●...

  • Page 28: Deleting Files (File)

    ODYS MP3 player X30 By selecting Yes you reset the player to the factory settings. System Info (Sys Info) Use the keys to select the Sys Info sub-menu and confirm using the PLAY key. Shows the current firmware version and the current amount of free memory space on your MP3 player.

  • Page 29: Troubleshooting

    ODYS MP3 player X30 Troubleshooting Symptoms Cause and solution Without power. Whether the battery is enough. Please confirm whether turn on the player. Without sound inside Please confirm the volume is not in the status of earphone. Zero and the connection of earphone is ok.
  • Page 30 ODYS MP3 player X30 connected to a USB installations CD. When connected to the PC, constantly hold down the "MINUS" button of the port. player and run the update. The MP3-Player shuts off Fully recharge the player. Charging the player after a short period of fully will take approximately 3-4 hours.

  • Page 31: Specifications

    ODYS MP3 player X30 Specifications 1 GB, 2 GB Internal memory Integrated flash memory Formats MP1, MP2, MP3, WMA, WAV, JPEG, BMP Record format Voice recording Record time approx. 8 hours (128 MB) Battery Li-Ion Battery life approx. 5 hours...

  • Page 32: Safety Instructions

    ODYS MP3 player X30 Safety instructions Although this product is safe, please observe the following information and warnings. Do not expose the device to direct sunlight, extreme heat or cold, damp or dusty conditions. Malfunctions and damage and can occur as a result..

  • Page 33: Warranty Conditions

    ODYS MP3 player X30 Warranty conditions The following conditions comprise the requirements and scope of our warranty conditions and do not affect our legal and contractual warranty obligations. We offer a warranty on our products in accordance with the following conditions: 1.
  • Page 34 ODYS MP3 player X30 1. Send the product suitably packaged with carriage and insurance paid. Do not enclose any accessories with the products (no cables, CD's, memory cards, manuals, etc.), unless the AXDIA Service Centre specifies otherwise. 2. Mark the RMA number on the outside of the package in such a way that it is visible and clearly legible.
