- Page 1 INSTALLATION AM 900 1200...
- Page 2 SAFETY INSTRUCTIONS This Manual must be read before installing The manufacturer cannot be held liable for the Airmaster air handling unit. Following damage arising from use or installing in this Manual will ensure this product is oper- contravention of these instructions. ated correctly.
-
Page 3: Table Of Contents
3.7. Fitting of Panels (AM 1200) ..................................10 3.8. Installation Check ......................................10 Appendix 1 Dimensional Drawings ........................11 AM 900 H ............................................11 AM 900 V ............................................11 AM 1200 H ............................................12 AM 1200 V ............................................13 Appendix 2 Additional Dimensions .........................15 Water Comfort Heater and condensate drain ..............................15... -
Page 5: General Information
General Information 6. Grilles (optional). Scope of Delivery: The Airmaster air handling unit with all options is packed on pallets. 7. Wall cover (optional). Please check the delivery before installation. 1. Airmaster air handling unit (AM). 8. Operator’s Manual (for programming) and Mounting Instructions and Installation Manual (for installation);... -
Page 6: Technical Specifications
Technical Specifications 1200 Weight, Standard unit without panels Colour, Panel (steel) 9010 9010 Design panel, dimensions 600x500 or 1200x1000 Colour, Case 9010 Dimensions see “Appendix 1 Dimensional Drawings” Minimum floor-to-ceiling height with wall ducts 2440* 2400 Minimum floor-to-ceiling height with roof ducts 2440* 2500 * Dimension can be reduced by up to 40 mm when there is no panel and the machine shoes are fully screwed down. -
Page 7: Air Handling Unit
3.3. Air Handling Unit Installation of an AM 900 1. Dismantle the floor panel of the unit. 2. Lift up the unit. on its adjustable feet. NB! When lifting the unit, protection must be provided for the height-adjustable feet to prevent breakage or deformation. - Page 8 Installation of an AM 1200 1. Fit the corner strips or the end panel set and position the ventilator section of the unit as close to the place of installation as possible. To achieve this, a pallet lifter may be used to move the unit. NB! The wheels are only suitable for fine adjustment of the unit position.
-
Page 9: Ducts, Grilles And Wall Cover
3.4. Ducts, Grilles and Wall Cover 3.5. Roof Cap The length of the air ducts is calculated on the basis of the Fit roof caps on the roof to finish off the installation of thickness of the wall/dimensions of the roof. exhaust and supply through a roof. -
Page 10: Fitting Of Panels (Am 1200)
3.7. Fitting of Panels (AM 1200) The panels should not be fitted until the unit is complete with all equipment, has been fitted and connected, and the functions of the unit are thoroughly tested. 1. Fit all design panel mounting strips. 2 strips for large design panels and 4 strips for small ones. -
Page 11: Appendix 1 Dimensional Drawings
Appendix 1 Dimensional Drawings AM 900 H 1 = Exhaust 2 = Supply 3 = Inlet AM 900 V 4 = Extract 5 = Electrical connections Ø315 Ø315 6 = Condensate drain 7 = Wall bracket * Dimension can be reduced by up to 50 mm when there is no panel and the machine shoes are fully screwed down. - Page 12 AM 1200 H AM1200HL 2427 AM1200HR 2427 1 = Exhaust 5 = Connection compartment, electrics 2 = Supply 6 = Condensate drain 3 = Inlet 7 = Service cover 4 = Extract 8 = Valves water comfort heater Appendix 1 - 12...
- Page 13 AM1200HC 2427 AM 1200 V AM1200VL 2427 Ø400 Ø400 1 = Exhaust 5 = Connection compartment, electrics 2 = Supply 6 = Condensate drain 3 = Inlet 7 = Service cover 4 = Extract 8 = Valves water comfort heater Appendix 1 - 13...
- Page 14 AM1200VR 2427 Ø400 Ø400 AM1200VC 2427 Ø400 Ø400 1 = Exhaust 5 = Connection compartment, electrics 2 = Supply 6 = Condensate drain 3 = Inlet 7 = Service cover 4 = Extract 8 = Valves water comfort heater Appendix 1 - 14...
-
Page 15: Appendix 2 Additional Dimensions
Appendix 2 Additional Dimensions Water Comfort Heater and condensate drain AM 1200 12xØ20 Ø20 6x 1, 6x 2 2427 Connection from beneath: 1: “DELIVERY” (FREM), 2: “RETURN” (RETUR). 3: “CONDENSATE” (KONDENS). Appendix 2 - 15... - Page 16 Industrivej 59 Tel: +45 98 62 48 22 info@airmaster.dk DK - 9600 Aars Fax: +45 98 62 57 77 www.airmaster-as.com Denmark...
