TOOLPRO
18V Cordless Jigsaw
Instruction Manual
Important
- Please read these instructions fully before operating or maintaining your jig saw
These instructions contain important information that will help you get the best from your
jig saw, ensuring it remains safe to operate.
If you need help or have damaged or missing parts, call the Customer Helpline on 1300 889 028
After Sales Support
FREE CALL 1300 889 028
EMAIL:salesau@positecgroup.com
CSJ18G.9
Advertisement
Table of Contents
Related Manuals for ToolPRO CSJ18G.9
Summary of Contents for ToolPRO CSJ18G.9
- Page 1 TOOLPRO 18V Cordless Jigsaw CSJ18G.9 Instruction Manual After Sales Support FREE CALL 1300 889 028 EMAIL:salesau@positecgroup.com Important - Please read these instructions fully before operating or maintaining your jig saw These instructions contain important information that will help you get the best from your jig saw, ensuring it remains safe to operate.
-
Page 2: Table Of Contents
Contents Safety Information ....................3 In The Box .........................9 Accessories ......................9 Operating Instructions .................... 10 Working hints for your Jig Saw ................13 Maintenance ......................17 Disposal of an exhausted battery pack ..............17 Troubleshooting ...................... 17 Technical Data ......................18 Customer Helpline 1300 889 028... -
Page 3: Safety Information
Safety Information Important - Please read these instructions fully before starting assembly Warning Symbols To reduce the risk of injury, Please read the instruction manual Warning Wear ear protection Wear eye protection Wear dust mask Indoor use only Do not expose to rain or water Do not burn Waste electrical products must not be disposed of with household waste. - Page 4 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.
- Page 5 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings key left attached to a rotating part of the power tool may result in personal injury. e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
- Page 6 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings 6) Service Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. Additional safety rules for your jig saw 1.
- Page 7 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings m) When disposing of battery packs, keep battery packs of different electrochemical systems separate from each other. n) Recharge only with the charger specified by manufacturer. Do not use any charger other than that specifically provided for use with the equipment.
- Page 8 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings 16. Keep battery charger’s slots are free of foreign objects and protect against dirt and humidity. Store in a dry and frost-free place. 17.
-
Page 9: In The Box
In The Box Parts Pendulum Action Control Lock-off Button On/Off switch Roller Guide Wood cutting blade Hand Grip Areas Tool-free Blade Holder Allen key Finger Protection Base Plate Angle Plate Accessories Allen key Wood cutting blade Customer Helpline 1300 889 028... -
Page 10: Operating Instructions
The saw blade recommendations are to be observed. 1. CHARGING We strongly recommend to use ToolPRO battery & charger kit. Please contact you local Supercheap Auto store for more details or log onto www.supercheapauto.com.au for Australia or www.supercheapauto.co.nz for New Zealand customers to find out more details. - Page 11 Operating Instructions CHARGING INDICATOR 1、Fast charger(See fig. A1) Light ON/OFF flash Status Charging Red on - - - - - Defective Battery Red flash Fully Charged Green on - - - - - - Hot/Cold Delay Green flash 2、Slow charger(See fig. A2) Light ON/OFF flash Status...
- Page 12 Operating Instructions 1. INSTALLING AND REMOVING THE BATTERY PACK (not supplied) A) TO REMOVE THE BATTERY PACK (SEE FIG B1) Depress the Battery Pack Release Button firmly first and then slide the Battery Pack out from your tool. B) TO INSTALL THE BATTERY PACK (SEE FIG B2) Slide the fully charged Battery Pack onto the tool with sufficient force until it clicks into position.
- Page 13 Operating Instructions 4. BLADE FITTING (SEE FIG. D, E, F) NOTE: Before any work on the tool itself, remove the battery. Wear protective gloves when assembling the saw blade. You can only use the blade type shown in (FIG D). Don’t use other blade types.
- Page 14 Operating Instructions 6. ADJUSTING THE CUTTING ANGLE (SEE FIG. G, H) Using a Allen key (4). Loosen the bolts securing the base plate (SEE FIG G). For preset angles rotate so the lines of the angle on the base plate and angle plate (6) superposition at the desired angle (0°, 15°, 30°, 45°) (SEE FIG H).For other miter angles, rotate to your desired angle (use a protractor scale).
- Page 15 Operating Instructions 8. PENDULUM ACTION CONTROL (SEE FIG I) The pendulum action varies the forward cutting angle of the blade for increased cutting efficiency. This can also be adjusted during no load running. Refer to the chart 1 for more details.
-
Page 16: Working Hints For Your Jig Saw
Working hints for your Jig Saw If your jig saw becomes too hot, especially when used at low speed, set the speed to maximum and run no Load for 2-3 minutes to cool the motor. Avoid prolonged usage at very low speeds. GENERAL Always use a blade suited to the material and material thickness to be cut. -
Page 17: Maintenance
Maintenance Before any work on the tool itself, remove the battery pack. There are no user serviceable parts in your power tool. Never use water or chemical cleaners to clean your power tool. Wipe clean with a dry cloth. Always store your power tool in a dry place. -
Page 18: Technical Data
Technical Data Technical Data Table Voltage No load speed 0-2400/min Stroke length 19mm Wood 65mm Cutting capacity Steel Bevel capacity ±45° Machine weight 1.82kg (Including battery) 1-1.5hr by fast charger, Charging time 3-5hrs by slow charger Charger Input 100-240V~50/60Hz 10.8~20V 1.5A by fast charger Charger Output 10.8--20V...
