D I A G R A M & L E G E N D
1. Internal Stem
2. Acetal Ring
3. Locking Screws
4. Crank Handle
5. Pole
6. Hub (Lower)
7. Hub (Upper)
*Adapter Plate A included and only to be used with mount kits. Free
standing BC05M steel base frames do not need adapter plate slots to
square up with umbrella.
3
7
13
6
5
4
3
2
1
8 9
10
11
12
8. Long Arm
9. Short Arm
10. Arm Strop (Hinge)
11. Arm End Fitting
12. Canopy
13. Strut
