Summary of Contents for Malekko Phase
- Page 1 USER MANUAL Malekko MALEKKO HEAVY INDUSTRY CORPORATION 1001 South Riviera Circle – Cedar Park, TX 78613 – 512 431 5428 Rev A...
-
Page 2: Controls And Connections
Input – You know what this is right? Output – see item #1 Footswitch On/O – Press the footswitch to turn your phase shifter on or o . When the LED is lit the e ect is on. Color – Shifts the phasing frequency. Counter clockwise, more bass passes through and decreases as you turn the potentiometer clockwise. - Page 3 Warning – Please read the following: Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Do not use this apparatus near water. 5. Clean only with dry cloth. 6. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
- Page 4 Using the Internal Frequency Trim Pot Use the internal trim pot to dial in a perfect phase tone. For even more exibility, this internal trim pot is a coarse frequency range selector. Simply ip the pedal over, unscrew the four retaining screws (screwdriver not included), and remove the bottom cover to reveal a tiny trim pot on the upper left-hand side.
