- Page 1 PowerPro Power Supplies Instruction manual Catalog No. PowerPro300 PowerPro3AMP PowerPro500 www.cleaverscientific.com Version 1 Revised on: 2017/7/19...
-
Page 2: Table Of Contents
Table of Contents PACKING LIST ......................3 WARNING ......................... 4 ..................8 ECTION NTRODUCTION 2.1 O ........................8 VERVIEW 2.2 P & F ..................9 RODUCT ESCRIPTION EATURE ................ 10 ECTION ECHNICAL PECIFICATION ..............11 ECTION NSTALLATION NSTRUCTIONS ............... 11 ECTION PERATION NSTRUCTIONS... -
Page 3: Packing List
Packing list checked by ________________________ Date ____________ Cleaver Scientific is liable for all missing or damaged parts / accessories within 7 days after customer received this instrument package. Please contact Cleaver Scientific immediately regarding this issue. If no response within such period from consignee... -
Page 4: Warning
Warning Cleaver Scientific PowerPro Power Supply has been tested and found to comply with the limits for the CE regulation. Also, it is RoHS compliant to deliver confident product which meets the environmental directive. These limits are designed to provide reasonable protection against harmful interference when the instrument series is operated in a commercial environment. - Page 5 Follow the guidelines below to ensure safe operation of the unit. The PowerPro Power Supply has been designed to utilize shielded wires thus minimizing any potential shock hazard to the user. Cleaver Scientific recommends against the use of unshielded wires.
- Page 6 Avoiding Damage to the Instrument 1. Do not attempt to operate the device if damage is suspected. 2. Protect this unit from physical damage, corrosive agents and extreme temperatures (direct sunlight, etc.). 3. For proper ventilation and safety concerns, keep at least 10 cm of space behind the instrument, and at least 5 cm of space on each side.
- Page 7 PowerPro 300 Max. voltage: 300 V Max. current: 700 mA Max. watt: 150 W PowerPro 3AMP Max. voltage: 300 V Max. current: 3000 mA Max. watt: 300 W PowerPro 500 Max. voltage: 500 V Max. current: 800mA Max. watt: 300W Potential Risk and Preventive Measure 1.
-
Page 8: Section 1 Introduction
Section 1 Introduction 2.1 Overview Cleaver Scientific PowerPro Series Power Supplies are recognized as unique power supplies equipped with very powerful specifications to cover the majority of electrophoresis applications on the market. Sufficient and accurate output voltages, five terminal pairs, and its compacted size can deliver accurate and reliable experimental results from one experiment to another. -
Page 9: Product Description & Feature
Cleaver Scientific PowerPro Series Power Supply provides Constant Voltage or Constant Current or Constant Power to instruments used in electrophoresis. 5 terminal pairs and the powerful specification equipped enable the maximum capability of PowerPro Series Power Supply compared to other existing similar product on the market. -
Page 10: Section 2 Technical Specification
Section 2 Technical Specification PowerPro 300 PowerPro 3AMP PowerPro 500 Output Voltage / Inc 5 - 300V / 1V 5 300 / 1V 5 500 / 1V Output Current / Inc 1 - 700mA / 1mA 10 3,000mA / 10mA 1 800mA / 1mA Max. -
Page 11: Section 3 Installation Instructions
Installation Instructions Section 3 PowerPro Series Power Supply is actually a pre-installed instrument. As long as it is placed on a sturdy and level surface in a safe, dry place, and further connects with well-prepared electrophoresis system, it is ready for operation. Operation Instructions Section 4 4.1 Control interface... -
Page 12: Start The Operation
Press to move cursor left forward between parameters Press to move cursor right forward between parameters Press to move cursor up between parameters and to increase numeric values Press to move cursor down between parameters and to decrease numeric values 4.2 Start the operation 1. -
Page 13: Constant Mode
4. Power on the unit by pressing the ON/OFF switch on the back. 5. The screen will show for few seconds then enter to the mode- selecting page. 4.3 Constant Mode Use the Constant Voltage / Current / Power Operation for applications that require only one specific voltage limit, current limit, and power limit continuously during the entire operation of electrophoresis. - Page 14 Ø Key and Key to select Constant Mode, and then press either to enter the next page. Ø to select ether Constant Voltage(V) or Constant Current(mA) or Constant Power(W), and then press to enter the next page Ø to move cursor to the parameter such as voltage (V) current (mA) or power (W) or time (min.).
- Page 15 Ø Press to switch pages between real- time value display and value set up page. Ø Press Key to temporarily interrupt power to ongoing electrophoresis without terminating the operation. The LED is flashing. Press Key to resume the run. Ø Press the Key again to stop electrophoresis and to terminate a timed run.
-
Page 16: Program Mode
4.4 Program Mode Instructions for operating PowerPro Series Power Supply in the programming operation are provided in this section. The Program Mode allows you to vary levels in voltage (V), current (mA), and power (W) during specified time periods for up to 6 Steps, depending upon your electrophoresis needs. - Page 17 Ø Press Key to start electrophoresis. The LED is lit, and the screen will show the real time parameter values. Ø When parameters reach the assigned value, the color would turn orange. Ø Press to switch pages between real- time value display and value set up page. Ø...
-
Page 18: Typical Running Condition
Ø If you need to make changes to the values of parameters during current running but do not want to terminate the time run, you may pause electrophoresis by pressing the Key. Press Key to enter the setting screen. Adjust the values and then press Key to resume your operation. - Page 19 Ú There are 4 categories that can be selected. Choose the model according to your experiment need. Ú Ø After selecting model, the preset value will display. User could adjust the value or simply just press start operation.
-
Page 20: Section 5 Trouble Shooting And Maintenance
Check AC power cord connections at connected both ends. Use the correct cords. Ø The fuse has blown Replace the fuse. Ø Contact Cleaver Scientific service Repeated fuse broken Hardware failure department Ø Operation stops and the It is recommended to send the... - Page 21 High voltage application is Ø DISABLE No Load alarm on the Display set to run on a very low Screen current Operation stops with Bad connections for Ø Check all the connections to alarm. Display shows terminal connectors or terminators, cables, wires, and gel damaged wires or damaged tanks platinum wires...
- Page 22 2. Call Technical Service or e-mail to support@cleaverscientific.com 3. If the unit must be shipped back for repair, contact Cleaver Scientific or the distributor for a Return Material Authorization number and shipping instructions. The unit will be repaired and returned to you as quickly as possible.
-
Page 23: Replacing The Fuse
4. Place the fuses holder back into the compartment. 5. Snap the cover closed. For additional fuses, contact Cleaver Scientific Maintenance PowerPro Series Power Supply uses all solid-state components and should require no maintenance or recalibration under normal use. If the unit must be returned for repair, contact our SERVICE DEPARTMENT or your local distributor for shipping instruction. -
Page 24: Section 7 Warranty
All claims made under this warranty must be presented to Cleaver Scientific within one year following the date of delivery of the product to the customer.
